- Page 1 Model:SG60 Robot Vacuum Cleaner...
-
Page 2: Table Of Contents
Table of Contents Safety Warnings ................................ Introduction .................................. Installation and APP Connection ........................Operation Instructions ............................Maintenance ................................Malfunctions and Troubleshooting ........................................................................................................................................................................ -
Page 3: Safety Warnings
Safety Warnings Application Restrictions This machine is used for indoor cleaning only. Do not use the machine outdoors (such as open balcony), on non-floors (such as sofa) or in • commercial or industrial places. • Do not use the machine in the place of cliff without protective rails (such as duplex floors, open balcony, furniture top). •... - Page 4 Safety Warnings Battery and Charging Do not use the battery, charging base or charger produced by any third parties. • • Do not disassemble, repair or modify the battery or charging base without authorization. • Do not keep the charging base close to heat sources (such as radiator). •...
-
Page 5: Introduction
Introduction Packing List Machine Charging Base Dustbin Side Brush HEPA Filter + Filter Sponge Adapter Remote Control Magnetic Strip Cleaning Brush... - Page 6 Introduction Machine Recharge WIFI Indicator Short Press to Recharge Light OFF: Offline Light Flash: Connecting Light ON: Online Power/Clean/Pause Short press to start Clean/Pause Press and hold for 3 seconds to System Reset Power ON/OFF Insert a pin to trigger the switch, the machine will shut off to reset the system.
- Page 7 Introduction Sensor and Structure Edge Sensor Charging Contacts Button Omni Wheel Side Brush Bumper Battery Lid Driving Wheel Rolling Brush Infrared Bumper Sensor Dustbin Infrared receiving sensor...
- Page 8 Introduction Dustbin Accessories Charging Base Power Indicator HEPA Filter Lid HEPA Filter Signal Transmission Filter Sponge Primary Filter AC IN Charging contact poles Dustbin Button...
- Page 9 Introduction Remote Control Auto Clean Recharge Direction Control Start/Pause Designated Clean Edge Clean Water Volume Suction Force (*Water tank is not included in packing list. The button is invalid if water tank is not equipped.)
-
Page 10: Installation And App Connection
Installation and APP Connection Notices Please sort out the wires, debris and fragile, Avoid personal injury or property damage caused unstable, valuable and potentially dangerous by entanglement, jamming, dragging, or bumping objects on the ground before starting the device. of equipment. Do not clean the liquid. - Page 11 Installation and APP Connection 3. Connect the adapter to the charging base and arrange the 1. Remove the protective strips. power cable properly. 4. Place the charging base in proper position and power on for charging. 2. Install the side brushes. Press left brush (L) and the right brush (R) respectively into corresponding holes until the "click"...
- Page 12 Installation and APP Connection 5. Do not move the charging base arbitrarily and keep it asway 6. Power-On and Charging from direct sunlight Press and hold to power on. When the indicator is illuminated, place the machine to the base for charging. The voice prompt of "Start Charging"...
- Page 13 Installation and APP Connection 1.Activate the WIFI and Bluetooth in the phone. 4.When the power is on, press and hold “Power” and “Recharging” for more than 3 seconds till the WIFI indicator starts to flash. 2.Search for "Smart Life” in App Store/Scan QR code to search and download “Smart Life”...
- Page 14 Installation and APP Connection 5.Enter “Smart Life”, click “Add Device”, then select + in the 7.Enter WIFI password for network configuration upper right corner to add device. 8.Wait for automatic connection. 6.Search for Sweeping Robot, then click “Add”. 9.Click on “Finish” in upper right corner to enter the operation interface.
-
Page 15: Operation Instructions
Operation Instructions Charging Power ON/OFF Auto Mode: The machine will automatically return to the charging Press and hold for 3 seconds till the indicator is illuminated, base for charging after cleaning. which means the machine has been powered on. Press and hold Manual Mode: In the PAUSE state, short press to start the for 3 seconds in standby mode, the indicator is OFF, which... - Page 16 Operation Instructions Designated Clean Auto Clean In the default cleaning mode, the machine will set the scanning Press on the remote control, the machine will set the self-cen- path to clean all the ground in an orderly and efficient manner. The tered path to clean a circular area within a diameter of 1.2m.
- Page 17 Operation Instructions Edge Cleaning Appoitment Cleaning To clean the edges indoors, the machine will move along the You can set appointment cleaning time on the APP and the edge of fixed objects (such as walls) and return to the charging machine will automatically start cleaning at the specified time and base after cleaning.
-
Page 18: Maintenance
Maintenance It’s recommended to clean the rolling brush every 1~2 weeks. Side brush (to be cleaned every week) 1. Turn the machine over and press the buckle to remove the brush lid. 1. Turn the machine over and pull out the side brush vertically. 2. - Page 19 Maintenance Dustbin and Filter Clean the dustbin (to be cleaned every 3~5 days) (to be cleaned every 1~2 weeks) 1. Press and hold the button to pull out the dustbin. 1. Clean the filter: Remove the filter sponge and HEPA filter. Gently tap the HEPA filter to remove the dust.
- Page 20 Maintenance Clean the infrared bumper sensor Clean the charging contacts (to be cleaned every month) (to be cleaned every month) Clean the edge sensor (to be cleaned every month)
- Page 21 Maintenance Battery Clean the signal transmitting area (to be cleaned every month) The machine is equipped with high-performance rechargeable • lithium-ion battery. For the sake of battery performance, please keep the machine fully charged in daily maintenance. If the machine will not be used for a long time, please power it off •...
-
Page 22: Malfunctions And Troubleshooting
Malfunctions and Troubleshooting Descriptions Machine cannot be switched on • The battery is low, please place the machine to the spring contact of the charging base and the machine will automatically power on. Machine cannot be switched on. • Ambient temperature is less than 0 °C or more than 40 °C, please use the machine in the 0℃~ 40℃ environment. - Page 23 Malfunctions and Troubleshooting Voice Prompt Solutions Insert dustbin The voice prompt will be heard when the dustbin is removed. Please insert the dustbin. Please pick up the machine; if the machine is not fully contact the ground, please move the Put the vacuum on the floor before starting machine to a flat place and start again.
- Page 24 Customer Service Please contact us if you need any help as following: - Technical Support - Package is NOT in perfect condition - Parts missing - Any other quality issues Email: service@Lubluelu.com Website: lubluelu.com Deutschland Email: Tiger-Zhou@web.de...
