When data recording is ON, and the FN key is...
Not pressed
Pressed for < 1 second
Pressed for 1–5
Pressed for 5–8
seconds
Pressed for > 8
seconds
www.javad.com
Table 2-1. FN Key Functions and REC LED Status (Continued)
FN Key
Red
If FN key mode is «LED blink mode switch»
Green
If FN key mode is «Occupation mode switch»
Green
Orange
If FN key mode is «LED blink mode switch»
Orange
If FN key mode is «Occupation mode switch»
Orange
No light
Red
No light
REC LED
No free memory; hardware problem with
data recording.
Data recording started (post-processing
occupation mode undefined).
Data recording started (Kinematic post-
processing occupation mode).
Data recording started (Static post-
processing occupation mode).
Release to change information mode.
Release to toggle between Static and
Kinematic post-processing modes.
Release to stop data recording.
Release to turn serial port A baud rate to
9600 bps.
No function (data recording still on).
K E Y S A N D L E D S
FN Key and REC LED
Status
