Numerous cabling options enable Zebra Portable Line printers to connect to a variety of popular hand-held
terminals. The following table depicts the Zebra cable for specific portable terminals:
CABLE
DESCRIPTION
RJ-45 to DB9 (Shielded)
Null Modem Cable
RJ-45 to MOD10
(Shielded) Cable
RJ-45 to MOD10
(Shielded) Cable
RJ-45 to PIM Optical
LPT (Shielded) Cable
RJ-45 to PIM Optical
COM (Shielded) Cable
RJ-45 to DB-15 Micro
D-Shell (Shielded) Cable
RJ-45 to DB-25 Shielded
Null Modem Cable
RJ-45 to 6 Pin Circular
Connector with Locking
End Cap (Shielded) Cable
RJ-45 to 6 Position
Circular DIN (Shielded)
Cable
RJ-45 to DB-9
Development (Not-
Shielded) Cable
RJ-45 to DB-9
Development (Shielded)
Cable
RJ-45 to DA15P with
Ferrite
RJ-45 to Hotsync 10P
(Shielded) Cable
PA/PT Mobile Printers
PX400 Cable_TableII.doc
CABLING OPTIONS
P/N#
TERMINAL
MODELS
Intermec : Trakker Antares
562014
T2425, Janus 2020
LXE : 1380, 1390, 1590,
MX1, MX3
Norand : 6400
This cable also works with most PC's
LXE : 2325
TBD
Percon : Falcon 310, 315, 320,
325
Symbol : PDT3100, PDT3110,
52502
PDT3140, PDT3200, PDT3300,
PDT3500, PDT6100, PDT 6140
Symbol : LRT3800, LDT3805,
52532
PDT6800, PDT 6840
Correct cable depends on software
settings. Contact your software
integrator to recommend appropriate
cable.
52704
Telxon : PTC960L,
562015
PTC960LE, PTC960RL,
PTC960SL, PTC960M
Telxon : PTC510, PTC610,
52545
PTC701, PTC710, PTC730,
PTC860, PTC860ES, PTC1134,
PTC2134
Norand : RT1700, with
52572
HR10A connector
LXE : 2280, 1280
52568
Connects to existing null
562006
modem cable of installed
printers or PDT to PC cable.
Connects to existing null
562011
modem cable of installed
printers or PDT to PC cable.
52686
Symbol : SPT1500
52663
Palm : Palm III
CABLE
DIAGRAMS
August 14, 2001
Page 1 of 2
