813 Compact Autosampler
Program version 5.813.0010
Instructions for use
06.2001 / dm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 813 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Metrohm 813

Summary of Contents for Metrohm 813

  • Page 1 CH-9101 Herisau/Switzerland Phone +41 71 353 85 85 +41 71 353 89 01 E-Mail info@metrohm.ch http://www.metrohm.com 813 Compact Autosampler Program version 5.813.0010 Instructions for use 8.813.1003 06.2001 / dm...
  • Page 2 Oberdorfstr. 68 CH-9100 Herisau Edition 2001 Copyright © 2001 by Metrohm Ltd. All rights reserved. This manual was carefully produced. Nevertheless the author does not warrant the information contained herein to be free of errors. The author appreciates your comments and feedback.

  • Page 3: Table Of Contents

    2.3.5 Placing the sample rack................12 2.3.6 Adjusting the sample rack ...............12 2.3.7 Tubing connections..................14 2.3.8 Tubing connection to Metrohm 761 / 790 IC–Systems ......15 2.3.9 Tubing connection to a Metrohm 747 VA Stand........16 2.3.10 Tubing connection to a Metrohm Computrace 757.........16 2.4 Instrument connections................17...
  • Page 4 3.2.1 Course of configuration ................23 3.3 RAM initialization..................24 3.4 The methods ....................25 3.5 The Metrohm IC control software ............. 27 3.5.1 Operational conditions................27 3.6 Modular Metrohm IC System 732/733 ............28 3.7 Metrohm 746 VA Trace Analyzer ............... 28 3.7.1 Monitoring ....................28...
  • Page 5 Fig. 12 Interconnection with 761 or 790 IC System ..........17 Fig. 13 Interconnection with a modular Metrohm IC System ........18 Fig. 14 Interconnection with a Metrohm 746 VA Trace Analyzer ......18 Fig. 15 Interconnection with 757 VA Computrace........... 19 Fig.

  • Page 7: Introduction

    Metrohm IC system instruments or voltammetric determina- tions with the Metrohm 746 Trace Analyzer or 757 VA Com- putrace . The sample rack provided may hold up to 36 vials of 2.5 or 11 mL volume respectively.

  • Page 8: Parts And Controls

    1.2 Parts and controls Metrohm Fig. 1 Side view Safety note: Never operate the instrument without splash protection and plug cover being mounted. The plug cover prevents any contamination of the connectors, caused by spilled solvents or chemicals. 813 Compact Autosampler...
  • Page 9 Tubing cartridge 6.2755.000 Sample rack 6.2041.7500 For 6.1826.0X0 pump tubing 6.1826.0X0 Pump drive PP sample tube 6.2743.050 Roller head with contact rollers (can be sealed with 6.2743.060 PE caps) Contact pressure lever Needle guide For adjusting the contact pressure 813 Compact Autosampler...

  • Page 10: Rear View

    1.3 Rear view 1.3 Rear view Type 1.813. Keyboard Made by Metrohm Herisau Switzerland Fig. 2 Rear view Mounting screws for Sample rack 6.2041.750 splash protection Tubing cartridge PP sample tubes 6.2743.050 6.2755.000 (can be sealed with 6.2743.060 PE For 6.1826.0X0 pump tubing...

  • Page 11: The Keyboard

    813 Compact A utosampler • The <STOP> key terminates a sample series or resets (if pressed twice) the 813 Compact Autosampler (RESET). • The <HOLD> key interrupts the course of a sample series and establishes the 'HOLD' state.

  • Page 12: Installation

    2 Installation 2.1 Setting up the instrument 2.1.1 Packaging The 813 Compact Autosampler is supplied together with the separately packed accessories in special packagings containing shock-absorbing foam linings designed to provide excellent pro- tection. The actual instrument is packed in an evacuated polyeth- ylene bag to prevent the ingress of dust.

  • Page 13: Mains Connection

    2.2.1 Setting the mains voltage Before switching on the 813 Compact Autosampler for the first time, check that the mains voltage set on the instrument (see Fig. 4) matches the local mains voltage. If not, reset the mains voltage...

  • Page 14: Fuses

    One of the two fuses 0.5 A/slow-blow for 100…120 V or 0.25 21 of the A/slow-blow for 220…240 V is installed in fuse holder 813 Compact Autosampler as standard Ensure that the instrument is never put into operation with fuses of another type, otherwise there is danger of fire! For checking or changing fuses, proceed as described in section 2.2.2.

  • Page 15: Switching The Instrument On/Off

    2 Installation 2.2.4 Switching the instrument on/off The 813 Compact Autosampler is switched on and off using the 23 . mains switch 2.3 Attaching the accessories For attaching the accessories at the 813 Compact Autosampler, proceed in the order described below.

  • Page 16: Installing The Needle

    Fig. 6 Needle installation If you are using the 6.1835.020 or 6.1835.030 PEEK tube as needle, the sample tubes must not be sealed with caps because they cannot be pierced by the PEEK tube and this could damage the tube! 813 Compact Autosampler...

  • Page 17: Installing The Splash Protection

    2 Installation 2.3.4 Installing the splash protection To avoid any danger of injury by the needle, the 6.2751.070 splash protection must always be installed when operating the 813 Compact Autosampler! Remove holding screws 16 and the washer mounted on the Remove the holding screws 9 at tower 18 using the 6.2621.100 Allen key.

  • Page 18: Placing The Sample Rack

    Fig. 8 Sample rack placing 2.3.6 Adjusting the sample rack If a new sample rack is placed on the 813 Compact Autosampler for the first time, it must be adjusted. Make sure you have mounted a steel needle or a PEEK needle before. Proceed as fol-...
  • Page 19 2 is exactly in the middle of the hand until the lowered needle lower hole at the rack position 1. 33 . • Tighten the adjusting screws Move to rest position Press <STOP> twice to move the sample rack to the initial position. 813 Compact Autosampler...

  • Page 20: Tubing Connections

    In such cases, rinse with different pump tubing or a different pump. For transferring the sample from the 813 Compact Autosampler to an injection valve the following tubing connections must be made: Install pump tubing •...

  • Page 21: Tubing Connection To Metrohm 761 / 790 Ic-Systems

    Coupling 6.2744.030 Tubing cartridge 6.2755.000 Stopper (black) Contact pressure lever 2.3.8 Tubing connection to Metrohm 761 / 790 IC–Systems Connection pump tubing – injection valve • Use a 6.2744.010 PEEK compression fitting and a 6.2744.030 17 to the coupling to tighten the 6.1831.060 PEEK capillary pump tubing •...

  • Page 22: Tubing Connection To A Metrohm 747 Va Stand

    Fig. 11 Measuring head of the747 VA Stand 2.3.10 Tubing connection to a Metrohm Computrace 757 Install tubing connections 813 Compact Autosampler – 757 VA Computrace as shown above for the 747 VA Stand. See the 757 VA Computrace user manual for more details.

  • Page 23: Instrument Connections

    Metrohm cables. Otherwise a safe signal transmission may not be guaranteed. Before an external device is connected to remote connection 22 the 813 Compact Autosampler must always be switched off 26 ! using mains switch 2.4.2 Interconnection with Metrohm IC systems...

  • Page 24: Interconnection With A Metrohm 746 Va Trace Analyzer

    Fig. 13 Interconnection with a modular Metrohm IC System 2.4.3 Interconnection with a Metrohm 746 VA Trace Analyzer The 813 Compact Autosampler is connected to a Metrohm 746 VA Trace Analyzer with 747 VA Stand using the 25 pin 6.2141.020 Remote cable.

  • Page 25: Interconnection With A Metrohm 757 Va Computrace

    2 Installation 2.4.4 Interconnection with a Metrohm 757 VA Computrace You need a 6.2141.150 Remote cable to interconnect a 813 Compact Autosampler with a Metrohm VA Computrace 757, see below. 6.2141.080 cable 6.2141.150 cable Fig. 15 Interconnection with 757 VA Computrace 2.4.5 Interconnection with other instruments...

  • Page 26: Operation

    Depending on the size of the sample tubes and the desired lift height for the suction of the sample solution the work position for the needle has to be set before starting a sample series. Read the following pages to learn how to configure the 813 Com- pact Autosampler. 813 Compact Autosampler...

  • Page 27: Configuration

    Triple injection of each sample, no air gap, the needle re- mains in the sample during the determination. Before running the 813 Compact Autosampler for the first time, the work position of the lift has to be set correctly. The work position defines the position of the suction needle while aspirat- ing the sample.
  • Page 28 RESET <STOP>. When the green LED is illuminated the 813 STOP Compact Autosampler is in the basic state and is ready to process a series of samples. lights up See next page for a figure of the whole configuration process.

  • Page 29: Course Of Configuration

    3. Press <HOLD> again, to select method 1. The red LED blinks slowly. To select method 2 press <HOLD> again. The red LED blinks double times. To select method 3 or 4 press <HOLD> again. The red LED will display the selected method by the blinking frequency. 813 Compact Autosampler...

  • Page 30: Ram Initialization

    5. The lift position set can be accepted with the <START> key. 6. Reestablish basic state of the 813 Compact Autosampler by pressing the <STOP> key. 3.3 RAM initialization...

  • Page 31: The Methods

    3 Operation 3.4 The methods All methods of the 813 Compact Autosampler make use of the built-in peristaltic pump to aspirate the sample and to fill the sample loop of the Ion chromatograph connected. The pump du- ration is controlled by the time program of the Ion chromato- graph's PC software by sending Remote signals to the Autosam- pler.
  • Page 32 10. Await first Remote signal of the IC again. 11. On receiving second Remote signal, switch on the peristal- tic pump. Sample is transferred. 12. Await third Remote signal. The instrument starts the third determination. 13. Peristaltic pump is switched off after 12 s. 813 Compact Autosampler...

  • Page 33: The Metrohm Ic Control Software

    3 Operation 3.5 The Metrohm IC control software To use the 813 Compact Autosampler with a 761 Compact IC or a 790 Personal IC one has to create a time program. First of all the IC has to send a Remote signal (Remote line 3) to synchronize the command sequence (first Remote signal) of the 813 Compact Autosampler.

  • Page 34: Modular Metrohm Ic System 732/733

    3.6 Modular Metrohm IC System 732/733 The 813 Compact Autosampler can be controlled directly by a Metrohm 732 IC Detector or by a PC control software, such as the Metrohm IC Net 2.0 using the remote control lines of the 732 IC Detector.

  • Page 35: Conditions To Be Met

    For the correct intercommunication of the 813 Compact Auto- sampler and the 746 VA Trace Analyzer the following conditions must be met: • Method 2 of the 813 Compact Autosampler has to be se- lected. • Always start the method of the 813 Compact Autosampler first, then you can start the 746 VA Trace Analyzer.

  • Page 36: Appendix

    Turning of a rack could not be carried out because the 10* raise lift first lift was below the rest (shift) position. Load or resistance too large to turn the rack. 12* changer overload 813 Compact Autosampler...

  • Page 37: Sequences

    The available Autosampler methods are described briefly in sec- tion 3.4 The following listings explain the sequences in detail. Method 1 Single determination with air gap after each run, needle lifted after sample transfer. 813 Compact Autosampler 813.0010 ¬ Program version parameters method 813_1 ¬...
  • Page 38 4.2 Sequences Method 2 Single determination, no air gap, needle remains in sample after sample transfer. 813 Compact Autosampler 813.0010 ¬ Program version parameters method 813_2 ¬ Method name number of samples: ¬ Number of samples unlimited >start sequence 1 SAMPLE: ¬...
  • Page 39 4 Appendix Method 3 Double determination of each sample, no air gap, needle remains in sample after sample transfer. 813 Compact Autosampler 813.0010 ¬ Program version parameters method 813_3 ¬ Method name number of samples: ¬ Number of samples unlimited >start sequence...
  • Page 40 4.2 Sequences Method 4 Triple determination of each sample, no air gap, needle remains in sample after sample transfer. 813 Compact Autosampler 813.0010 ¬ Program version parameters method 813_4 ¬ Method name number of samples: ¬ Number of samples unlimited >start sequence...

  • Page 41: Technical Specifications

    Output 3 Output 0 Output 1 Output 8 Output 12 Output 9 Output 13 Output 10 Input 0 Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 0 Vo lt Output 11 813 Compact Autosampler...
  • Page 42 EN55011 (class B), EN55022 (class B), EN50081-1 01.92 Immunity to interference Standards met: IEC801-2/IEC1000-4-2 (class 4), IEC801-3/ IEC1000-4-3 (class 2), IEC801-4/IEC1000-4-4 (class 3), IEC801-5/IEC1000-4-5 (class 2/3), IEC801-6/IEC1000-4-6 (class 2), EN55011 (class B), EN55022 (class B), EN50081-1/2 01.92, EN50082-1 01.92, EN61000-3, EN61316-1 03.97 813 Compact Autosampler...

  • Page 43: Maintenance And Servicing

    4.4.1 Maintenance by Metrohm service is best done as part of an annual service performed by specialists from the Metrohm company. If work is frequently performed with caustic and corrosive chemicals, it may be necessary to shorten the interval between servicing.
  • Page 44 11 from holding clamp 14 by press- 15 and remove from mounting ing down snap-action lever 10 at the 813 Compact Autosampler (see Fig. 1). • Remove old pump tubing. Insert new pump tubing • Insert the new pump tubing 8 (6.1826.040) in the tubing...

  • Page 45: Warranty And Conformity

    (e.g. conductive protective bag). (Exception: assemblies with built-in voltage source belong in a non-conductive protective packaging). No warranty responsibility whatsoever will be accepted by Metrohm for damage which arises as a result of non-compliance with these instructions. 813 Compact Autosampler...

  • Page 46: Certificate Of Conformity And System Validation

    The features of the system software are documented in the in- struction manual. Metrohm Ltd. is holder of the SQS-certificate of the quality system ISO 9001 for quality assurance in design/development, production, installation and servicing. Herisau, March 5, 2001 Dr.
  • Page 47 Ionenanalytik • Analyse des ions • Ion analysis • Análisis iónico 813 Compact Autosampler EU Declaration of conformity The METROHM AG company, Herisau, Switzerland hereby certifies that the in-strument: 813 Compact Autosampler meets the requirements of EC Directives 89/336/EWG and 73/23/EWG.

  • Page 48: Standard Equipment

    Type CEE (7), VII (D…) ......6.2122.040 Type CEE (22), V Type NEMA 5-15 (USA…)...... 6.2122.070 6.2141.130 Connection cable (Remote) Connection cable 813 Compact Autosampler – Compact IC 761, Personal IC 790 or 732 IC Detector 6.2142.110 Keyboard for 813 Compact Autosampler "...
  • Page 49 Connection between 6.2744.010 PEEK com- pression fitting and 6.1826.0X0 pump tubing set of 4 6.2751.070 Splash protection Must be installed at the tower of the 813 Compact Autosampler. 6.2752.010 Plug cover Must be installed at the 813 Compact Autosampler. 6.2755.000...
  • Page 50 4.6 Standard equipment 2.813.0020 Compact Autosampler (for VA applications) Quant. Order No. Description 6.1826.020 Pump tubing  made of PVC (Tygon ); with 2 firmly attached black-black stoppers; i.d. = 0.76 mm, e.d. = 2.27 mm 6.1831.050 PEEK Capillary Length = 40 cm 1.59...
  • Page 51 Connection between 6.2744.010 PEEK com- pression fitting and 6.1826.0X0 pump tubing set of 4 6.2751.070 Splash protection Must be installed at the tower of the 813 Compact Autosampler. 6.2752.010 Plug cover Must be installed at the 813 Compact Autosampler. 6.2755.000...

  • Page 52: Optional Accessories

    Needle holder (1/16") For steel needle 6.2624.000 and PEEK needle 6.1835.000 6.2743.040 PP Sample tubes (2,5 mL) For sample rack 6.2041.750 set of 2000 6.2743.047 PP Sample tube (2,5 mL) For sample rack 6.2041.750 set of 200 813 Compact Autosampler...
  • Page 53 6.2125.120 Adaptor for remote connection with 5 connections for remote cables 6.2141.150 Connection cable (Remote) Connection cable 813 Compact Autosampler – 757 Computrace/ 731 Relay Box/Dosimat 6.1826.020 Pump tubing made of PVC (Tygon®); with two firmly attached blue-blue stoppers;i.d. = 1.6 mm, e.d. = 2.27 mm.

  • Page 54: Index

    Figure....... 3 Installing Coupling Mounting screws Splash protection... 11 Figure......15 Figure....... 4 Installation ...... 14 Installing the pump tubing 15 Needle Ordering designation43, 45 Instructions for Use Figure......3, 10 Remove......15 8.813.1003 ..... 43, 45 813 Compact Autosampler...
  • Page 55 Work position ....21, 24 Technical specifications. 35 Install tubing cartridge ... 14 Tubing material ....35 working position....22 Software Type ....... 35 IC Chromatograph ..27 Pump drive Splash protection Figure ....... 3 Figure ..... 3, 4, 11 813 Compact Autosampler...
