IHP sv4.5htss Instruction Manual

Advertisement

TERMINATIONS: SV4.5HTSS, SV4.5-20SSWSK, SF-HTSS, SV4.5TK90SS;
FLEX KITS: SFKIT12-SS, SFKIT18-SS, SFKIT24SS, SFKIT36SS, AND SFKIT48-SS

TERMINATIONS

SS Terminations

SV4.5HTSS
SV4.5-20SSWSK
SF-HTSS
SV4.5TK90SS

Flex Kits Using the SV4.5HTSS Termination

SFKIT12SS
SFKIT18SS
SFKIT24SS
SFKIT36SS
SFKIT48SS

Standards

These terminations have been tested and listed to ANSI Z21.88/
CSA 2.33 by Omni Test Laboratories (Report 116-P-40D-5).
Refer to the installation instructions provided with the fireplaces
listed above for framing and clearance information, and for
proper vent configuration and assembly.
For the fireplace models listed, the SV4.5HTSS (and kits listed
above) can be substituted for the SV4.5HT-2 termination
pictured in the installation instructions provided with
the fireplace.
Table 1: Venting components required for exterior
wall thicknesses, when using Square (SV4.5HT) and
Small Square (SV4.5HTSS) Terminations
Venting Components Required
Termination Kit Only
Termination Kit and 6 in. Vent Section
(SV4.5L6)
Termination Kit and 12 in. Vent Section
(SV4.5L12)
Termination Kit and 20 in. Vent Section
(SV4.5RCHA)
Termination Kit with Telescopic
Section (SV4.5LA) and
6 in. Vent Section (SV4.5L6)
P750204M
P/N 750204M
Rev. F 03/2015
Exterior Wall Thickness
6–9 in. (152–228 mm)
10 1/2–13 1/4 in. (267–337 mm)
16 3/4–17 1/2 in. (425–495 mm)
9–21 1/4 in. (228–540 mm)
12–21 1/4 in. (305–540 mm)
NOTE: DIAGRAMS AND ILLUSTRATIONS NOT TO SCALE

COMPATIBLE FIREPLACES

The following fireplaces are listed for use with the
SS terminations and flex kits listed:
Astria Aries Series
Aries 33, 35, 40, and 45
Superior DRT/DRC2000 Series
DRT2033, 2035, 2040, and 2045
DRC2033, 2035, 2040, and 2045
Astria Gemini Series
Gemini 33, 35, 40, and 45
Gemini CD 35 and 40
Superior DRT/DRC3000 Series
DRT3033, 3035, 3040, and 3045
DRC3035 and 3040
Linear Fireplaces
DRL6542TEN
Rhapsody42TEN
DRL3042 and 3054
Sirius 42 and 54
The following legacy fireplaces are no longer in production
but are also listed for use with the SS terminations and flex
kits listed;
Superior
SSDV-3328
SSDV-3530
Lennox Merit
LMDV3328
LMDV-3530
MPLDV-30
MPLDV35
Lennox Merit Louverless Series
MLDVT30
MLDVT35
MLDVT40
MLDVT45
MLDVTCD-35
HEARTH PRODUCTS
KITS AND ACCESSORIES
HORIZONTAL TERMINATIONS
Superior Direct Vent
SDV35N
SDV35N-2
Superior Louverless Series
SLDVT30
SLDVT35
SLDVT40
SLDVT45
Merit Series
MPDP35N
MPDP35P
MeritPlusProDV35N
MeritPlusProDV35P
