Mia Toybox
Assembly Instructions -
Dimensions
:
Width
80.0 cm
Depth
:
42.0 cm
Height
:
46.5 cm
Assembly Instructions -
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 0845 640 30 30
350273-01
Please keep for future reference
Please keep for future reference
White 2573968
Issue 00 - 25-05-2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Mia 2573968
Summary of Contents for Argos Mia 2573968
- Page 1 80.0 cm Depth 42.0 cm Height 46.5 cm Assembly Instructions - Please keep for future reference If you need help or have damaged or missing parts, call the Argos Customer Helpline: 0845 640 30 30 Issue 00 - 25-05-2014 350273-01...
