Table Of Contents - Icom IC-756PROIII Instruction Manual

6 FUNCTION FOR TRANSMIT ......................... 66 - 72
■ VOX function .................................................. 66
D Using the VOX function ............................... 66
D Adjusting the VOX function.......................... 66
■ Break-in function ............................................ 67
D Semi break-in operation .............................. 67
D Full break-in operation ................................. 67
■ Transmit filter width setting (SSB only) .......... 68
■ Speech compressor ....................................... 68
■ ∂TX function .................................................. 69
■ Monitor function ............................................. 70
■ Split frequency operation ............................... 71
■ Quick split function ......................................... 72
7 VOICE RECORDER FUNCTIONS ................. 73 - 76
■ Digital voice recorder ..................................... 73
8 MEMORY OPERATION .................................. 77 - 82
■ Memory channels .......................................... 77
■ Memory channel selection ............................. 77
■ Memory channel screen ................................ 78
■ Memory channel programming ...................... 79
■ Frequency transferring ................................... 80
■ Memory names .............................................. 81
■ Memory clearing ............................................ 81
■ Memo pads .................................................... 82
9 SCANS ........................................................... 83 - 87
■ Scan types ..................................................... 83
■ Preparation .................................................... 83
■ Programmed scan operation ......................... 84
■ ∂F scan operation ......................................... 84
■ Fine programmed scan/
fine ∂F scan ................................................... 85
■ Memory scan operation ................................. 85
■ Select memory scan operation ...................... 86
■ Setting select memory channels .................... 86
■ Scan set mode ............................................... 87
■ Tone scan ....................................................... 87
10 ANTENNA TUNER OPERATION ................... 88 - 90
■ Automatic antenna selection .......................... 88
■ Antenna tuner operation ................................ 89
■ Optional external tuner operation .................. 90
11 CLOCK AND TIMERS .................................... 91 - 93
■ Time set mode ............................................... 91
D Setting the current time ............................... 92
D Clock2 function activity ................................ 92
D Clock2 offset setting .................................... 92
D Timer function activity .................................. 92
D Setting power-on time.................................. 93
D Setting power-off period............................... 93
D Timer operation............................................ 93

TABLE OF CONTENTS

12 SET MODE ................................................... 94 - 104
■ Set mode description ..................................... 94
■ Level set mode .............................................. 95
■ Display set mode ........................................... 97
■ DSP filter set mode ......................................... 99
■ Miscellaneous (others) set mode ................... 99
13 OPTION INSTALLATION .................................... 105
■ Opening the transceiver's case ................... 105
■ UT-102
VOICE SYNTHESIZER UNIT
14 INTERNAL VIEWS .............................................. 106
15 MAINTENANCE ......................................... 107 - 109
■ Troubleshooting ........................................... 107
■ Fuse replacement ........................................ 108
■ Clock backup battery
replacement ................................................. 108
■ Tuning dial brake adjustment ....................... 109
■ Frequency calibration
(approximate)................................................ 109
16 CONTROL COMMAND ............................... 110- 114
■ Remote jack (CI-V) information .................... 110
17 SPECIFICATIONS ............................................... 115
18 OPTIONS ............................................................. 116
19 ABOUT CE ........................................................... 117
1
2
3
4
.................. 105
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
iv
