D OPC-499 (
HEADSET ADAPTER)
When using a headset, such as those from the David Clark Co. via the OPC-499
puts your transmitted voice to the headset for monitoring. See "I Side tone function "(p. 11) when setting the side tone level.
PTT
IC-A24/A6

OPTIONAL HEADSET CONNECTION

connection
PTT switch
Use a PTT switch with a
3.5 mm ( 1 / 8 ") diameter
plug, if required.
OPC-499
adapter
HEADSET ADAPTOR
,
HEADSET
(Must be purchased
separately)
13
the transceiver out-
12
13
34
