9. Structure Diagram

PS/2 keyboard
Aluminium front panel
Class A active matrix TFT LCD panel
Analog to digital signal converter board
Rear metal case
LCD inverter
LCD membrane
Ball bearing telescopic slides with stopper
Adjustable mounting bracket
KVM membrane & KVM switch board
