Yuria-Pharm ULAIZER HOME CN-02 MY User Manual page 15

EN 26
8. TROUBLESHOOTING
Problem/Question Possible Cause/Remedy
The nebulizer bottle pro- 1. Too much or too little medication in the nebulizer bottle.
duces little or no aerosol. Minimum: 2 ml, maximum: 8 ml, recommended: 5 ml
2. Check that the nozzles are not blocked. If necessary, clean the nozzle
(e.g. by rinsing). Use the nebulizer bottle again.
Caution: Only poke implements through the fine holes from the under-
side of the nozzle.
3. The nebulizer bottle is not held in an upright position.
4. The medicine solution is unsuitable for nebulizing (e.g. too thick).
The medicine solution should be specified by the doctor.
Output is too low. Air tube kinked, filter blocked, too much inhalation solution.
Consult your doctor.
Which medicines are
suitable for inhalation? Essentially all medicines that are suitable and approved for device-based
inhalation can be inhaled.
Some inhalation solution This is normal and occurs for technical reasons. Stop inhalation if you
remains in the nebulizer hear a notable difference in the noise of the nebulizer bottle.
bottle.
What special steps should 1. In babies, the mask should cover the mouth and nose to guarantee
be taken for babies and effective inhalation.
children? 2. In children, the mask should also cover the mouth and nose. Nebuliza-
tion next to a sleeping person is not suitable because insufficient medi-
cine reaches the lungs.
Note: Children should only use the device with help and under supervi-
sion of an adult. Never leave a child alone with the nebulizer.
Inhalation with the mask This is for technical reasons. Less medicine is inhaled per breath through
takes longer. the mask holes than using the mouthpiece. The aerosol is mixed with
ambient air through the holes in the mask.
Why do I need to replace There are two reasons for this:
the nebulizer at regular
1. To guarantee a therapeutically effective particle spectrum, the nozzle
intervals? holes should not exceed a certain diameter. Due to the thermal and me-
chanical stresses, the plastic is subjected to a certain amount of wear.
The nebulizer bottle is particularly sensitive. This can also cause changes
to the droplet composition of the aerosol, which has a direct effect on the
effectiveness of the treatment.
2. You are also recommended to replace the nebulizer bottle on a regular
basis for hygiene reasons.
Does each person need This is absolutely necessary for hygiene reasons.
their own nebulizer bottle?
USER'S MANUAL
9. SPECIFICATIONS
Power
Power Consumption
Medication Capacity
Particle Size
MMAD
Sound Level
Average Nebulization Rate
Compressor Pressure Range
Operating Pressure Range
Liter Flow Range
Operating Temperature Range
Operating Humidity Range
Storage Temperature Range
Storage Humidity Range
Dimension (L x W x H)
Weight
Standard Accessories
Optional Accessories
Consider
instructions for use
Consider
instructions for use
Vega Technologies Inc.
11F-13, 100 Chang Chun Road,
Taipei, Taiwan
ISO9001 & ISO13485 Certified
This device complies with EU EMC standard EN60601-1-2
27
AC 230V 50 Hz
180 VA
5ml
0.5 to 10 um
5 um
around 60 dB
0.2 ml/min.
25 to 42 psi (0.17 to 0.29 Mpa)
8 to 13 psi (0.056 to 0.09 Mpa)
5.0 ~ 8.0 Lpm
10 to 40 °C (50 to 104 °F)
10 to 95% RH
-21 to 70 °C (-13 to 158 °F)
10 to 95 % RH
200 × 150 × 92 mm
1.324 kg
Nebulizer, Air Tube, Mouth piece, adult mask, 5
filters. It can be equipped with a children's mask
Baby pacifier inhalator w/connector, child
mask, medicine saving device
Application part of
Attention!
Type BF
Disposal for separate
collection
Biolife, Ltd.
203, Mesogion Av. P.C. 115 25 Athens,
Greece.(VAT NO: EL 999725460)
EN
