Summary of Contents for SIP TEMPEST 540/155
- Page 1 SIP TEMPEST 540/155 Wall Mounted Electric Pressure Washer 08909 User Manual EN • WARNING. Read the instructions before use and assembly...
- Page 3 2° 1°...
- Page 5 1° 3° 2°...
- Page 6 1° 2°...
-
Page 7: Technical Characteristics And Specifications
Read and keep in mind that indicated in the INSTRUCTION WARNING MANUAL - SAFETY WARNINGS. TECHNICAL CHARACTERISTICS AND SPECIFICATIONS 08909 Tempest 540/155 ELECTRICAL CONNECTIONS Power supply 230 V 1~50 Hz Input 2,4 kW Fuse 13 A HYDRAULIC CONNECTION Maximum water supply temperature 40 °C... -
Page 8: Parts Identification
PARTS IDENTIFICATION Refer to gs. 1, 2 and 3. 18 Water inlet lter Main ON/OFF switch Lifting and transport handle 19 Foam spray nozzle Left safety hook 20 Detergent suction adjustment device 21 Detergent ask Warning plate. It informs of residual risks; it is forbidden to use the machine without having read 22 High pressure gun lever the instruction manual rst;... -
Page 9: Standard Fittings
• Service centre booklet. • Key for disassembling the nozzle. • Nozzle cleaning pin. If there are problems, contact your dealer or SIP After Sales Department. OPTIONAL ACCESSORIES The following range of accessories can be added to the standard high-pressure cleaner equipment: •... -
Page 10: Installation Wall Mounting
INSTALLATION WALL MOUNTING • Chose a suitable wall where the high pressure water cleaner can be mounted: the high pressure water cleaner must be mounted exclusively on brick walls or reinforced cement walls with thickness of no less than 10 cm/4”; do not mount the high pressure water cleaner on walls made of plasterboard, wood, sheet metal or any other material that is not suitable to take the wall-plugs supplied. - Page 11 guarantees the correct connection of the suction pipe, which would otherwise interfere with the oor. See FIG. 7C. • Raise the stops (3) and (7), so that they uncouple from the cowling of the high pressure water cleaner and release the stop (8), pushing it inwards until it clicks in place. SEE FIG.
-
Page 12: Routine Maintenance
STOPPING TOTAL STOP • Release the lever (22) of the high pressure water gun and the cleaner will stop automatically. The cleaner will start again regularly the next time the lever of the high pressure water gun is pressed. STOPPING •... -
Page 13: Supplementary Maintenance
SUPPLEMENTARY MAINTENANCE Supplementary maintenance must be carried out by a , following the QUALIFIED TECHNICIAN table below (guideline data). MAINTENANCE INTERVAL OPERATION Every 50 hours • Check the pump hydraulic circuit (water). • Check pump xing Every 100 hours • Pump oil replacement. •... -
Page 14: Eu Declaration Of Conformity
And the relevant harmonised standard/s, including: EN 60335-1 EN 60335-2-79 EN 62233:2008 EN 50581 EN 55014-1:2006+A1:2009+A2:2011 EN 55014-2:2015 EN 61000-3-2:2014. EN 61000-3-3:2013. Name: Mr Paul Ippaso The echnical ile is kep a: Position: Director SIP Indusrial Producs Ld Loughborough Leicesershire LE12 9NH UK... - Page 15 Leicestershire LE12 9NH England As the manufacturer within the UK, England, Scotland & Wales, declare that the SIP Tempest 540/155 Wall Mounted Pressure Washer Part No. 08909 Suppliers Model Type: 90520017 Max Flow: 8,5 l/min Net Installed Power: 2400 W Conforms to the requirements of the following Directive/s, as indicated.
- Page 16 This will allow the recycling of raw materials and help protect the environment. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: TEL: 01509 500400 EMAIL: sales@sip-group.com or technical@sip-group.com...
