Intermec CN2A Instructions

Serial adapter

Hide thumbs Also See for CN2A:

Installing and Using the Serial Adapter

Remove the serial port plug from the serial port.

Serial

port plug

Clips

DB9

connector

Slide the serial adapter onto the CN2 and snap the two clips into

place on the CN2.

Connect a serial printer or button link to the DB9 connector on the

serial adapter.

While holding the CN2, push down on the serial adapter until the

clips are released from the CN2.

Clips

Slide the adapter off the CN2.

Table of Contents

Do you have a question about the CN2A and is the answer not in the manual?

Page 1 CN2 Serial Adapter Instructions Use the CN2 Serial Adapter (P/N 074247) to turn the 16-pin serial port (COM1) on the CN2 into a DB9 (9-pin) male serial connector that you can connect to a serial printer or a button link. Installing and Using the Serial Adapter Remove the serial port plug from the serial port.
Page 2: Specifications
6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2005 Intermec Technologies Corporation. All rights reserved. CN2 Serial Adapter Instructions *074758-002* P/N 074758-002 1 - Not connected 2 - Receive data (RXD) 3 - Transmit data (TXD)
