Media and data export devices

Table 3: Media and data export devices
Function
Type and min.
size
RS-232 Control peripheral devices
USB host User storage of reference
port (supports waveforms, screen images,
removable USB and instrument setups.
flash drive) Control peripheral devices.
LAN Ethernet Control + data
connector
GPIB connector Control + data
Disable the RS-232 port
and USB functions
Tektronix BERTScope BSA Series Declassification and Security Instructions
The following table lists the data export devices in the standard instrument and listed options. Detailed procedures to
disable these devices, if any, are shown following the table.
Data Input method
Method of
modification
Directly
Directly User writeable
Directly N.A.
Directly N.A.
Complete the following steps to disable the RS-232 ports and USB functions:
1. Press Delete on the keyboard during Boot Up to go to the BIOS configuration menu.
2. Press the down arrow key and go to Integrated Peripherals.
3. Press Enter.
4. Press the down arrow key and go to Super IO Device.
5. Press Enter.
6. Go to Onboard Serial Port 1.
7. Press Enter.
8. Press the up arrow and set Serial Port to Disable.
Location Process to disable
Rear panel (COM1) The RS-232 port can be disabled. (See page 7, Disable
the RS-232 port and USB functions.)
Front and rear of instrument Files can be deleted or overwritten on the BERTScope or
on a PC, or USB flash drive can be removed or destroyed.
The USB ports can be disabled. (See page 7, Disable the
RS-232 port and USB functions.)
Rear panel The Ethernet port can be disabled. (See page 9, Disable
the Ehternet and GPIB ports.)
Rear panel The GPIB port can be disabled. (See page 9, Disable the
Ehternet and GPIB ports.)
Clear and sanitize procedures
