Summary of Contents for Mocka 040822
- Page 2 screwdriver required...
- Page 3 To begin assembly, use the allen key provided and a flathead screwdriver to loosely attach Upper Backboard [3], Lower Backboard [4] and Support Brace [5] to the Highchair Leg [1] using long screws (B) and bolt nuts (C). Hold the nut using the flathead screwdriver to ensure it is in the right position for the screws.
- Page 4 Slide seat board [7] at the appropriate height for your child’s comfort. For babies we recommend positioning the seat on the first or second level down. Slide the foot board [8] into the slots, 3 spaces below the top metal rod. If the seat and foot boards are slipping out of the slots, slightly tighten Rods [6] with the allen key.
- Page 5 1. Open the strap fully as shown below. 2. Fold the wing pieces flat on top of each other with the soft velcro side facing up. This will help the strap slide through the slot more easily. 3. Then feed the length of the strap through the slot until it reaches the wings.
- Page 6 5. Tighten fifth 6. Tighten sixth 3. Tighten third 4. Tighten fourth 1. Tighten first 1. Tighten first 2. Tighten second 2. Tighten second Gradually pull safety strap through the groove in the Seat board [7] and through the underside of the tray [9] as shown. Pull the strap tight and fold over the velcro flaps onto the strap to secure it in place.
