1. Application Buttons -
Locator and Navigation Buttons – Quickly boot to diagnose function or return android system home.
2.
3. Status Icons - Display system and communication signals.
NOTE
It is recommended to lock the screen when not in use to protect information in the system and conserve
the power.
Almost all operations on the tablet are controlled through the touchscreen. The touchscreen navigation is
menu driven allowing for quick access to test procedure, or data that you need, through a series of
questions and options. Detailed descriptions of the menu structures are found in the chapters for each
application.
3.1.1 Application Buttons
The table below briefly describes each of the applications in the NEXZDAS system.
Name
Car
Diagnostics
Heavy-duty
Diagnostics
Special
Function
IMMO Key
DTC Query
VIN Query
APP Store
Personal
www.obdii365.com
Figure 3-1 Application Menu
Diagnose and application functions selection.
Table 3-1 Applications
Button
Accesses the unit's car diagnostics functions.
Accesses the unit's Heavy-duty diagnostics functions.
Accesses special functions menu
Accesses Key programming and IMMO Reset menu
Accesses the DTC Query functions.
Accesses the VIN Query functions.
Accesses system software update menu.
Accesses saved consumer information and change data live
unit, upgrade NEXZDAS system application, logo in/out
system and switch/add product.
Description
