Triad InRoom Bronze Pedestal Assembly Instruction

Advertisement

Quick Links

InRoom Bronze LCR
Stand Assembly Instructions
To add stability to the stand, we recommend you fill the base with dry sand. It holds about 20 pounds, or
about 5 quarts (liters). For even more stability use lead shot, usually available at sporting goods stores.
Assemble the Stand
1
Open the plastic bag
4
Attach the base.
Use the longer screws
and two washers
2
*
Pour in the sand
3
Tighten the zip-tie
around the bag
and tuck it in.
*
Optional, but recommended
Attach the Speaker
5
Run the wire thru the stand.
6
Attach the wire to the speaker.
Red is positive
Black is negative
7
Attach the joining plate over the wire.
Use the shorter screws
and four washers
