Triad InCeiling Mini SealedRound Installation Manual page 6

Grill Scrim:
Our optional square grills include a sheet with four dark corner scrims.
These are used to line the inside corners of the square grills on light colored
walls and ceilings so that the contrast of the speaker baff e is not visible through
the grill. Simply transfer the four corner scrims to the corresponding corners on
the inside of the grill, with the glue side to the grill..
Speaker Grill Installation & Removal:
Attach the metal grill to the frame by placing the grill over the edge of the frame.
Grill will self-center onto the magnet system.
To remove the grill, grab the edge of the grill and gently pull away.
pg. 6 - Triad InCeiling Rounds Installation Manual
Tuning: Special Applications
Single Tweeter Models:
Tweeters on all models can be aimed up to 30 degrees in each direction around
the axis of their arms to vary their sound distribute pattern as desired.
DT: For typical dipole or diffuse Bipole applications, angle both tweeters in
opposite directions at their 30 degree extremes.
Dual Tweeter Models:
There are three primary applications for DT (Dual Tweeter) models.
Each application requires a different combination of Tweeter Orientation &
Bipole/Dipole Switch setting on the front baff e and Input Connections & Stereo/
Mono Switch setting on the back.
Stereo Mode (Factory Default)
Plays both channels of a two-channel system through a single speaker. This is
appropriate for areas where stereo separation is not desired, such as bathrooms,
dressing rooms, hallways, etc. This is the default setting as the speaker is
delivered to you from the factory. Both tweeters are in phase.
Tweeter Orientation Bipole Switch
to Bipole
Inputs/Stereo Switch
to Stereo
Triad InCeiling Rounds Installation Manual - pg. 7
