USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the monitor.
Please keep this manual in a safe place for
your future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProLite XUB2792UHSU and is the answer not in the manual?

Questions and answers

Related Manuals for Iiyama ProLite XUB2792UHSU

Summary of Contents for Iiyama ProLite XUB2792UHSU

  • Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
  • Page 3 Congratulations! This product is TCO Certified for Sustainable IT TCO Certified is an international third party sustainability certification for IT products. TCO Certified ensures that the manufacture, use and recycling of IT products reflect environmental, social and economic responsibility. Every TCO Certified product model is verified by an accredited independent test laboratory.
  • Page 4 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL2792UH We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 INSTALLATION ................5 FITTING AND REMOVAL OF BASE ..........6 CONTROLS AND CONNECTORS..........7 CONNECTING YOUR MONITOR ..........8 DISCONNECTING YOUR MONITOR ..........9...

  • Page 6: For Your Safety

    DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage.
  • Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.

  • Page 8: Special Notes On Lcd Monitors

     If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center.  For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it.

  • Page 9: Before You Operate The Monitor

    CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.  Power Cable* ...

  • Page 10: Installation

    INSTALLATION WARNING  Before installation, make sure the wall, ceiling or desktop arm is strong enough to hold the necessary weight of the display and the mount. < WALL MOUNTING > WARNING  When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screws (4pcs) with washer which “L” length is 7mm to fasten the monitor.

  • Page 11: Fitting And Removal Of Base

    FITTING AND REMOVAL OF BASE  Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped.  Do not give a strong impact to the monitor. It may cause damage. ...

  • Page 12: Controls And Connectors

    CONTROLS AND CONNECTORS <Front> <Back> Power Indicator NOTE Blue: Normal operation Orange: Power Management Power Switch ( ) Menu / Select Button (ENTER) Scroll Up / Volume Button ( ) * Scroll Down / ECO Button ( ) * Exit / i-Style Color Button (EXIT) * Input Select Button (INPUT) * Speakers USB Downstream (Battery Charger) Connector ( 5V, 1.5A) USB Downstream Connector ( 5V, 900mA) USB Upstream Connector ( Keyhole for Security Lock You can fasten a security lock and cable to prevent the monitor from being removed NOTE without your permission.

  • Page 13: Connecting Your Monitor

    An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office.

  • Page 14: Disconnecting Your Monitor

    DISCONNECTING YOUR MONITOR Ensure that both the computer and the monitor are switched off. Disconnect the power source first and then the Power Cable from the monitor. Disconnect the audio cable from the computer and the monitor. Disconnect the USB cable from the computer and the monitor. Disconnect the signal cable from the computer and the monitor. COMPUTER SETTING  Signal Timing Change to the desired signal timing listed on page 24: COMPLIANT TIMING.

  • Page 15: Operating The Monitor

    OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 24. You are also able to adjust the picture by following the button operation shown below.

  • Page 16: Adjustment Menu Contents

    ADJUSTMENT MENU CONTENTS Picture Adjust * ProLite XUB2792UHSU PICTURE ADJUST BRIGHTNESS COLOR SETTINGS CONTRAST LANGUAGE RECALL MODE1 MISCELLANEOUS BLUE LIGHT REDUCER MODE1 INPUT SELECT ADV. CONTRAST AUDIO SETTINGS OVERDRIVE Adjustment Item Problem / Option Button to Press Too dark 2,3,4...
  • Page 17 Color Settings ProLite XUB2792UHSU PICTURE ADJUST COLOR TEMPERATURE COLOR SETTINGS 9300K 7500K 6500K USER PRESET LANGUAGE RECALL GREEN MISCELLANEOUS BLUE INPUT SELECT AUDIO SETTINGS I-STYLE COLOR CINEMA Adjustment Item Problem / Option Button to Press 9300K Cool color Color Temperature *...
  • Page 18 ProLite XUB2792UHSU PICTURE ADJUST ON SCREEN DISPLAY SETTINGS COLOR SETTINGS OSD HORIZONTAL POSITION OSD VERTICAL POSITION LANGUAGE RECALL OSD TIME MISCELLANEOUS INPUT SELECT AUDIO SETTINGS Adjustment Item Problem / Option Button to Press OSD is too left OSD Horizontal Position...
  • Page 19 Recall ProLite XUB2792UHSU PICTURE ADJUST RECALL ALL? COLOR SETTINGS RECALL LANGUAGE RECALL MISCELLANEOUS INPUT SELECT AUDIO SETTINGS Adjustment Item Problem / Option Button to Press Factory-preset data is restored. Recall 14 OPERATING THE MONITOR...
  • Page 20 Video Mode Adjust Aspect * Expansion display of Aspect Dot By Dot Display a picture dot by dot. iiyama Logo is displayed when the monitor is turned on. Opening Logo iiyama Logo is not displayed when the monitor is turned on.
  • Page 21 Miscellaneous ProLite XUB2792UHSU PICTURE ADJUST MISCELLANEOUS COLOR SETTINGS SHARP AND SOFT VIDEO MODE ADJUST FULL OPENING LOGO LANGUAGE RECALL DISPLAY INFORMATION MISCELLANEOUS PIP/PBP PIP POSITION TOP-LEFT INPUT SELECT AUDIO SETTINGS PIP SIZE MIDDLE Adjustment Item Problem / Option Button to Press PIP/PBP mode is turned off.
  • Page 22 Input Select ProLite XUB2792UHSU Direct PICTURE ADJUST INPUT SOURCE COLOR SETTINGS AUTO MANUAL MANUAL LANGUAGE HDMI RECALL SUB SOURCE HDMI MISCELLANEOUS DISPLAYPORT MODE SELECT INPUT SELECT AUDIO SETTINGS Adjustment Item Problem / Option Button to Press Search for an available input source and select Auto automatically.
  • Page 23 Audio Settings ProLite XUB2792UHSU PICTURE ADJUST VOLUME COLOR SETTINGS OPTIONS LANGUAGE MUTE AUDIO RECALL AUDIO INPUT HDMI LINE-IN MISCELLANEOUS INPUT SELECT AUDIO SETTINGS Adjustment Item Problem / Option Button to Press Too soft Volume Direct Too loud Turn off the sound temporarily. Mute Audio Return the sound volume to the previous level.
  • Page 24 Lock Mode  <OSD Menu> The OSD can be locked to avoid an accidental setting change. 1. Make sure the monitor is turned ON. 2. The OSD lock will be activated by pressing the front ENTER Button for about 10 seconds. If you try to access the OSD by pressing any of the buttons, a message "OSD Locked"...

  • Page 25: Power Management Feature

    POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of ENERGY ® STAR and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer.

  • Page 26: Trouble Shooting

    MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...

  • Page 27: Recycling Information

    A strange noise is The Audio Cable is properly connected. heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 22 TROUBLE SHOOTING / RECYCLING INFORMATION...

  • Page 28: Appendix

    APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS Size Category 27" Panel technology IPS Panel Technology Size Diagonal: 27" (68.4cm) Pixel pitch 0.16mm H × 0.16mm V Brightness 300cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left : 89 degrees each, Up / Down : 89 degrees each (Typical) Response time 4ms (Gray to Gray) Display Colors Approx. 1.07B DVI: Horizontal: 31.0-90.0kHz, Vertical: 55-75Hz Sync Frequency HDMI: Horizontal: 31.0-160.0kHz, Vertical: 55-75Hz DisplayPort: Horizontal: 31.0-160.0kHz, Vertical: 50-75Hz...

  • Page 29: Dimensions

    DIMENSIONS 613.5mm / 24.2” 54.0mm / 2.1” 603.5mm / 23.8” 300.0mm / 11.8” ( ) : Maximum adjustment range COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 640 × 480 31.469kHz 59.940Hz 25.175MHz 800 × 600 37.879kHz 60.317Hz 40.000MHz 1024 × 768 48.363kHz 60.004Hz 65.000MHz 1280 ×...
