Vcci - Vehicle Communication And Check Interface; Software Overview - Humzor NEXZDAS PRO Manual

Operating Temp.
Temperature
Storage Temp.
Software
Android 9.0
platform：
Interface style Google
Language Support multi-languages
Standard Android soft keyboard (support third-party handwriting input method/support external hard
Input
keyboard)
Audio: MP3,MP2, AMR,AWB,APE,M4A, MIDI, OGG,WAV,FLAC,3GP (Need License: AAC, WMA)
Video: MPEG4-SP, H.264/AVC,H.263,3GP,3G2,MP4,MKV,AVI,1080P
PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11897-2,
ISO-11897-3, SAE-J2819 (TP20),TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo
Protocols Byte, SAE-J2809 (Honda Diagnose-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP,
Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708,
SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
2.2 VCCI – Vehicle Communication and Check Interface
2.2.1 Functional Description

2.3 Software Overview

2.3.1 Overview
NEXZDAS is a tool-based APP which focus on car diagnosis, reset, key programming and other
maintenance functions. It is connected to the vehicle through a specific Bluetooth (V5.0) device. The car
www.obdii365.com
0 to 50°C (32 to 122°F)
-20 to 60°C (-4 to 140°F)
Software specifications
Figure 2-4 HUMZOR VCCI Top View
9
