INSTALLATION AND
OPERATION INSTRUCTIONS
WRT3920WS
EPA Wood-Burning Fireplace
P/N 900881-00 REV. B 10/2018
MODELS
WRT3920WS
This installation manual will enable you to obtain a safe, efficient
and dependable installation of your fireplace system. Please read
and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any cir-
cumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace, chimney components and
accessories, may void the warranty, listings and approvals of this system
and could result in an unsafe and potentially dangerous installation.
IHP wood-burning fireplaces are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
• The fireplace cannot be operated without a
door. Consult your dealer to select the correct
replacement door.
• The fireplace is equipped with a blower, electri-
cal connection must be made prior to fireplace
installation
• Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
• Install the fireplace only as described in these
instructions.
This product can expose you to chemicals includ-
ing Carbon Black, which is known to the State of
California to cause cancer, and Carbon Monoxide,
which is known to the State of California to cause
birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
P900881-00
WARNING
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Superior Fireplaces WRT3920WS and is the answer not in the manual?

Questions and answers

Summary of Contents for IHP Superior Fireplaces WRT3920WS

  • Page 1 SAVE THESE INSTRUCTIONS and could result in an unsafe and potentially dangerous installation. FOR FUTURE REFERENCE IHP wood-burning fireplaces are designed for use as a supplemental heater. They are not intended for continuous use as a primary heat source. An French manual is available upon request. Order P/N 900881-01.
  • Page 2: Table Of Contents

    Security Chimneys only. ® • 6” diameter chimney - Model DuraTech ® Thank you for selecting a IHP fireplace as the answer to your home supplemental heat- DTC manufactured by DuraVent only, ® ing needs. including: - Chimney lengths...
  • Page 3: Safety Rules

    IMPORTANT! GENERAL SAFETY WARNING WARNING PRECAUTIONS. READ AND UNDERSTAND THESE SAFETY Be careful adding wood fuel to Use care when selecting window RULES BEFORE YOUR FIRST FIRE. treatments for windows located the fire or handling fireplace tools near the fireplace. Avoid using such as shovels, tongs or pokers.
  • Page 4: Operating The Fireplace

    Figure 1 This manual describes the installation and operation of the IHP model WRT3920WS catalytic equipped wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s certified to comply with 2020 particulate emission standards using crib wood. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 10,900 to 35,600 Btu/hr.
  • Page 5 The combustion air control should be in the Medium Combustion Slow Combustion closed position when the fireplace is not in use. This will minimize air leakage up the chimney. This is the recommended mode of operating When the air combustion control is completely The combustion air control and the CAT bypass the WRT3920WS fireplace and should be the closed, the fireplace is in a slow combustion phase.
  • Page 6: Starting And Maintaining A Fire

    STARTING AND MAINTAINING A FIRE Step 3. Open the door about 1” and wait 5 D. Wet wood seconds until the air flow has stabilized. Then Wet or tarred wood will smoulder and smoke open the door completely, put the logs in and instead of burning properly.
  • Page 7: Smoke Detector

    SMOKE DETECTORS RECOMMENDED Standard Cord of 8 Ft. Since there are always several potential sources Wood (2.4M) of fire in any home, we recommend installing smoke detectors. If possible, install the smoke detector in a hallway adjacent to the room 4 Ft.
  • Page 8: Well Seasoned Fuel

    MAINTAINING YOUR FIREPLACE Catalyst Monitoring Before performing chimney sweep, open the CAT bypass and remove the combustor. Remove dust accumulation after chimney Have your product inspected at least once It is important to periodically monitor the sweep and put the combustor back in place. a year by a qualified service technician to operation of the catalytic combustor to ensure ensure gaskets, air tubes, baffles, and vent-...
  • Page 9 Cleaning Procedure (see Figure 9A): Tools required: (2) 9/16” wrenches, #2 square drive bit/driver With catalyst bypass in closed position, remove (2) baffle boards from firebox. 1. Using (2) 9/16” wrenches, loosen and remove the bolt and nut that connects the linkage arm to the catalyst bypass box 2.
  • Page 10 CATALYTIC COMBUSTOR TROUBLESHOOTING GUIDE Problem Condition Solution Ash Build-up on Combustor Surface Normal Ash, a fluffy light gray powder, and soot, accumulate on the com- bustor surfaces in normal use. Ashes accumulate as a result of the smoke being burned within the combustor and carried out of the firebox by the chimney draft.
  • Page 11: Refractory Installation

    The intense heat of the fire will normally cause hairline cracks in the refractory. These cracks can be minimized by proper curing as described in “First Fires”. They will not normally dimin- ish the effectiveness of the refractory. If large cracks develop, then the refractory should be replaced.
  • Page 12: Door Removal

    F [260° C], is suitable) or adhesion problems may result. Apply gasket Screw cement to the gasket channel and install the new gasket. This replace- ment part is available from your IHP dealer in the following dimensions: Figure 12 Gasket...
  • Page 13: Fireplace Installation

    FIREPLACE INSTALLATION This fireplace may be installed directly on the floor or on a raised base (for proper guidelines, refer to “Hearth Extension Requirements”) and a minimum of 6’8” (2 m) measured from the base of the appliance to the Locating The Fireplace ceiling is required.
  • Page 14: Optional Cast Facade Installation

    Optional Cast Facade installation Install the Facade per instructions provided in WARNING: THE HEARTH EXTEN- Facade Kit (ordered separately - see Page 27). SION IS TO BE INSTALLED ONLY AS ILLUSTRATED. Fireplace Framing, Facing And Mantel The construction of the framing, facing, and mantel must be in accordance with the stan- The crack between the fireplace Safety Metal Strip...
  • Page 15: Framing Dimensions

    Back Wall of Chase/Enclosure OUTSIDE CHASE Corner Installation Including Finishing Materials, if any FRAMING DIMENSIONS 36” 915 mm 22-1/8” 37-3/4” 959 mm * Zero Clearance 31-3/8” 797 mm From Back Spacer to Wall 14-7/8” 378 mm 74-3/8” 1889 mm 37-1/4” 946 mm 19-5/8”...
  • Page 16: Nailing Flanges

    Drywall or Any Rigid Material Draft Stops 2” x 4” Insulated Chase Construction Mantel and Facing (Side View) 1/2” Plywood Storm Roof Support Collar Mantel Drywall Firestop Flashing 12” Attic 2 x 3 Min. * Floor (305mm) Radiation (51mm x 76mm) Ceiling Max.
  • Page 17: Fireplace Blower

    FIREPLACE BLOWER A wall on/off switch must be installed to control Noncombustible Facing the blower. An optional heat switch and variable The fireplace is equipped with a blower. It is speed control are available (see Page 28). located in the bottom of the fireplace towards Drywall If installed, the heat activated switch must be the back.
  • Page 18: Central Forced Air Kit

    WRT3920WS fireplace hot air exhaust. thermostat will turn on the blower when the openings. Fix the adaptors on the fireplace 7. Use only IHP grills and components as room where the fireplace is located becomes openings by turning clockwise (Figures 23 described in this manual.
  • Page 19: Outside Air Kit

    Make a 4-1/4” (110 mm) hole in the outside wall of the house at the chosen location. From outside, place the outside air register in the hole (open side down) and fasten the register to the wall with screws as shown (see Figure 28).
  • Page 20: Draft Requirements

    NOTE: 2" clearance to combustibles around chimney components required. are especially prone to flow reversal. 3. The IHP fireplace model WRT3920WS may be installed only with Se- NOTE: Blown or fill type insulation materials must not be in contact with or DuraVent models the fireplace or in the enclosure frame as described in ‘’Enclosure’’...
  • Page 21 CHIMNEY INSTALLATION Attic Radiation Shield INSTRUCTIONS Attic Radiation ASHT / S2100 Air Cooled Pipe * Shield HT6103+ / HT6000+ 1. Cut and frame the holes in the ceiling, floor Solid Packed Pipe * and roof where the chimney will pass (see Figure 31).
  • Page 22: Offset Chimney Installation

    After reaching the location requiring the elbow, proceed as follows: Air Cooled Chimney * Chimney ASHT+ / HT6103+ / S-2100+ / HT6000+ Collar DuraTech DTC Chimneys Spacer (built 1. Install the first elbow; turn it in the required into flashing) direction.
  • Page 23 Offset Dimensions Total Height Horizontal Offset Chimney Elbow Offset & One Length Between Elbows Two Lengths Between Elbows 6” Height 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48”...
  • Page 24: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD OFFSET CHIMNEY INSTALLATION When traversing a combustible wall with the chimney at a 30º or 45º angle, an angled firestop or wall radiation shield must be installed. Only Chimney AC one is required. NOTE: 45º angle for Canada only ( RSMI45 / 6DTC-S45 In cold climate locations (climates where temperatures will fall below 32°...
  • Page 25: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION Universal Roof Support When installing a support, slightly lift the chimney system so the weight 18” (460 mm) will lie on the support, not on the fireplace to reduce expansion noises. 18” (460 mm) This support has three possible uses: 1.
  • Page 26: Masonry Application Instructions

    INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION Follow these steps: WARNING: Before starting the installation, the masonry chimney must 1. Position the fireplace in its location. Temporarily install the ASHT+ be inspected by a qualified chimney sweep. elbow on the top of the fireplace and, using a level, mark with an oval the location where the flue liner will enter the masonry chimney.
  • Page 27: Installation Accessories

    OPTIONAL INSTALLATION ACCESSORIES Central Forced Air Kit Accessories Central Forced Air Kit, Central forced air kit including: blower (BISZY), flex adaptor (BISAF), 2 clamps, variable Installation Accessories speed control (VRUW), thermo-disk (VTU), fan to flexible BISFWK-1 pipe adapter (BISAVF), back draft damper (BISBD), aluminium Description Cat./ Part No.
  • Page 28: Replacement Parts

    BISBD Fireplace to Flex adaptor and 2 clamps, BISAF BISAF Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards.
  • Page 29: Chimney Components Lists

    SECURITY CHIMNEYS AND DURAVENT - PARTS AND COMPONENTS LISTS ® ® The components listed below must be ordered from Security Chimneys or DuraVent . Contact your Security Chimneys or ® ® DuraVent Distributor or Dealer for ordering information. M&G DuraVent Security Chimneys ®...
  • Page 30 SECURITY CHIMNEYS - PARTS AND COMPONENTS LISTS ® The components listed below must be ordered from Security Chimneys . Contact your Security Chimneys Distributor or Dealer for ordering information. ® Tubinox LL Chimney Lining System** ® Security Chimneys ® 450-973-9999 Rigid Stainless Steel Liner For Relining A Masonry Chimney, 6”...
  • Page 31: Safety/Listing Label

    SAFETY / LISTING LABEL - WRT3920WS NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
  • Page 32: Warranty

    In order for any claim under this warranty to be valid, you must contact the IHP dealer/distributor from which you purchased the product. If you cannot locate the dealer/ distributor, then you must notify IHP in writing. IHP must be notified of the claimed defect in writing within 90 days of the date of failure. Notices should be directed to the IHP Warranty Department at 1769 East Lawrence Street;...
  • Page 33 In order for any claim under this warranty to be valid, you must contact the IHP dealer/distributor from which you purchased the product. If you cannot locate the dealer/ distributor, then you must notify IHP in writing. IHP must be notified of the claimed defect in writing within 90 days of the date of failure. Notices should be directed to the IHP Warranty Department at 1769 East Lawrence Street;...
  • Page 34: Product Reference Information

    Dealer’s Name _____________________________________________________ Dealer’s Phone Number ______________________________________________ Innovative Hearth Products (IHP) reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
