EasyCoder 401/501/601 – Installation Instructions
LABEL-TAKEN SENSOR KIT
General Information
Note:
Illustrations show an EasyCoder 501.
The principles for fitting this optional
equipment in an EasyCoder 401,
EasyCoder 401 Linerless, or Easy-
Coder 601 printer are similar.
The label-taken sensor excludes the
fitting of a paper cutter and vice versa.
Preparation Before
Installation
EasyCoder 401/501/601
Label-Taken Sensor Kit
Installation Instructions
Edition 5, September 1998
Part No. 1-960350-06
This booklet contains instructions on how to install the Label-
Taken Sensor Kit (LTS) on EasyCoder 401, EasyCoder 401
Linerless, EasyCoder 501, and EasyCoder 601 printers. Installa-
tion should preferably be performed by an authorized service
technician.
For information on how to use the label-taken sensor, please refer
to the Technical Manual for EasyCoder 401, EasyCoder 401
Linerless, EasyCoder 501, or EasyCoder 601 respectively.
The Label-Taken Sensor Kit consists of:
• One Reflecting Sensor assy. with cable and connector
• One Sensor Bracket
• One Screw
• This Installation Instructions booklet
The only tools needed are #T10 and #T20 Torx screwdrivers and a
small non-conductive flat-tipped screwdriver.
Make a simple Fingerprint program that checks the status of the
LTS, e.g.:
10 BREAK 1,88
20 BREAK 1 ON
30 FORMFEED
40 IF (PRSTAT AND 2) THEN BEEP
50 GOT0 40
60 END
RUN
You can break this program by transmitting the character X
(ASCII 88) decimal on the standard serial interface "uart1:".
