RX LED

Your receiver may be equipped with a different modem type, e.g. with PDL
receiver from Pacific Crest or with JNS 2W UHF 410-470 radio transceiver,
with JNS 1W UHF902-928 MHz radio transceiver, L-Band/Beacon receiver, or
with single GSM/GPRS radio modem. The color of the RX LED indicates if the
modem has power, is receiving signals, or is turned off. The RX LED shows
status of the modem's operation.

L-Band/Beacon Receiver

The color of the RX LED indicates the status of the differential corrections for
the L-Band/Beacon board.
www.javad.com
Mode LED Status
No light
Green flashes
L-Band
Solid green
Solid green +
red flashes
No light
Green flashes
Beacon
Solid green
Solid green +
red flashes
The command BR002RG changes over the Red and Green
LEDs.
Explanation
Receiver is turned off.
Receiver is searching for the selected L-Band satellite.
The selected L-Band satellite is locked.
The L-Band satellite is locked and raw data is being
received.
Receiver is turned off.
The receiver is scanning for a Beacon station signal.
A signal from the Beacon station is locked
The receiver is tracking the signal from the Beacon station
and RTCM messages are being received.
