P/N 126631-01 Rev. H 01/2019
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 126631-02.
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also con-
tains information that will enable you to obtain replacement parts or accessory items when needed. Keep it
with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This wood burning fireplace complies with UL127
CAN/ULC-S610-M87 standard as a FACTORY BUILT
FIREPLACE.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to
ANSI Z21.60 or Z21.84 standards or for use with a vent-free gas log heater approved to ANSI Z21.11.2 standard .
An IHP hood must be installed when using a vent-free log heater (see Accessories, page 20).
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before
installation to determine the need to obtain a permit.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes.
This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace
system. Please read and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circumstances. Any modification or alteration of
the fireplace system, including but not limited to the fireplace, chimney components and accessories, may void the
warranty, listings and approvals of this system and could result in an unsafe and potentially dangerous
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS: INSTALL THIS FIREPLACE IN A SQUARE
AND PLUMB CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PFS
C
REPORT NO. 09-171
SAVE THIS BOOK
NOTE: DIAGRAMS AND ILLUSTRATIONS THROUGHOUT THE MANUAL ARE NOT TO SCALE.
INSTALLATION AND OPERATION INSTRUCTIONS
Merit Series Wood-Burning Fireplace
®
US
WRT2042WS
WRT2042WSI
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour
consultation ultérieure.
Ce foyer au bois est conforme aux UL 127 CAN/ULC-
S610-M87 norme comme une USINE CONSTRUITE
CHEMINÉE.
POUR LE CANADA: L'autorité compétente (comme
le service municipal du bâtiment, les pompiers,
etc.) doit être contacté avant l'installation afin de
déterminer la nécessité d'obtenir un permis.
MODELS
WCT2042WS
WCT2042WSI
P126631 01
installation.
Advertisement
Table of Contents
Related Manuals for IHP Superior Fireplaces Merit WRT2042WS
Summary of Contents for IHP Superior Fireplaces Merit WRT2042WS
- Page 1 ANSI Z21.60 or Z21.84 standards or for use with a vent-free gas log heater approved to ANSI Z21.11.2 standard . An IHP hood must be installed when using a vent-free log heater (see Accessories, page 20). FOR CANADA: The authority having jurisdiction POUR LE CANADA: L’autorité...
-
Page 2: Table Of Contents
Use only firelogs that have been hazard. evaluated for the application in fireplace and refer to • The IHP warranty will be voided by and IHP disclaims any respon- firelog warnings and caution markings on packaging sibility for the following actions. - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. CHARCOAL) CAN RESULT IN CARBON MONOXIDE SOME EXAMPLES OF CONDITIONS THAT COULD POISONING, WHICH MAY LEAD TO DEATH! CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning – Early signs of carbon •...
-
Page 4: Specifications
SPECIFICATIONS 1" (26 mm) AIRSPACE TO COMBUSTIBLE MATERIAL 0" (0 mm) GAS LINE TO TOP RIGHT SIDE KNOCK OUT SPACERS NO COMBUSTIBLE MATERIAL ON FACE " (210 mm) 7" COMBUSTIBLE (178 mm) WALL BOARD " (19 mm) GAS LINE AIR KIT AIR SPACE KNOCK OUT KNOCK OUT... -
Page 5: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION To determine safest and most efficient location for fireplace, you must take into consideration the following guidelines: 1. Location must allow for proper clearances (see Figures 1 and 2). 2. Consider a location where fireplace will not be affected by drafts, air conditioning ducts, windows or doors. - Page 6 FIREPLACE INSTALLATION Continued MANTELS WARNING: Hearth extension is to be installed A mantel may be installed if desired (see Figure 4). Woodwork such only as shown in Figure 3. as wood trims, mantels or any other combustible material projecting from front face must not be placed within 12" of fireplace opening (and within 9"...
-
Page 7: Venting Installation
Note: Electrical housing and cover plate have sharp edges. Wear See accessories, page 20 for Kit F2659. protective gloves. An IHP chimney system consists of 12", 18", 24", 36" and 48" snap- lock, double-wall pipe segments, planned for maximum adaptability to individual site requirements. Actual lengths gained after fitting overlaps must be taken into consideration (lineal gain) and are given in lineal gain chart (see Figure 8, page 8). - Page 8 VENTING INSTALLATION Continued ASSEMBLY AND INSTALLATION OF DOUBLE WALL CHIMNEY WARNING: The opening in collar around chimney SYSTEM at top of fireplace must not be obstructed. Never use Each double wall chimney section consists of a galvanized outer blown insulation to fill chimney enclosure pipe, a stainless steel inner flue pipe and a wire spacer.
- Page 9 VENTING INSTALLATION Continued Return Elbow Return Elbow Return Elbow Offset Offset Elbow Elbow 6' Max.(1.83 m) 6' Max.(1.83 m) Ceiling Return Support Pipe Elbow 6' Max.(1.83 m) 12S-8DM 6' Max.(1.83 m) Return Offset Offset Elbow Elbow Elbow Offset 6' Max.(1.83 m) 6' Max.(1.83 m) Elbow Figure 9 - Typical Offset Installation...
- Page 10 VENTING INSTALLATION Continued If area above is a living space, install OFFSET RISE CHIMNEY LENGTH firestop below framed hole. 48" 36" 24" 18" 12" " " ELBOW SET ONLY 9" " " 31" 15" " " " 20" " " "...
- Page 11 VENTING INSTALLATION Continued Storm Collar Installation (SC1) Minimum Measurements Place storm collar over pipe and slide down until it is snug against " open edge of flashing (see Figure 16). Use SC1 for all round termina- (48.3 cm) 30" tions. Apply waterproof caulk around perimeter of collar to provide 1"...
- Page 12 VENTING INSTALLATION Continued CHASE INSTALLATIONS (3.05 m) Level of Instructions for chase installations are included with chase style ter- Flue Gas Outlet mination chosen. In a multiple chase installation, be sure to provide adequate distance between terminations to prevent smoke spillage (3.05 m) from one termination to another.
-
Page 13: Optional Gas Line Installation
QUALIFIED SERVICE PERSON. creosote and ashes be a qualified chimney cleaner. Note: An IHP hood must be installed when using an unvented gas Creosote will ignite if heavily heated. log set (see Accessories on page 20). -
Page 14: Operation And Maintenance
This will provide sufficient combustion air and maintain safe WARNING: Risk of fire! Replace grate with IHP temperatures in firebox. model 107001-02 only. This grate has been designed to IMPORTANT: The glass must be allowed to warm slowly and evenly. -
Page 15: Replacement Parts
For further operating guidelines, instructions and warranty informa- tion, please refer to your homeowner's guide or contact your dealer. used with IHP Shroud Leg Spacer Kit (SLK) in accor- dance with instructions provided with the shroud. NOTICE: The firebox canopy (hood) must not be modified or replaced with a canopy that may be provided with the unvented decorative room heater. -
Page 16: Parts
PARTS WOOD BURNING FIREPLACE MODELS WRT2042WS, WRT2042WSI, WCT2042WS, WCT2042WSI MODEL CAT NO. WRT2042WS F0687 WRT2042WSI F0688 WCT2042WS F0689 WCT2042WSI F0690 SuperiorFireplaces.us.com 126631-01_H... - Page 17 This list contains replaceable parts used in your fireplace. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards.
-
Page 18: Accessories
PARTS Continued This list contains replaceable parts used in your fireplace. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not ap- proved by IHP. Use of non-approved parts can result in poor performance and safety hazards. - Page 19 ACCESSORIES Continued CAT NO. MODEL DESCRIPTION BI-FOLD GLASS DOORS F0975 42" - Standard Black Finish (Bungalow Only) BDB42 F0976 42" - Standard Brushed Brass Finish (Bungalow Only) BDB42B F0977 42" - Standard Platinum Finish (Bungalow Only) BDB42P DOUBLE WALL PIPE F0895 12-8DM 12"...
- Page 20 ACCESSORIES Continued ANTI-DRAFT SHIELD (Round Top Termination Only) F0927 ADS-8DM Anti-Draft Shield for Round Top Only MESH ROUND TOP TERMINATIONS F0916 RT-8DM Round Top with Mesh Screen F0888 RT-8HT Hi-Temp Round Top with Mesh Screen MESH ROUND TOP TERMINATIONS WITH SLIP SECTION F0917 RTT-8DM Round Top with Slip Section &...
-
Page 21: Draft Smoke Guidelines
Overfiring Damage - If the appliance or chimney connector glows, source of negative pressure. IHP accepts no liability for damages you are overfiring. Other symptoms may include: Cracking, warping resulting from negative pressures described here. - Page 22 APPENDIX A Continued Smoking – Causes And Troubleshooting Location Recommended To reduce the likelihood of smoking when opening the door, open Marginal Location the combustion air control or damper before opening the door. Wind Direction Your appliance has been designed and tested to provide smoke free Tree operation.
-
Page 23: Warranty
In order for any claim under this warranty to be valid, you must contact the IHP dealer/distributor from which you purchased the product. If you cannot locate the dealer/ distributor, then you must notify IHP in writing. IHP must be notified of the claimed defect in writing within 90 days of the date of failure. Notices should be directed to the IHP Warranty Department at 1769 East Lawrence Street;... - Page 24 SuperiorFireplaces.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Dealer name P126631 01 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
