Iiyama Pro Lite H511S Specifications

ProLite H511S-2
The 20.1" ProLite H511S offers plenty of area to display every element of even the most space-hungry
applications. The PVA LCD technology provides a native resolution of 1600 x 1200 and a lateral viewing angle of
178°. The height of the display can be adjusted through 110mm and the screen itself rotates for a landscape or
portrait viewing mode. Flexible inputs (1 x VGA & 1 x DVI-D with cables included) reinforces the position of the
ProLite H511S as the professional 20.1" LCD of choice. Available in both ivory and black.
Panel
Diagonal
Display area h x w
Response time
Contrast ratio
Brightness
Viewing zone
Display colour
Pixel pitch h x v
Native resolution
Horizontal sync
Vertical sync
Bandwidth
Analog input connector
Digital input connector
Output connector
Synchronization
Plug & Play
Speakers
Included accessories
Apple - Mac
Controls
User controls
Driver
Ergonomics
Safety
Power supply
Power Supply Unit
Power usage
Power management
Anti-theft-device
VESA mounting
Height adjustment
Rotation (pivot function)
Swivel Stand
Tilt angle
Dimensions w x h x d
Weight
Aspect ratio
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-13406-2 in
connection with pixel defects.
www.iiyama.com
PVA
20.1"
306 x 408 mm
8 ms
900 : 1 typical
300 cd/m² typical
horizontal/vertical: 178°/178°; right/left: 89°/89°; up/down: 89/89°
16.7 million
0.255 x 0.255 mm
1600 x 1200 (1.9 megapixel)
24 - 80 KHz
55 - 85 Hz
162 MHz
D-Sub
DVI-D
headphone socket
Composite, Separate, Sync On Green
DDC 2B™
2 x 2 W (Stereo)
power Cable, D-Sub Cable, audio cable, user manual, Pivot® & Liquid view software
All iiyama monitors are compatible with Apple-Macintosh computers.
OSD menu - 6 languages (D, GB, F, SV, Jp, I), 6 control buttons (Power, Auto-Setup, brightness, contrast,
menu, signal selection)
brightness, contrast, colour temperature, horizontal and vertical position, clock, phase, sharpness,
regulation of basic colours, sRGB, gamma correction, Eco mode, signal input, OSD position, OSD Timer,
OSD lock out, zoom (full screen, 1 : 1, max. preservation of the original ratio of dimensions), reset
Windows 95 / 98 / 2000 / ME / XP
TCO'03 (ProLite H511S-B: TCO'99), MPR III (prEN50279), ISO 13406-2
CE, TÜV GS, FCC-B, UL/C-UL, VCCI-B, CCC
AC 100 - 240 V, 50 / 60 Hz
internal
max. 55 W in normal use; max. 2 W in Power management mode
VESA DPMS, ENERGY STAR®
Kensington-lock™ prepared
100 mm
110 mm
90°
70°; 35° left; 35° right
35° up; 5° down
446 x 391.5 (501.5) x 242 mm
10 kg
4 : 3
