Led Indicator For Jns Tri-Band Receiver - Javad MinPad User Manual

Solid green + red flashes
Solid red
Red flashes
Red flashes + green flashes

LED Indicator for JNS Tri-Band Receiver

The RX LED indicates the L-Band signal status
Flashes green
Solid green
Solid green + red flashes
The RX LED indicates the Beacon signal status
Flashes green
Solid green
Solid green + red flashes
The RX LED indicates the UHF signal status
Solid green
Solid green + red flashes
www.javad.com
LED Status
The color of the RX LED indicates the status of the differential corrections
for the Tri-Band board.
LED Status
K E Y S A N D L E D S
Explanation
Modem is receiving data.
Modem is in transmitter mode.
A fault condition has been detected.
Check the condition of the radio
modem's antenna to make sure it is not
damaged and connected properly and
securely. Also, make sure that there are
no conducting objects near the antenna
location.
Modem is in command mode.
Explanation
The satellite signal is being searched
The satellite is locked.
The data is being received
the Beacon station signal is being searched
The Beacon station is locked
The data is being received
The UHF is ready to receive a signal
The data is being received
MinPad User's Manual 2-11
RX LED
