Introduction - IOGear MiniView Micro GCS62 Installation Manual

1. VGA port for the console monitor
2. PS/2 port for the console keyboard
3. PS/2 port for the console mouse
4. VGA connector goes to the computer
5. PS/2 keyboard connector goes to the computer
6. PS/2 mouse connector goes to the computer
7. Selected LEDs
1
7
2 3
6

Introduction

5
4
6
5
4
6
