Summary of Contents for Fisher & Paykel Double DishDrawer FDD24SAX9N
- Page 1 DOUBLE DISHDRAWER™ DISHWASHER DD24DA & DD24DCT models INSTALLATION GUIDE US CA 591153C 05.19...
-
Page 2: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electrical Shock Hazard Installation of this dishwasher requires basic mechanical and electrical skills. Before installing the dishwasher, remove the house fuse or open the circuit Be sure to leave these Instructions with the Customer. breaker. -
Page 3: Parts Supplied
PARTS SUPPLIED Drain hose Drain hose Wire clip (2) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips Rubber washer Moisture protection Hexagonal Prefinished... - Page 4 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE LOWER DRAWER REMOVE THE ACCESS COVER & REMOVE POWER CORD To prevent kinked hoses Either sit the drawer down on the left hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal. Clip Clip Access cover...
- Page 5 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION TERMINATE MAINS WIRING AS SHOWN AND REPLACE MODULE AND COVERS Fit a suitable cable clamp for the conduit through the metal knockout. Ensure wiring is routed through or under housing ribs. Screw down the Live, Neutral and Earth wires correctly.
-
Page 6: Product Dimensions
PRODUCT DIMENSIONS FRONT PROFILE DD24DA DD24DCT PRODUCT DIMENSIONS INCHES (MM) INCHES (MM) Overall height of product 32 5/16 - 34 5/8” (820-880) 34 - 36 3/8” (864-924) Overall width of product 23 9/16” (599) 23 9/16” (599) Overall depth of product 22 9/16”... -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS Bracket slots PLAN PROFILE DD24DA DD24DCT CABINETRY DIMENSIONS INCHES (MM) INCHES (MM) Inside height of cavity* min. 32 5/16” (820) min. 34” (864) Inside width of cavity 23 5/8” (600) 23 5/8” (600) Minimum clearances from adjacent cabinetry Inside depth of cavity min. -
Page 8: Cavity Preparation
CAVITY PREPARATION COUNTERTOP Water Connection Recommended HOT Moisture 3/8” protection tape (Maximum 140°F/60°C). (10 mm) must be applied Supplied hose to suit 3⁄ 8 ” (9 mm) male compression fitting. Water Pressure These marks indicate formed Water softener models bracket screw locations, if Max. - Page 9 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE LEFT HAND SIDE RIGHT HAND SIDE Drain hoses - 78 1/2” (2000 mm) Drain hoses - 70 1/2” (1800 mm) Inlet hose - 64 3/4” (1650 mm) Inlet hose - 49” (1250 mm) Power cord (excl.plug) - 29 1/2”...
- Page 10 NOW CHOOSE WHICH INSTALLATION METHOD (A) OR (B) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (A) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS PULL THROUGH HOSES & PUSH INTO THE CAVITY optionally attach the Clip all four side mounting brackets two top mounting brackets into their slots using a flat-bladed...
- Page 11 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting Open the drawer brackets will only (x2) halfway. Using bend upwards a a flat bladed maximum of 3/8” screwdriver, prise (10 mm). Replace the gray the gray rubber rubber plug back into plug out of the...
- Page 12 ALTERNATIVE METHOD (B) - SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses Either sit the drawer down on the left hand optionally attach the side (recommended) or rotate the drawer two top mounting brackets clockwise, resting it on its side after removal.
- Page 13 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting brackets will only bend upwards a (x2) maximum of 3/8” For further adjustment, (10 mm). using the most appropriate length Hexagonal socket supplied, fully extend leveling feet up to required distance by hand.
- Page 14 FIT THE SUPPLIED TOEKICK PANEL Mounting rail Where the toekick meets the bottom of the tub is the cut-off point Lay the toekick face down on Turn the toekick over and Smooth the edges with a file. a chopping board or similiar score along the same line Be careful of sharp edges.
- Page 15 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. DRAINAGE OPTION 1 Dishwasher and Ø 1 1/2” (38 mm) Standpipe Screw Drain hose support to back wall at correct height. If space is limited for fixing, push hose through drain max.
- Page 16 DRAINAGE OPTION 2 Dishwasher using Dual Air Gap/Break with Drain Hose Joiner IMPORTANT! We recommend the use of a commercially available Dual (Double) Air Gap/Break Kit. This provides totally separate draining for each drawer and eliminates possible “cross Drain hose draining”...
- Page 17 DRAINAGE OPTION 3 Dishwasher using drain hose joiner onto sink trap/waste tee Supplied drain hose joiner to suit Screw Drain hose Ø 3/4” (19 mm) support to back wall waste tee at correct height. If space is limited for fixing, push hose through drain hose support to required height.
-
Page 18: Troubleshooting
CONNECT INLET HOSE TO HOT WATER SWITCH PRODUCT ON No leaks! Ensure the supplied rubber washer is Tighten coupling with spanner. fitted inside the coupling. TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle. (This is displayed as an fault) Check for a kinked drain hose, blocked waste connection, highloop not properly installed, drain hose not routed correctly or spray arms not in place. -
Page 19: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Turn on the power and water supplies, then open the drawers. You should hear a Check all parts are installed. beep and see a program indicator light up on the internal control panel. Ensure that all panels and parts thereof are secure and final electrical tests have Check the spray arms are in place, mounted correctly and free to rotate, by been conducted in accordance with local electrical regulations. - Page 22 SINGLE DISHDRAWER™ DISHWASHER DD24SA & DD24SCT models INSTALLATION GUIDE US CA 591153C 05.19...
- Page 23 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electrical Shock Hazard Installation of this dishwasher requires basic mechanical and electrical skills. Before installing the dishwasher, remove the house fuse or open the circuit Be sure to leave these Instructions with the Customer. breaker.
- Page 24 PARTS SUPPLIED Drain hose Drain hose Wire clip (1) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips 1 1/2” (38mm) Rubber washer Moisture protection 5/8”...
- Page 25 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION REMOVE THE DRAWER REMOVE THE ACCESS COVER & REMOVE POWER CORD To prevent kinked hoses Either sit the drawer down on the left hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal. Clip Clip Access cover...
- Page 26 OPTIONALLY HARD WIRING PRIOR TO INSTALLATION TERMINATE MAINS WIRING AS SHOWN AND REPLACE MODULE AND COVERS Fit a suitable cable clamp for the conduit through the metal knockout. Ensure wiring is routed through or under under housing ribs. Screw down the Live, Neutral and Earth wires correctly.
- Page 27 PRODUCT DIMENSIONS FRONT PROFILE DD24SA DD24SCT PRODUCT DIMENSIONS INCHES (MM) INCHES (MM) Overall height of product 16 1/8” (410) 17 7/8” (454) Overall width of product 23 9/16” (599) 23 9/16” (599) Overall depth of product 22 9/16” (573) 22 9/16” (573) Depth of chassis (to back of front drawer panel) 21 3/4”...
- Page 28 CABINETRY DIMENSIONS Bracket slots PLAN PROFILE DD24SA DD24SCT CABINETRY DIMENSIONS INCHES (MM) INCHES (MM) Inside height of cavity min. 16 1/4” (412) min. 18” (456) Inside width of cavity 23 5/8” (600) 23 5/8” (600) Minimum clearances from adjacent cabinetry Inside depth of cavity min.
- Page 29 CAVITY PREPARATION COUNTERTOP Moisture 3/8” protection tape (10 mm) must be applied Water Connection Recommended HOT (Maximum 140°F/60°C). These marks indicate formed bracket screw locations, if Supplied hose to securing by drawer removal. suit 3/8” (9 mm) male compression fitting. Ø...
- Page 30 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE LEFT HAND SIDE RIGHT HAND SIDE Drain hose - 78 1/2” (2000 mm) Drain hose - 70 1/2” (1800 mm) Inlet hose - 64 3/4” (1650 mm) Inlet hose - 49” (1250 mm) Power cord (excl.plug) - 78 1/2”...
- Page 31 NOW CHOOSE WHICH INSTALLATION METHOD (A) OR (B) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (A) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS PULL THROUGH HOSES & PUSH INTO THE CAVITY Clip all four side mounting brackets into their slots using a flat-bladed screwdriver.
- Page 32 SECURE TO THE CABINETRY ON THE SIDES Open the drawer halfway. Using a flat bladed screwdriver, prise the grey rubber plug out of the trim moulding. Replace the grey rubber plug back Using a small Philips screwdriver, into the trim moulding and ensure screw through the trim moulding, securing the trim seal is facing forward.
- Page 33 ALTERNATIVE METHOD (B) - SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses Either sit the drawer down on the left hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal. Push drawer runners back in on either side.
- Page 34 SECURE TO THE CABINETRY ON THE SIDES The product has three pairs of fixing points: Ensure the sound insulation is repositioned correctly. a pair of fixing two pairs of formed holes either side brackets on either side on the bottom of the chassis (use 1 1/2”...
- Page 35 THERE ARE THREE DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. DRAINAGE OPTION 1 Dishwasher and Ø 1 1/2” (38 mm) Standpipe Screw Drain hose support to back wall at correct height. If space is limited for fixing, push max.
- Page 36 DRAINAGE OPTION 2 Dishwasher using Air Break with Drain Hose Joiner Secure drain hose to drain hose joiner and secure to Air Break 37 3/8” (950mm) Max. height to top of Air Break step 14 (countertop or wall mounted) min. R 8” (200mm) IMPORTANT! Ensure that drain connection...
- Page 37 DRAINAGE OPTION 3 Dishwasher using drain hose joiner onto sink trap/waste tee Supplied drain Screw Drain hose hose joiner to suit support to back wall Ø 3/4” (19 mm) at correct height. waste tee If space is limited for fixing, push hose through drain hose support to required height.
- Page 38 CONNECT INLET HOSE TO HOT WATER SWITCH PRODUCT ON No leaks! Ensure the supplied rubber washer is fitted Tighten coupling inside the coupling. with spanner.
- Page 39 TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle. (This is displayed as an fault) Check for a kinked drain hose, blocked waste connection, highloop not properly installed, drain hose not routed correctly or spray arms not in place. No water supply (This is displayed as an fault) Check water is connected and turned on.
- Page 40 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Turn on the power and water supplies, then open the drawer. You should hear a Check all parts are installed. beep and see a program indicator light up on the control panel. Ensure that all panels and parts thereof are secure and final electrical tests have Check the spray arm is in place, mounted correctly and free to rotate, by physically been conducted in accordance with local electrical regulations.
