Thank you for choosing Hongqi HS5!
All FAW vehicle models have passed China Compulsion Certification (CCC Certification) and
Gulf Cooperation Council Certification (GCC Certification).
Hongqi HS5 sedan carries multiple luxury equipment and advanced technology. To take full
advantage of these equipment and technology, FAW recommends you read this manual
thoroughly to know Hongqi HS5 sedan quickly and comprehensively.
In addition to introducing the use of the vehicle, this manual explains the driving safety, vehicle
maintenance and
emergency countermeasures in detail to help you drive this vehicle safely
and comfortably, and meanwhile maintain the value of the vehicle to the maximum degree.
The documents provided with the vehicle include this Owner's Manual, Maintenance Manual,
which contain the important maintenance information for HS5 Sedan. FAW suggests you keep
the documents provided inside the vehicle for reference at any time.
This manual is compiled in accordance with the product situations at the time of printing. It will
be modified into a second edition for the subsequent products. FAW will reserve the right to
make changes at any time without notice. Thank you for your understanding.
Foreword
First Automobile Works (FAW)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS5 and is the answer not in the manual?

Questions and answers

Валерий
February 21, 2025

Здравствуйте.Какая аккумуляторная батарея стоит ,название и модель?Машина HONGQI HS5 2023 год.

0
1 comments:
Mr. Anderson
February 21, 2025

The battery model for the 2023 Hongqi HS5 is a ternary lithium battery.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Hongqi HS5

Summary of Contents for Hongqi HS5

  • Page 1 All FAW vehicle models have passed China Compulsion Certification (CCC Certification) and Gulf Cooperation Council Certification (GCC Certification). Hongqi HS5 sedan carries multiple luxury equipment and advanced technology. To take full advantage of these equipment and technology, FAW recommends you read this manual thoroughly to know Hongqi HS5 sedan quickly and comprehensively.

  • Page 3: Safety Instructions

    Contents Pictorial Index Search by illustration Safety Instructions One must read through the safety instructions. How to read instruments, various alarm lights and Instrument Cluster indicators, etc. The opening/closing of windows and doors, adjustments Operating the Components before driving, etc. Driving Required operations and advice while driving Audio System...

  • Page 4: Table Of Contents

    Contents Index 3.2. Opening, closing and locking of doors and Safety Instructions trunk lid 1.1. Instructions for Safe Use Doors ..............77 Safe driving ............24 Trunk lid ..............81 Seat belt ..............25 Intelligent entry & start system ......85 Airbag ..............
  • Page 5 Turn signal lamp control handle ......131 Blind Spot Detection (BSD)* ......190 Electronic parking brake (EPB) system ....132 Traffic Sign Recognition (TSR)* ......194 AUTO HOLD* ............ 134 Idling start/stop system ........196 4-3. Operating lights and wipers Auto Parking Assist (APA)* ........
  • Page 6 Using the mobile phone APP ....... 258 Trunk device ............290 5-13. Hongqi Smart Connect • Cargo hook ............290 Using Hongqi Smart Connect ......261 • Luggage net ............290 6-4. Other Interior Equipment On-board wireless charging* ....... 291 Interior Equipment Sun visor ..............
  • Page 7 If a warning lamp turns on or a warning buzzer Maintenance sounds ..............348 7-1. Maintenance and Servicing In the case of a flat tire ........354 Cleaning and protecting vehicle exterior trim ..304 If the engine cannot be started ......362 Cleaning and protecting vehicle interior trim ..
  • Page 8 Pictorial Index Exterior Engine compartment cover Front windshield wipers Sunroof Exterior rear mirror Side turn signal lamp Front Turn signal Low beam / high beam Front Fog Lamp Day and night driving lights Front position Towing eye cover lamp...
  • Page 9 Rear position lamp Filler cap High-level brake lamp Rear windshield Vehicle door Wipers Trunk lid Reversing lamp License plate l Tire Rear fog lamp Transpos ition Replace Turn back signal Tire pressure Brake lamp Trunk lid, electric Close button...
  • Page 10 Pictorial Index Interior Front seat center storage Eyeglasses box compartment Front seat belt Driver airbag Front passenger airbag Curtain airbag Front head restraint Glove box Front seat Front cup holder...
  • Page 11 Central door lock switch Exterior rearview mirror adjusting button Interior door handle Power window locking switch Power window switch Bottleholder and side pocket...
  • Page 12 Pictorial Index Interior Front interior lamp Front map lamp Front map lamp switch Roof grab Electric sunshade handle curtain switch Rear map lamp Rear map lamp switch Vanity mirror lamp Sun visor SOS switch Sunroof switch Front interior lamp switch Interior anti-glare rear view mirrors...
  • Page 13 Pictorial Index Instrument Panel Combination instrument display Lamp control lever Wiper control lever Headlamp Turn lamp Multimedia display Fog lamp Hazard warning lamp switch Steering wheel Steering wheel adjustment electric adjustment handle button Cruise control lever Constant speed cruise Adaptive cruise control Advanced cruise...
  • Page 14 Pictorial Index Instrument Panel Internal / external circulation button Forced defrosting of Windshield heating button windshield /Defrost (defrost) button Air volume increase AUTO button button Driver side Front passenger side temperature display temperature display Front passenger side Driver side temperature setting temperature setting key button Air volume decrease...
  • Page 15 Engine switch Shift lever knob Driving mode switch button Shift unlock button P gear button Electronic parking brake Automatic parking switch button Front passenger’s seat Driver's seat heating key heating key Front passenger side Driver's seat Wireless charging area ventilation key seat ventilating button...
  • Page 16 Pictorial Index Instrument Panel Hang up Gear up paddle Volume adjustment/mute Gear down paddle button Call answer key Combination instrument Voice recognition MOD button display operation button button...
  • Page 17 Heads up display setting button Steering wheel heating button Opening button inside the trunk lid Hill descent control button Mileage setting button Left lower panel glove box...
  • Page 18 Pictorial Index Rear of the Vehicle Rear central armrest Rear seat heating button Rear head restraint Rear seats Rear cup holder Rear power window switch Rear seat belt...
  • Page 19 If you are unclear about the purchased vehicle or the User’s Manual, please contact FAW authorized Hongqi dealers. Accessories, Spare Parts and Modification of the Vehicle The FAW authorized Hongqi dealers possess advanced tools, equipments and genuine accessories required for providing maintenance and service for your vehicle.
  • Page 20 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by FAW authorized Hongqi dealers before you scrap the vehicle. The SRS airbag and seat belt pretensioner devices in the vehicle contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners...
  • Page 21 Vehicle Model Code This manual introduces the vehicle models CA6471 , CA6472HA6 , CA6471T , CA6472HA6T. : Two-wheel drive vehicle. : Four-wheel drive vehicle. CAUTIONS Driving precautions  The driver always drive soberly and defensively with full attention. ●Sober driving: do not drive the vehicle after drinking or taking drugs. Alcohol or some drugs will delay the response time and affect the judgment and coordination ability, which may lead to serious injury or even death.
  • Page 22 Reading this Manual CAUTIONS Introduce warning. Failure to follow instructions may result in serious personal injury or even death. Caution Explain precautions which, if not observed, may cause damages or failures in the vehicle or devices. Step 1 Indicates that operations or steps are performed in numerical order. Indicates actions (push, turn, press, etc.) for operating switches and other devices.
  • Page 23 How to Search Search by title   Contents........P.1 Search by installation position  Pictorial index......P.6...
  • Page 25 Safety Instructions 1.1. Instructions for Safe Use Safe driving ............24 Seat belt ..............25 Airbag ..............31 Child safety information ........42 Children restraint device ........43 Install the child restraint device ......47 Precautions for Exhaust Gas ......50 1-2.

  • Page 26: Safety Instructions

    1-1. Safety Instructions Safe driving Adjust the seats, steering wheel and rear-view mirrors to the appropriate position before driving to ensure safety. Correct driving posture  Sit back straight and lean against the seat back. Adjust the position of the seat backward to ensure that the pedals can be easily depressed.

  • Page 27: Seat Belt

    1-1. Safety Instructions Seat belt Before driving the vehicle, ensure that all occupants in the vehicle have fastened their seat belts. Correct use of the seat belts  Stretch the shoulder belt so that it crosses the shoulder, but should not touch the neck or slip off the shoulder. ...
  • Page 28 1-1. Safety Instructions Adjust the seat belt height (front seats) Press the button for adjustment Down Press and hold the adjusting button and move the height adjuster up and down as needed until you hear a "click". Rear central seat belt Fasten the seatbelt Insert the locking bolt into the buckle until a "click"...
  • Page 29 1-1. Safety Instructions Emergency lockup retractor (ELR)  In case of emergency braking or collision, the retractor will lock the seatbelt. if you lean forward too fast, it will also lock the seatbelt. Moving slowly and smoothly will extend the seatbelt and allow you to move freely.
  • Page 30 1-1. Safety Instructions CAUTIONS To reduce the risk of personal injury during emergency braking, emergency steering or accidents, please observe the following precautions, otherwise serious personal injury or even death may result. Fasten the seat belts  ● Make sure that the driver and all occupants have fastened their seat belts. ●Always wear seat belts correctly.
  • Page 31 1-1. Safety Instructions CAUTIONS To reduce the possibility of personal injury during emergency braking or accident and avoid causing serious personal injury or even death, please observe the following precautions. Correctly wear the seat belt  ● It is very dangerous for the driver to be in an incorrect posture or wear a seat belt incorrectly. Due to the incorrect wearing position of the seat belt, the pretensioner and the force limiting system are not providing adequate protection, which may lead to serious personal injury.
  • Page 32 1-1. Safety Instructions CAUTIONS Damage and wear of seat belts  ● Do not allow the door to grip the seat belt, locking tab or buckle, as this may damage the seat belt. ● The seat belt device must be inspected regularly. Inspect the seat belt components for cuts, wear and looseness.

  • Page 33: Airbag

    1-1. Safety Instructions Airbag The airbags are the passive safety protection devices to reduce or avoid injury to the passengers when the vehicle is subjected to severe impacts that may cause serious injury to the passengers. When the vehicle is under some serious impacts, the airbag is activated. The vehicle is equipped with multiple airbags.
  • Page 34 1-1. Safety Instructions Airbag system components Curtain airbag Driver seat airbag Driver's airbag Airbag failure alarm light Airbag control unit Front passenger airbag Front passenger seat airbag The main airbag system components are shown above. The airbag system triggers the airbag gas generator in the event of some severe frontal or side impact. The chemical reaction in the gas generator quickly makes the airbag filled up with non-toxic gas, so as to avoid injury caused by secondary collision between the driver and car.
  • Page 35 1-1. Safety Instructions CAUTIONS Precautions for Airbags  Observe the following precautions regarding the airbags. Otherwise, it may result in serious injury or even death. ● The driver and all passengers in the vehicle must wear their seat belts properly. ●...
  • Page 36 1-1. Safety Instructions CAUTIONS Precautions for Airbags  ● The impact force of the driver's airbag deployment is quite large. If the driver is too close to the airbag, it may cause serious personal injury or even death. The front passenger seat should be as far away from the airbag as possible.
  • Page 37 1-1. Safety Instructions CAUTIONS ■ Precautions for Airbags ● Do not kneel on the passenger seat facing the door or extend your head or hands out of the car. ● Do not stick any articles or lean on the instrument panel or the cover of the driver's airbag.
  • Page 38 1-1. Safety Instructions CAUTIONS Precautions for Airbags  ●Do not use seat accessories that may cover the deployment area of the seat airbag. They may hinder the deployment of the airbag. ● Do not hit the area where the airbag components are located or apply excessive force on them, otherwise the airbag may fail.
  • Page 39 1-1. Safety Instructions If the airbag deploys (inflated)  ● The impact force of the airbag deployment is quite large, and the occupants are too close to the airbag, it may lead to serious injury of casualties. ● When the air bag is deployed, it will be accompanied by a detonation sound of the airbag, and smoke will appear, but no fire will occur.
  • Page 40 1-1. Safety Instructions Operating conditions (Seat airbags and curtain airbags)  ● With the impact exceeding the set critical value in the event of severe side collision, the side airbags and curtain airbags on the collision side will be deployed. ●...
  • Page 41 1-1. Safety Instructions ● Rear-end collision ● side collision ● rolling over Situations where the airbag (seat airbag or curtain airbag) may not deploy  Seat airbags/curtain airbags may not deploy if the vehicle experiences a side impact at an angle to the body or if the non-passenger compartment experiences a side impact.
  • Page 42 1-1. Safety Instructions When to contact an authorized Hong Qi dealer of China FAW  In the following cases, the vehicle needs to be checked and/or repaired. Please contact and authorized Hong Qi dealer of China FAW as soon as possible. ●...
  • Page 43 1-1. Safety Instructions ● There are scratches, cracks or other damages on the seat surface equipped with seat airbag. ● There are scratches, cracks or other damages on the parts of curtain airbag, and parts such as A-pillar, B-pillar and C-pillar guard.

  • Page 44: Child Safety Information

    1-1. Safety Instructions Child safety information Please observe the following precautions when there are children in the car. Children should use appropriate child protection devices until they have grown up to use seatbelts on vehicles.  It is recommended that children be seated in the rear seat to prevent accidental touching of the shift lever, wiper switch, etc.

  • Page 45: Children Restraint Device

    1-1. Safety Instructions Children restraint device FAW strongly recommends the use of child restraint device. Points to be remembered Studies have shown that installing a child restraint device on a rear seat is much safer than installing one to the front passenger seat.
  • Page 46 1-1. Safety Instructions Information on the adaptability of different ISOFIX positions to ISOFIX child restraint systems The information in the table below shows the suitability of the child restraint system in different seat positions. ISOFIX position on the vehicle Mass group Size class Fixture module Rear left seat...
  • Page 47 1-1. Safety Instructions When installing the child restraint device in the front passenger seat  It is not recommended to install the child restraint device in the front passenger seat. When it is not avoidable, the following adjustments are necessary: ●...
  • Page 48 1-1. Safety Instructions CAUTIONS Use the child restraint system  ● If a child restraint system that is not suitable for this vehicle is used, it may not be possible to properly protect infants or children. This may lead to serious casualties (in case of emergency braking or accidents). Precautions for child protection ...

  • Page 49: Install The Child Restraint Device

    1-1. Safety Instructions Install the child restraint device Follow the instruction manual provided by the manufacturer. Use ISOFIX rigid anchor to secure the child restraint device to the seat. Attach the top tether strap when installing the child restraint device. Installing with the ISOFIX rigid anchor Step Slightly increase the gap between seat...
  • Page 50 1-1. Safety Instructions Fasten the locking clip firmly into the anchor support Step and tighten the top strap. Make sure the top tether strap is securely latched. Reinstall the head restraints Step CAUTIONS When installing a child protection device  Observe the following precautions.
  • Page 51 1-1. Safety Instructions CAUTIONS When installing a child protection devices  Please follow the instructions provided with the child protection device. Fix the child protection device firmly in place. If the child protection device is not properly fixed in place, it may cause serious injury or even death to children or other passengers in case of emergency operation or accident.

  • Page 52: Precautions For Exhaust Gas

    1-1. Safety Instructions Cautions on exhaust gas Exhaust gas contains substances harmful to the human body. CAUTIONS The waste gas contains colorless and odorless harmful gas carbon monoxide (CO). Please observe the following precautions. Otherwise, the exhaust gas may enter the vehicle, causing dizziness and accidents, or may seriously endanger your health and even cause death.

  • Page 53: Anti-Theft System

    1-2.Anti-Theft System Engine anti-theft system To prevent the vehicle from being stolen, the smart key and the card key have a built-in password chip. If the key is not registered in the computer in advance, the key cannot start the engine. Different vehicles have different information registered in the key.

  • Page 54: Body Anti-Theft System

    1-2.Anti-Theft System Vehicle body immobilizer system The body anti-theft system mainly monitors the status of four doors, hood and trunk lid. When the system detects that someone is forcing their way into the vehicle, it will give an alarm and flash the turn signal continuously.
  • Page 55 Instrument Cluster 2. Instrument Cluster Combination instrument ..........54 Alarm light ..............56 Indicator ............... 58 Multi-function display screen of instrument cluster 60 Head up display* ............70...

  • Page 56: Instrument Cluster

    2. Instrument Cluster Combination instrument Instantaneous vehicle speed Short-term average fuel consumption Due to the different vehicle configurations, the contents displayed also vary. Engine tachometer Displays the revolutions per minute of the engine. Tip/alarm icons display area Shows the vehicle warning lamp and indicator lamp, etc. Speedometer Displays the vehicle speed.
  • Page 57 2. Instrument Cluster Adjusting the backlight brightness in the vehicle The interior backlight brightness can be adjusted in the vehicle settings of the audio system. (See P.223) Condition for lighting the combination instrument  The engine switch is placed in "IG-ON" mode. CAUTIONS Prevent damage to the engine and its components ...

  • Page 58: Alarm Light

    2. Instrument Cluster Warning lamp The warning light indicates the current status of the vehicle system or the possible faults of the corresponding system of the vehicle. (See P.348) IHC system fault warning lamp Low fuel level warning lamp Failure indicator for engine control Engine exhaust gas monitoring system system fault warning lamp...
  • Page 59 Driving mode selection system fault SACC system steering assist failure warning lamp indicator Note: If any of the lights does not turn on or off, the corresponding system may be faulty. Contact FAW authorized Hongqi dealer for vehicle check.

  • Page 60: Indicator

    2. Instrument Cluster Indicator lamp The indicator light indicates the current operating status of each system of the vehicle. Left turn signal indicator lamp Right turn signal indicator lamp High beam ON indicator lamp Position lamp ON indicator lamp Front fog lamp ON indicator lamp Rear fog lamp ON indicator lamp ESC system working indicator lamp ESC system OFF indicator lamp...
  • Page 61 2. Instrument Cluster AEB system OFF indicator lamp AEB system working indicator lamp DSM system warning indicator lamp DSM system warning indicator lamp (minor abnormality) (serious abnormality) LDW/LKA system working indicator LDW/LKA system ON indicator lamp lamp system intelligent speed Active speed limiting...

  • Page 62: Multi-Function Display Screen Of Instrument Cluster

    2. Instrument Cluster Combination instrument multifunction display The combination instrument multifunction display presents the driver with a variety of driving-related information and audio navigation information. Instantaneous vehicle speed Instantaneous fuel consumption Comfort Multifunction display area Operate / view vehicle information, radio, music, phone, navigation assistance information, Himalayan online application, QQ music online application and other modules.
  • Page 63 2. Instrument Cluster Display switch Left and right selection buttons Short pressing will switch the setting interface Roller Rolling: rolling up and down will switch the selection item. Short pressing: confirm the selection. Return Short press to return to the previous interface. Menu button In the music and phone interfaces, short press to return to the menu interface.
  • Page 64 2. Instrument Cluster Multifunction display area By using the left and right buttons on the steering wheel, you can switch between the driving information, radio, music, phone, navigation, warning information, driver assistance information, Himalaya online, and QQ music. Multifunction display navigation bar Multifunction display information area Instantaneous vehicle speed Instantaneous...
  • Page 65 2. Instrument Cluster Navigation Displays the navigation information Specific operation. (See P.68) Warning information Displays the warning information Specific operation. (See P.68) Driver assistance information Displays the driver assistance information Specific operation. (See P.69) Himalaya online Displays the Himalaya online Specific operation.
  • Page 66 2. Instrument Cluster Note: the instant average fuel consumption/vehicle speed means the average fuel consumption/vehicle speed of this driving cycle. (If the power-off time for the last stop does not exceed 2h (hours), the last information will be accumulated). Long-term average fuel consumption/vehicle speed ...
  • Page 67 2. Instrument Cluster Date  Display the current date. Date 4WD status information *  Display the current AWD status. Average fuel consumption charge/long - term average fuel consumption charge  Display average fuel consumption billing information The average fuel consumption billing on/off can be set Average fuel consumption billing in the vehicle setting of audio system.
  • Page 68 2. Instrument Cluster Acceleration timer  Display and record the acceleration timer information. The acceleration timer on/off can be set in the vehicle setting of audio system. (See P.227) Current record Last record History best click Cancel save Radio  Select the channels in the list of FM, AM and favorite through the steering wheel roller to play.
  • Page 69 2. Instrument Cluster If the music is playing, the current play information will be displayed when the music interface is accessed. Operate the steering wheel roller to switch the tracks up/down; operate the home key or menu key to return the music operation interface.
  • Page 70 2. Instrument Cluster Answer the phone  In the call answer interface, you can perform operations such as, answer, hang up, and answer privately. Call Navigation  When the on-board navigation application is turned on, the navigation status display area displays the current navigation information.
  • Page 71 2. Instrument Cluster Driver assistance information  When the driving assistance system is turned on, the multi-function display area displays the driving assistance information interface. In the driving assistance information interface, you can query the status and alarms of the driving assistance system. Himalaya online ...

  • Page 72: Head Up Display

    2. Instrument Cluster Head up display* The head-up display is linked with the instrument and the system to provide driving assistance and audio entertainment information on the windshield where the driver is facing. Navigation system display area Display the next intersection information under the current navigation traffic conditions. Entertainment system display area Displays the currently playing radio, music, and phone information.
  • Page 73 2. Instrument Cluster Using the head up display Heads up display setting button  Press the key to enable the head-up display: press it again to disable the head-up display. Adjust up Raise the heightof the head-up display image. Adjust down Turn down the height of the head-up display image.
  • Page 74 2. Instrument Cluster...

  • Page 75: Operating The Components

    Operating the Components 3.1. Key information Key ..................74 3.2. Opening, closing and locking of doors and trunk lid Doors ..................77 Trunk lid ................81 Intelligent entry & start system .......... 85 3-3. Adjusting the Seats Front seats ................90 Rear seats ................

  • Page 76: Key

    3.1. Information on the Key The car comes with the following keys. Intelligent key* Passive entry & start system  (See P.85) Operating the wireless remote control function  Clip Passive entry & start system  (See P.83) Mechanical key Key number plate' Wireless remote control Unlock the doors by pressing the button, while open all...
  • Page 77 3.1. Information on the Key Use the mechanical key. Take out the mechanical key as shown in the figure. Put the mechanical key in the card key after using it. Carry the mechanical key together with the card key. If the battery of smart key or card key is fully discharged and cannot work normally, the mechanical key is required.
  • Page 78 3.1. Information on the Key Caution Prevent key damage  ●Do not subject the key to violent collision or expose it to high temperature (e.g. direct sunlight) and humid environment. Do not wet the key or clean it in equipment such as ultrasonic cleaner. ●...

  • Page 79: Doors

    3.2. Opening, Closing and Locking the Doors and Trunk Lid Doors Unlock and lock the door from the outside of the vehicle Smart entry  As long as you carry a smart key or a card key, you can unlock and lock the doors through the smart access function.
  • Page 80 3.2. Opening, Closing and Locking the Doors and Trunk Lid Mechanical key  Open the door keyhole cover using the mechanical key. Lock and unlock the vehicle using the mechanical key. Lock door Unlocking door  Operation signal All turn signals flash to indicate that the door has been locked/unlocked. (Locked: Once; Unlocked: Twice) ...
  • Page 81 3.2. Opening, Closing and Locking the Doors and Trunk Lid Unlock and lock the door from interior • The door can be unlocked and locked by the central door lock switch on the driver's door. Central control lock switch  Lock all doors Unlock all doors Note: When a door is not closed, the central control door lock switch can only be used to unlock but not to...
  • Page 82 3.2. Opening, Closing and Locking the Doors and Trunk Lid Locking at certain speeds  When all doors are closed and one door fails to be locked, the speed locking function is activated to lock all  doors when the vehicle speed exceeds about 20 km/h. Situations affecting smart entry and the start system and wireless remote control operations ...

  • Page 83: Trunk Lid

    3.2. Opening, Closing and Locking the Doors and Trunk Lid Trunk lid The trunk lid can be opened by using the trunk lid button, smart entry function and wireless remote control function. Opening the trunk lid Open the trunk lid from the inside of the car ...
  • Page 84 3.2. Opening, Closing and Locking the Doors and Trunk Lid Closing the trunk lid Trunk lid OFF button *  Press the trunk lid close button and the trunk lid is closed automatically. Trunk lid handle  Use the trunk lid handle to lower the trunk lid, and then press the trunk lid downward from outside to close it.
  • Page 85 3.2. Opening, Closing and Locking the Doors and Trunk Lid CAUTIONS When opening and closing the trunk lid, be careful to avoid being pinched by the trunk lid.  Before driving  ● Make sure the trunk lid is completely closed. If the trunk lid is not completely closed, it may accidentally open and bump into nearby objects during driving, or the luggage in the trunk may accidentally be thrown out, thus causing an accident.
  • Page 86 3.2. Opening, Closing and Locking the Doors and Trunk Lid CAUTIONS Use the trunk  Observe the following precautions: Otherwise, it may pinch some part of the body and cause serious injury. ● Before opening the trunk lid, remove the heavy load on the trunk lid, such as snow and ice. Otherwise, the trunk lid may suddenly close again.

  • Page 87: Intelligent Entry & Start System

    3.2. Opening, Closing and Locking the Doors and Trunk Lid Passive entry & start system As long as you carry a smart key or card key with you, for example, in your pocket, you can perform the following operations. (The driver must always carry the key with him) Note: This picture only takes the smart key as an example.
  • Page 88 3.2. Opening, Closing and Locking the Doors and Trunk Lid ■ Effective range (the zone which can detect the smart key) Effective range of the smart key antenna: A hemispherical area with a radius of about 1.2m (m) Sensing area inside Sensing area inside the vehicle around the induction antenna.
  • Page 89 3.2. Opening, Closing and Locking the Doors and Trunk Lid ■ Conditions impairing operation The passive entry & start system uses weak radio waves. In the following situations, the communication between the key and the vehicle may be affected, preventing the passive entry & start system and wireless remote control from operating properly.
  • Page 90 3.2. Opening, Closing and Locking the Doors and Trunk Lid ■ Operate system correctly Make sure to carry the key when operating the system. Do not get the key too close to the vehicle when  operating the system from the outside of the vehicle. Depending on the specific position of the key and how to hold it, the key signal may not be detected, ...
  • Page 91 3.2. Opening, Closing and Locking the Doors and Trunk Lid CAUTIONS Notes regarding the electronic devices interference  People who use implantable pacemakers, cardiac resynchronization therapy pacemakers or implantable cardioverter defibrillators should keep a proper distance from the antenna of smart access and activation system.

  • Page 92: Front Seats

    3.3. Adjusting the seat Front seat Adjustment steps  Driver side seat Waist support bulge Waist support pit Lumbar support moving upward* Lumbar support moving downward Seat shift forward Seat move back Seat front end up Seat front end down Seat up Seat down Seat backrest straight...
  • Page 93 3.3. Adjusting the seat CAUTIONS Seat adjustment  Do not tilt the seat too much while the vehicle is running to prevent the body from sliding out of the waist  belt. If the seat is tilted too much, the waist belt may slip over the hip and directly cross over the abdomen or the shoulder belt may touch the neck, which will increase the possibility of serious injury or even death in the event of an accident.

  • Page 94: Rear Seats

    3.3. Adjusting the seat Rear seats Adjust and fold the rear backrest Pull the left and right seat release handles on the rear seats to adjust and fold the rear backrest. Restore the backrest When returning the folded seat back to the upright position, you must hear a "click"...
  • Page 95 3.3. Adjusting the seat CAUTIONS Folding the rear seat back  Please observe the following precautions, otherwise serious personal injury or even death may result. Do not fold the seat back while driving.  Park the vehicle on a flat surface. Shift the gear lever to P position. Apply parking brake. ...

  • Page 96: Head Restraints

    3.3. Adjusting the seat Head restraints Upward Press and hold the left lock release button while pulling the head restraint upwards. Downward Press and hold the left lock release button while pushing the head restraint downwards. Lock release button  Remove the headrest Press and hold the left lock release button while pulling the head restraint upwards.
  • Page 97 3.3. Adjusting the seat Fold the wings of the headrest inward to a comfortable position. CAUTIONS Precautions for Headrest  Please observe the following cautions about the head restraint. Otherwise it may lead to serious personal injuries, or even death. Please use headrests specially designed for each seat.

  • Page 98: Seat Memory

    3.3. Adjusting the seat Seat memory* It can store the information of seats, steering wheel (for partial models), exterior mirrors and the key. Seat memory setting Memory setting: after adjusting the position of the seat, the steering wheel and the exterior rearview mirror, press any memory key (for more than 3s (seconds)) for a long time, release the key after hearing the instrument prompt, and the position information and current key...
  • Page 99 3.3. Adjusting the seat ■ Welcome function switch It can be set to turn on and off the greeting function in the vehicle setting of the audio system. (See P.224) ■ When automatically backing off: During the automatic return process, if the driver operates the steering wheel adjustment switch, the seat adjusting switch or the seat memory key, the steering wheel and/or seat return operation will be terminated.

  • Page 100: Steering Wheel

    3.4. Adjusting steering wheel and rearview mirror Steering wheel Adjusting the steering wheel The steering wheel can be adjusted to a comfortable position. ■ Power adjustment* Down Forward Backwards ■ Mechanical adjustment Release the steering wheel adjustment lever Adjust the steering wheel to a comfortable position Lock the steering wheel adjustment lever Steering wheel heating * Touch the steering wheel heating key, the indicator light...
  • Page 101 3.4. Adjusting steering wheel and rearview mirror Horn The horn can be sounded by pressing the horn logo or the surrounding area. CAUTIONS Precautions during driving  Do not adjust the steering wheel during driving, otherwise accidents may occur due to driver’s ...

  • Page 102: Anti-Glare Inner Rear View Mirror

    3.4. Adjusting steering wheel and rearview mirror Anti-glare inner rear view mirror Adjusting the interior rear-view mirror According to the driving posture, the rearview mirror can be adjusted up and down/left and right. The driver must adjust the interior rearview mirror to a suitable position so as to see the condition behind the car through the rear windshield.
  • Page 103 3.4. Adjusting steering wheel and rearview mirror Setting button Press the button once to enter the brightness adjustment mode. You can adjust the image brightness by pressing the / button Press the button twice to enter the height adjustment mode, and the image height can be adjusted through the / button CAUTIONS Precautions during driving...

  • Page 104: Exterior Mirrors

    3.4. Adjusting steering wheel and rearview mirror Body — Exterior mirror Adjust exterior rearview mirror When the engine switch is placed in "IG-ON" mode, the angle of the exterior rearview mirror can be adjusted. Turn the adjusting knob to select the rearview mirror to Step be adjusted.
  • Page 105 3.4. Adjusting steering wheel and rearview mirror Adjust exterior rearview mirror When the mirror fogs up, rotate the adjustment knob to the position with a heating label to heat the mirror. If it is not manually turned off, the heater will turn off automatically after running for about 10min (minutes).
  • Page 106 3.4. Adjusting steering wheel and rearview mirror CAUTIONS When driving ■ Observe the following precautions while driving. Otherwise, it may cause the driver to lose control of the vehicle and accidents to occur, resulting in serious injuries or even death. ●...

  • Page 107: Power Windows

    3.5. Opening and Closing Windows Power windows Opening and closing the power window Power window switch on the driver side  The power window switch on the driver side regulates other windows Manual UP/DOWN Pull/press the level 1 on the corresponding window switch (keep pulling/pressing), the window will be regulated up/down manually.
  • Page 108 2 seconds, then the initialisation process finishes. Please contact the FAW authorized Hongqi dealer if necessary. Anti-pinching function ...
  • Page 109 3.5. Opening and Closing Windows CAUTIONS Observe the following precautions when closing windows to avoid serious injury or even death:  ● Check and make sure that all passengers would not have any part of their bodies pinched when a window is being operated.

  • Page 110: Panorama Sunroof

    3.5. Opening and Closing Windows Panorama sunroof* The sunroof switch can be used to open and close the sunroof. Opening and closing Opening Press the switch when the sunroof is closed, the rear part of the sunroof is tilted up and the sunshade curtain opens partially.
  • Page 111 3.5. Opening and Closing Windows Operating condition for sunroof  The engine switch is in IG-ON mode. Initialization  ● Sunroof initialisation Initialization is required when the sunroof position is incorrect, the sunroof automatic function fails or the panoramic sunroof and sun visor linkage function fails. The initialization steps are as follows: place the engine switch in "IG-ON"...
  • Page 112 ● Confirm all functions of the sunroof after initialization. ● If unable to finish the initialisation, please contact the FAW authorized Hongqi dealer. Anti-pinching function  ● Never try to activate the anti-pinch function intentionally by having any body part pinched.

  • Page 113: Driving

    Driving 4-1. Before Driving Fixed speed cruise control* ....... 148 Driving a vehicle ..........112 Adaptive cruise control (ACC) function* ..151 Goods and luggage ..........118 Super Adaptive Cruise Control (SACC) function * ................157 Trailer towing ............. 119 Front and rear parking radar ......

  • Page 114: Before Driving

    4.1. Before Driving Driving a vehicle The following procedures should be observed to ensure safe driving. ■ Starting the engine (See P.121) ■ Driving Step Depress the brake pedal and operate the gear lever to switch to the D position. (see P.123) Step Release the electronic parking brake.
  • Page 115 4-1. Before Driving Moving off on a steep uphill When the gradient is too large and it is not suitable to use EPB hill start assist function, please operate the vehicle as follows: Step Depress the brake pedal firmly and change the shift lever to D. Make sure the gear indicator displays D.
  • Page 116 4.1. Before Driving CAUTIONS When starting the vehicle  Always keep your foot on the brake pedal while the vehicle stops with the engine operating. This prevents the vehicle from creeping. Precautions during driving  ● Do not drive if you are unfamiliar with the locations of the brake and accelerator pedals to avoid depressing the wrong pedal.
  • Page 117 4-1. Before Driving CAUTIONS When driving on slippery road surfaces  ● Sudden braking, acceleration and steering may cause tire spinning and reduce your ability to control the vehicle, resulting in an accident. ● The sudden changes in engine speed (e.g., engine braking caused by a downshift) may cause the vehicle to spin, thus causing an accident.
  • Page 118 The exhaust system should be checked from time to time. In case any tiny hole or crack caused by corrosion is found, or any connector is damaged, or abnormal exhaust noise is heard, connect with China FAW authorized Hongqi distributor to examine and repair the car. When taking a nap in the car ...
  • Page 119 ● Short circuit of electrical components. ● Engine damage due to flooding. In case water comes into the car, do contact with China FAW authorized Hongqi distributor to examine: ● Whether the braking function is normal. ● Engine oil and transmission oil.

  • Page 120: Goods And Luggage

    4.1. Before Driving Goods and luggage Take notice of the following information about storage precautions for goods and luggage. ● Try your best to store the goods and luggage in the trunk. ● Be sure all items are secured in place. ●...

  • Page 121: Trailer Towing

    4-1. Before Driving Trailer towing FAW recommends you not to tow the trailer by your vehicle, neither install towing device or tow wheel chair, small motorcycle and bicycles via towing device. Your vehicle is not designed for towing or as a mounting carrier for towing devices.

  • Page 122: Engine (Start) Switch

    4.2. Driving Specifications Engine (start) switch Start the engine or switch the engine (start) switch mode when carrying the smart key the or card key. Switch the engine (start) switch mode  When the brake pedal is released, the switch mode can be switched by pressing the engine (start) switch. (Each time the switch is pressed, the mode will be switched accordingly) OFF mode Light horn, position lights and hazard warning lights can...
  • Page 123 4.2. Driving Specifications Start the engine  Step Check that the gear lever is in the P or N position and the electronic parking brake has been applied. Step Sit in the driver's seat and firmly depress the brake pedal (the indicator lamp of the engine (start) switch is green).
  • Page 124 When starting the engine  ● Do not allow the engine to run at high speed in cold state. ● If the engine is difficult to start or flames out frequently, please contact the FAW authorized Hongqi Dealer to check the vehicle immediately.

  • Page 125: Transmission

    4.2. Driving Specifications Transmissions Select a gear position appropriate for driving conditions. Shift unlock button P gear button Gently operate the shift lever and ensure correct shifting. After each shift operation, release the shift lever to reset it. Move the gear lever ...
  • Page 126 4.2. Driving Specifications Gear switch  After starting the engine, change gears as follows. ● P switched to D: Press the brake pedal, press the release button, and operate the shift lever down to the first or second stroke. ● P to N: depress the brake pedal, press the unlocking button and operate the gear lever upward to the first section of travel.
  • Page 127 4.2. Driving Specifications Gear switch  Gear stage Function Parking Reversing Neutral Driving Manually up-shifting Manually down-shifting Shift descriptions ► P (parking) gear The P locks the transmission and prevents the wheels from turning. CAUTIONS When operating the shift lever for the first time ...
  • Page 128 4.2. Driving Specifications ► M (Manual) gear M gear is the manual shift mode. You can switch to the M position only when in the D position. When in the D gear position, move the gear lever to the left to enter the M gear range. Upshifting or downshifting between M1-M6 can be done by moving the shift lever or operating the shift paddle.
  • Page 129 4.2. Driving Specifications ► Upshift and downshift via the gear lever Up-shifting Down-shifting The selected gear will be shown on the multi-function display of the instrument cluster. Temporary manual mode  In the D gear mode, you can enter the temporary manual mode by turning the shift paddles, which can meet the functions of overtaking, power uphill, and engine braking.

  • Page 130: Driving Mode

    4.2. Driving Specifications Driving mode This vehicle is equipped with a driving mode switching system. It can provide different vehicle modes, and the vehicle has unique driving performance in different modes to meet the driver's needs. Driving mode switching Rotate the driving mode switch knob to switch the driving mode cyclically.
  • Page 131 4.2. Driving Specifications ● Both acceleration and fuel consumption are normal. ● The transmission gear shift is in default status. ● For AWD model, the driving mode is AWD. ● The steering is light. ● For vehicles equipped with intelligent shock absorber system, the shock absorber is relatively soft and highly comfortable.
  • Page 132 ● With the driving mode operating conditions met, if the driving mode system does not work, please immediately contact the authorized FAW HONGQI dealer to check. ● The driving mode is only a driving assist system and can't replace the driver's judgment on the driving...

  • Page 133: Turn Signal Lamp Control Handle

    4.2. Driving Specifications Turn signal lamp control handle Right turn signal lamp Left turn signal lamp Comfort flicker When control handle toggled non-self-locking position once, the left/right turn signal lights will blink three times; when the control handle is continuously toggled to the non-self-locking position, the left/right turn lights will continue flashing until the control handle is released.

  • Page 134: Electronic Parking Brake (Epb) System

    4.2. Driving Specifications Electronic parking brake (EPB) system Applying the EPB electronic parking brake (the indicator on) When the engine switch is placed in "IG-ON" mode, after depressing the brake pedal to confirm that the vehicle is stationary, lift the electronic parking brake switch upward to apply the electronic parking brake.
  • Page 135 Release the electronic parking brake completely. In the event of a failure (e.g. an electrical failure), the rear brake disc locked by the EPB can only be unlocked mechanically. It is recommended that you contact the FAW authorized Hongqi Dealer for the operation. ●...

  • Page 136: Auto Hold

    4.2. Driving Specifications AUTO HOLD When the AUTOHOLD function is standby, the vehicle’s auto hold will be activated when the brake pedal is depressed with the gear position in D or N to stop the vehicle. At this time, if the brake pedal is released.
  • Page 137 4.2. Driving Specifications ● Driver depresses the brake pedal until the vehicle is stopped, and then releases the brake pedal. CAUTIONS When parking on slippery road surfaces  If the tire's grip is exceeded, the AUTO HOLD automatic parking function cannot stop the vehicle. Do not use this system on slippery roads.

  • Page 138: Front Headlamp Switch

    4.3. Operating lights and wipers Headlamp switch Front position lamp, rear position lamp, license plate lamp and instrument panel backlights illuminate. Headlamps (dipped beam) and all the above lamps illuminate. Headlights (low beam), position lights, license plate lights turn on and off automatically Off.
  • Page 139 4.3. Operating lights and wipers ■ Rain & lamp sensor The sensor may not function properly if an object blocks the sensor, or anything affixed to the windshield blocks the sensor. Doing so interferes with the sensor detecting the ambient lamp intensity and may cause the automatic headlamp system and automatic wiper malfunctions.

  • Page 140: Operating Lights And Wipers

    4.3. Operating lights and wipers Intelligent high beam control (IHC) system* IHC intelligent high-beam control function can help drivers to switch between high beam and low beam automatically according to the surrounding road conditions. When the vehicle speed is greater than 50km/h, the intelligent high-beam control is activated, and the intelligent high-beam indicator of the combination instrument lights up;...
  • Page 141 4.3. Operating lights and wipers Under the following circumstances, the system may not be able to accurately detect the ambient brightness  level, which may cause the intelligent high-beam control system not to work properly. In this case, please switch between high beam and dipped beam manually. ●...

  • Page 142: Fog Lamp Switch

    4.3. Operating lights and wipers Fog lamp switch Fog lamps improve visibility under unfavorable driving conditions, such as rainy days or foggy days. The front fog lights are on. Turn on both front and rear fog lamps Operating conditions of fog lamps ...

  • Page 143: Front Windshield Wipers And Washer

    4-3. Operating lights and wipers Front windshield wipers and cleaners When the wiper control handle is in the AUTO position, if the light rain sensor detects rain, the wiper will move automatically. The system automatically adjusts the wiper speed according to rain volume and vehicle speed.
  • Page 144 4.3. Operating lights and wipers Cleaning / wiping operation Pull back the wiper control lever for cleaning the front windshield. Operating conditions of front windshield wiper and washer  The engine switch is in “IG-ON” mode and the engine compartment cover is closed. Rain &...
  • Page 145 4-3. Operating lights and wipers CAUTIONS Warning for using windshield wipers in AUTO mode  In AUTO mode, if the sensor is touched, the rearview mirror is strongly shaken or the windshield glass is strongly vibrated (e.g. knocking hard on the windshield), the windshield wiper may accidentally operate. Be careful not to pinch your finger or anything else by the windshield wiper.

  • Page 146: Rear Windshield Wiper And Washer

    4.3. Operating lights and wipers Rear windshield wiper and washer When the rear windshield wiper control handle is rotated to different positions, the wiper and washer can be operated: Off. Rear wiper ON. Cleaning operation. After the lever is released, it will automatically restore to the wiper position.

  • Page 147: Opening The Fuel Tank Lid

    4-4. Filling the Fuel Opening the fuel tank lid Perform the following steps to open the fuel tank lid. Before filling fuel  Depress the brake pedal, place the shift lever to the P position, apply parking brake, close the engine switch, and ensure that all doors and windows are closed.
  • Page 148 Fuel tank capacity  About 64 L When failing to open the filler cap  In the event of failure to open the filler cap due to low battery power or other reasons, please contact the FAW authorized Hongqi Dealer.
  • Page 149 4-4. Filling the Fuel CAUTIONS Filling fuel  Observe the following precautions while refuelling the vehicle: ●Static electricity that may be carried on the body needs to be removed before opening the filler cap and the fuel tank cover. When the body is charged, the fuel may catch fire due to discharge sparks, thus causing burns.

  • Page 150: Fixed Speed Cruise Control

    4-5. Use other driving system Constant speed cruise control* By cruise control, the vehicle can be maintained at the set speed without using the accelerator pedal, and the set speed is recommended not to exceed 130km/h. Setting the constant speed cruise Pull the cruise control handle backward to the Step "ON/OFF"...
  • Page 151 4-5. Use other driving system Adjusting the vehicle speed  Increasing the speed Short pushing: Pushing the lever once increases the speed by 5 km/h; Long pushing: Rapidly increasing the vehicle speed. If the lever is released, the speed shown on the multi- function display screen of the combination instrument is the target speed.
  • Page 152 Deactivate the constant speed cruise function, and then reactivate it again. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. please contact with China FAW authorized Hongqi distributor for check. CAUTIONS To ensure driving safety when setting the cruise speed, it is recommended not to exceed 130km/h.

  • Page 153: Adaptive Cruise Control (Acc) Function

    4-5. Use other driving system ACC adaptive cruise control function* ACC adaptive cruise function can comprehensively control the speed and the distance from the target vehicle within the speed range of 0~130km/h, thus reducing the burden on the driver and increasing the driving comfort.
  • Page 154 4-5. Use other driving system Adjusting the vehicle speed  Increasing the speed Short pushing: Pushing the lever once increases the speed by 5 km/h; Long pushing: After the system confirms the long pushing is valid, the speed continues to increase by 1 km/h.
  • Page 155 AEB/HDC/APA is activated. ● When the driving mode is switched among snow mode, off-road mode, and sand mode. ● System related function fault. ACC system fault  Have the FAW authorized Hongqi dealer check the vehicle if a fault has occurred.
  • Page 156 • Remove and install the camera unit of the advanced driver assistance system. • After adjusting wheel alignment. Please contact with China FAW authorized Hongqi distributors. CAUTIONS To ensure driving safety when setting the cruise speed, it is recommended not to exceed 130km/h. It is very dangerous to use the cruise function when driving at high speed, and the driver is recommended to drive actively.
  • Page 157 4-5. Use other driving system CAUTIONS If during ACC cruise control, when the vehicle is too close to the vehicle ahead (for example, due to  sudden emergency braking of the vehicle ahead), the system will send an audible and visual alarm to the driver through the instrument cluster.
  • Page 158 4-5. Use other driving system CAUTIONS If a vehicle in the adjacent lanes enters the front of the direction in which your vehicle moving but it  is not covered by the monitoring area, the system may not detect it, resulting in sluggish response of SACC.

  • Page 159: Super Adaptive Cruise Control (Sacc) Function

    4-5. Use other driving system Super Adaptive Cruise Control (SACC) function* SACC advanced cruise control is based on ACC adaptive cruise function. It can not only provide cruise and follow-up functions, but also identify lane lines through cameras of the advanced driving assistance system.
  • Page 160 4-5. Use other driving system Adjusting the vehicle speed  Increasing the speed Short pushing: Pushing the lever once increases the speed by 5 km/h; Long pushing: After the system confirms the long pushing is valid, the speed continues to increase by 1 km/h.
  • Page 161 4-5. Use other driving system Canceling the super cruise control Cancel Depress the brake pedal or push the cruise control handle forward to the "CANCEL" position and then release to cancel the cruise control. SACC and ACC switch setting  •...
  • Page 162 System related function fault. SACC system fault  Have the FAW authorized Hongqi dealer check the vehicle if a fault has occurred. After turning off the IGNITION switch  When turning off the IGNITION switch, the set cruise speed or headway will be deleted.
  • Page 163 4-5. Use other driving system CAUTIONS To avoid activating the SACC super adaptive cruise control by mistake  If this function is deactivated, ACC is canceled. Situations unsuitable for SACC  Do not use SACC in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
  • Page 164 4-5. Use other driving system CAUTIONS When the driver depresses the accelerator pedal to actively accelerate, the cruise speed icon  displayed on the multi-function screen of the instrument cluster will flash. This is a normal phenomenon. SACC may lose the target vehicle or misidentify the target vehicle when the vehicle enters or leaves ...
  • Page 165 4-5. Use other driving system CAUTIONS If a vehicle get in front from adjacent lanes but not in the sensor monitoring area, the system may  not be able to detect the vehicle, resulting in lagging of SACC response. Pay close attention to the vehicle movement in the adjacent lanes.

  • Page 166: Front And Rear Parking Radar

    4-5. Use other driving system Front and rear parking radar The front and rear parking radar system consists of a controller and an ultrasonic sensor. The ultrasonic sensor can measure the distance between the vehicle and the obstacle. According to the distance change of the obstacle entering the detection area, the speaker sounds at different frequencies, and the multimedia display screen will display the distance and orientation information of the obstacle.
  • Page 167 4-5. Use other driving system Display When obstacles are detected  If the PDC sensor detects an obstacle, an image is displayed on the multimedia display screen according to the obstacle position and the distance from the obstacle. The slow-driving zone, warning zone and danger zone are displayed in green, yellow and red, respectively.
  • Page 168 4-5. Use other driving system Information display on parking warning zone for center sensor  Distance to obstacle: 40～90cm If an obstacle is detected in this range, the yellow color bar on the multimedia display is lit and the speakers sound a warning to the driver.
  • Page 169 4-5. Use other driving system Longest distance detected by the sensor About 60cm About 150cm About 120cm The diagram shows the detection range of the sensors. (Note that the sensors cannot detect obstacles that are extremely close to the vehicle.) The range of the sensors may change depending on the shape of the obstacle.
  • Page 170 4-5. Use other driving system ● The shape of the obstacle may prevent the sensor from detecting it. Pay special attention to the following obstacles. • Wires, fences, ropes, etc. • Cotton, snow and other materials that absorb radio waves. •...

  • Page 171: Rear View Camera System

    4-5. Use other driving system Rear view camera system* When reversing (for example, parking), the rear view camera system assists you by displaying the vehicle rear view image on the audio multimedia display. Activating/deactivating the rear view camera system Activating ...
  • Page 172 4-5. Use other driving system Reversing information display Assist the driver to complete the parking with by screen display. Dynamically adjust the parking guide line according to various angles. Parking guide line Indicating the predicted vehicle track line with the steering wheel operating.
  • Page 173 4-5. Use other driving system Reversing camera The vehicle backup camera is located in the illustrated position. The area that the camera can monitor is limited. Objects that are close to either corner (within 20 cm) of the bumper or under the bumper cannot be seen on the About 20cm screen.
  • Page 174 4-5. Use other driving system Displaying the difference between the screen and the actual road Even if it seems that the distance between the auxiliary parking line and the left/right dividing line of the  parking space is the same, it may not be the same in practice and must be checked visually. Even if it seems that the close warning line and the auxiliary parking line are parallel to the dividing line of ...
  • Page 175 ● If the back of the vehicle has been hit, the camera’s position and mounting angle may have changed. please contact with China FAW authorized Hongqi distributor for check. ● If the temperature changes drastically, such as the vehicle is splashed with hot water in cold weather, the camera may not work properly.

  • Page 176: Panoramic Image System

    4-5. Use other driving system Panoramic image system* Panoramic image system is displayed by audio multi-media display screen, which is convenient for drivers to clearly see and understand the surrounding conditions of vehicles. At the same time, the relative orientation and distance of obstacles are judged to achieve safe and easy parking. Activating/deactivating the panoramic image system Activating ...
  • Page 177 4-5. Use other driving system Panoramic image system screen mode Panoramic image system has a variety of screen modes, the driver can choose the appropriate mode according to need. Main view Small bird's-eye view Front view Bird' s-eye Left Right view view view...
  • Page 178 4-5. Use other driving system Track line ⑨Track line When selected, the parking aid line will be displayed. MOD (Moving Object Detection) It can be selected in front and rear view modes. After enabled, it can detect dynamic objects within the range of 3m (meters) in front and rear of the vehicle and 3m (meters) in left and right.
  • Page 179 4-5. Use other driving system Panoramic camera Panoramic cameras are respectively installed at the front grille, trunk lid and left and right exterior rearview mirrors. If the above components are opened or folded, the splicing of pictures may fail. When the above components are opened or folded, there will be corresponding indication on the display screen.
  • Page 180 ● If the vehicle has been hit, the camera’s position and mounting angle may have changed. please contact with China FAW authorized Hongqi distributor for check. ● If the temperature changes drastically, such as the vehicle is splashed with hot water in cold weather, the camera may not work properly.

  • Page 181: Tire Pressure Monitor System (Tpms)

    4-5. Use other driving system Tire pressure monitor system (TPMS) The tire pressure monitoring system can monitor and check the tire pressure and give an alarm automatically when the pressure is lower than the limit value. Abnormal tire pressure/system fault warning lamp Tire pressure information System working conditions Vehicle status...
  • Page 182 4-5. Use other driving system CAUTIONS Precautions for tire pressure monitoring system <TPMS>  ● The system cannot prevent tire leakage and puncture. Its main function is to give an alarm after monitoring the tire pressure value below a certain set value. ●...

  • Page 183: Ldw/Lka Lane Keeping Assist System

    4-5. Use other driving system LDW/LKA Lane keeping assist system* The lane keep assist system can detect the driver's status and the driving state of the vehicle when the vehicle speed is higher than 60km/h. When the system judges that the driver's non-subjective intention (chatting, distraction, operating the sound system, etc.) causes the vehicle to deviate from the lane, the system will send out an alarm or an alarm plus a correction prompt to prevent danger or violations.
  • Page 184 The brightness of the external environment of the vehicle suddenly changes, such as entering the tunnel. The system shall be calibrated when changing the advanced driver assistance system camera unit,  front windshield or after four-wheel alignment. Otherwise, the system can not be used normally. Please contact with China FAW authorized Hongqi distributors.
  • Page 185 4-5. Use other driving system CAUTIONS LDW/LKA is only a driving assistance system. Do not rely too much on it. Drivers must drive  carefully. The system may malfunction due to road and environment factors. Stop using this system in that ...

  • Page 186: Driver Status Monitoring (Dsm)

     front windshield or after four-wheel alignment. Otherwise, the system can not be used normally. Please contact with China FAW authorized Hongqi distributors. CAUTIONS The driver status monitoring system is only a driving assistance system. It can only give an alarm ...

  • Page 187: Forward Collision Warning (Fcw) System

    FCW OFF is lit on the combination instrument. The system shall be calibrated when changing the advanced driver assistance system camera unit,  front windshield or after four-wheel alignment. Otherwise, the system can not be used normally. Please contact with China FAW authorized Hongqi distributors.
  • Page 188 4-5. Use other driving system CAUTIONS For the sake of safety, the passengers must wear seat belts properly.  FCW is only a driving assistance system. Do not rely too much on FCW. Drivers must drive  carefully. FCW only makes warning for collision danger. Driver must operate the brake pedal or the steering ...

  • Page 189: Autonomous Emergency Brake (Aeb) System

    The system is turned on by default. The system shall be calibrated when changing the advanced driver assistance system camera unit,  front windshield or after four-wheel alignment. Otherwise, the system can not be used normally. Please contact with China FAW authorized Hongqi distributors.
  • Page 190 4-5. Use other driving system CAUTIONS For the sake of safety, the passengers must wear seat belts properly.  AEB is only a driving assistance system. Do not rely too much on AEB. Drivers must drive carefully.  AEB may not be able to identify the modified or decorated vehicles with special appearance. ...
  • Page 191 4-5. Use other driving system Caution To prevent the system from disturbing the driver by false alarm, the following situations will not be  alarmed: ● Vehicle speed is lower than 8km/h. ● Within 20s after the last warning. After the AEB system is triggered, if any of the following conditions are met, the AEB system will be ...

  • Page 192: Blind Spot Detection (Bsd)

    4-5. Use other driving system Blind Spot Detection (BSD) * The system contains a blind spot detection, side warning assist (SWA) and a cross traffic alert (CTA) to provide driving assistance. Blind spot detection and side warning assist When the gear lever is in D position and the vehicle speed is greater than 30km/h, if the rear-side vehicle in the 7m (m) blind area or the 7 - 70m (m) interval behind the vehicle, the corresponding rear-view mirror warning...
  • Page 193 4-5. Use other driving system Blind area detection and lane change assist functions may not be activated or may be delayed in the  following situations: ● When the vehicle is driven on a steep slope. ● When the vehicle is driven through the mountain top or the mountain road. ●...
  • Page 194 4-5. Use other driving system Caution Be sure to prevent the rear bumper from being clashed when parking. Otherwise, the sensor in the  bumper may be displaced or damaged, and thus cause the SWA to be automatically shut down or the SWA function to be affected.
  • Page 195 4-5. Use other driving system CAUTIONS ■ Turn off the radar detection system when towing or accessories (such as bicycle bracket) are installed at the rear, otherwise, the radio waves emitted by the radar will be blocked, resulting in abnormal operation of the system. ■...

  • Page 196: Traffic Sign Recognition (Tsr)

    Please adjust or calibrate the TSR system under the following circumstances, otherwise the TSR system may not work properly • Front windshield is damaged or replaced. • After wheel alignment. • Replace the camera unit of the advanced driver assistance system. For calibration, contact the FAW authorized Hongqi dealer.
  • Page 197 4-5. Use other driving system CAUTIONS ■ TSR is only one of the driving assist systems. Do not depend on TSR more than necessary. Driver shall drive with caution. ■ The TSR may not work properly if there is heavy snow or rain. ■...

  • Page 198: Idling Start/Stop System

    4-5. Use other driving system Idling start/stop system The idling start-stop system refers to a system that controls the engine's idling start and stop during a short stop based on driving operation and system requirements. Idling start/stop system ON/OFF Press the idle start-stop system button, the idle start-stop indicator on the instrument cluster turns on, and the idle start-stop system turns off;...
  • Page 199 4-5. Use other driving system Start the engine  ● With your vehicle in D/N, the engine shut down and the brake pedal pressed, releasing the brake pedal starts the engine automatically. ● With your vehicle in P, the engine shut down, pressing the brake pedal or acceleration pedal again starts the engine automatically.
  • Page 200 4-5. Use other driving system ● Preconditions for starting the engine automatically The engine starts automatically if all the following conditions are met: • No-idling start/stop system corresponding fault. • The driver door is closed. • Engine compartment cover is closed. •...
  • Page 201 4-5. Use other driving system Caution After the engine stops automatically, press the engine switch, and the vehicle cannot start at this  time. When the vehicle is in the idle-stop state, the start-stop function is terminated if one of the following ...

  • Page 202: Auto Parking Assist (Apa)

    4-5. Use other driving system Auto Parking Assist (APA) * Automatic parking measures the length of parking spaces on both sides of the road through ultrasonic waves and cameras, selects suitable parking spaces, and then controls the vehicle to park automatically in the selected parking spaces.
  • Page 203 4-5. Use other driving system Auto in Select parking mode and space type  There are two parking modes of automatic parking and manual parking. In each mode, there are three types of parking spaces: vertical parking, inclined parking and horizontal parking.
  • Page 204 4-5. Use other driving system ■ Parking control After determining the target parking space, depress the brake pedal and touch the "Confirm Parking" button to park. During the parking process, must press and hold the unlock button on the shift handle until the vehicle is parked-in.
  • Page 205 4-5. Use other driving system ■ Exit control After selecting the type, depress the brake pedal and press the "Confirm Park" button to start the vehicle. During the exit process, must press and hold the unlock button on the shift handle until the vehicle exits. In the vehicle out process, if the gear lever unlocking key is released, the vehicle out will stop;...
  • Page 206 4-5. Use other driving system Caution The driver is the main operator of the vehicle. APA automatic parking system is only a driving  assistance system. The driver should control the vehicle according to the actual road conditions and drive carefully. In order to ensure the success rate and safety of the parking system, the system needs to be used in ...
  • Page 207 4-5. Use other driving system CAUTIONS ■ Pay special attention to the people animals, and various obstacles around the vehicle. The sensors have undetectable blind spots. ■ When looking for a parking space or during parking, make sure that there are no obstacles in the parking space, such as stones, thin pillars or drawbars, because the system may be not able to detect such obstacles.

  • Page 208: Driver Assistance System

    4-5. Use other driving system Driver assistance system Functions integrated by ESC (Electronic Stability Program), which may be different according to different vehicle models. To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. However, bear in mind that these functions are only for assistance and should not be excessively relied upon when driving the vehicle.
  • Page 209 4-5. Use other driving system Active Pre-Braking (ABP)*  When the brake pedal is pressed in an emergency, the response speed of the brake is improved. EPS electric power assisted steering  It uses motor to reduce the required force of turning steering wheel. When TCS/ESC are operating If the vehicle slips or the drive wheels are idling, the indicator flashes, indicating that TCS/ ESC is working.
  • Page 210 The ABS and EPS systems will not function correctly if different tires are installed on the vehicle. For details about replacement of tires or wheels, please contact with China FAW authorized Hongqi distributor.

  • Page 211: Driving Information Key Points For Driving In Winter

    4-6. Driving Information Key points for driving in winter Please make necessary preparation and inspection before driving in winter. Be sure to drive in a way that is suitable for the main weather conditions in winter. ■ Prepare to use oil suitable for outdoor temperature during winter driving. •...
  • Page 212 4-6. Driving information ■ Tire chain Please take the following precautions when installing or removing tire chains: • Install and remove tire chains in a safe location. • Install the chain on the driving tire. • Install tire chains following the instructions in the user manual of the tire chains. CAUTIONS ■...

  • Page 213: Audio System

    Using the hands-free system ......249 5-10. Bluetooth Telephone Using Bluetooth® phone ........252 5-11. Speech recognition Using the voice recognition function ....256 5-12. Mobile phone APP Using the mobile phone APP ......258 5-13. Hongqi Smart Connect Using Hongqi Smart Connect ......261...

  • Page 214: Multimedia Display

    You can quickly enter the system settings by touching or sliding down the status bar from the top of the screen. Enter Hong Qi smart link (see R261) Hongqi Smart Connect Touching the application icon can quickly access the QQ music and Himalaya.
  • Page 215 5.1. Basic Operation Information display screen The images shown in this manual are only for reference, and the actual images shown on the vehicle will prevail. ■ Splash screen Splash screen of the audio system. ■ Switch key The switch key is in the lower og message display. In the off state, short press to turn on;...
  • Page 216 FAW HONGQI. ● Do not repair, disassemble or modify the unit without authorization. In the case of malfunction, immediately shut down the audio system and contact the authorized dealer of FAW HONGQI.

  • Page 217: Multimedia Switch On The Steering Wheel

    5.1. Basic Operation Multimedia switch on the steering wheel Some multimedia features can be controlled using the multimedia switches on the steering wheel. Call answer key Call hang up key MOD button Voice recognition button Volume adjustment/mute button Features: To answer the phone through Bluetooth, press the phone application; when there is call in, press it to answer. If there is call out, in or talking, press this can hang up.

  • Page 218: Usb Interface

    5.1. Basic Operation USB interface Connect a USB device to the USB port, go to the corresponding mode, then you can operate it via the audio system. To use a USB1/USB2 port Open the front seat center storage box lid, and connect the external multimedia source.

  • Page 219: Settings

    5.2. Settings System settings Go to the main interface of system settings by tapping the button [System Settings] on the screen on the main menu interface. System Audiovisual Document settings settings management Mobile network Closing Bluetooth Closing Personal Closing hotspot Mobile phone Baidu CarLife interconnection...
  • Page 220 5.2. Settings Main interface of system settings System Audiovisual Document settings settings management Mobile network Closing Bluetooth Closing Personal Closing hotspot Mobile phone Baidu CarLife interconnection Mobile internet ■ Enable mobile network: access the network through the network environment created by built-in network card.
  • Page 221 5.2. Settings ■ Password setting: set personal hotspot to ON, enter the new password in the password setting interface and confirm to complete the password setting. Mobile phone interconnection You can choose how to connect to the phone by default. Voice recognition ■...
  • Page 222 5.2. Settings Audiovisual settings System Audiovisual Document settings settings management Automatic Mobile network Brightness Environment tone effect Night Music adjustment Music settings Theme mode It can be set to classic, sport and concise. Display mode It can be set to automatic, day or night modes. Brightness To adjust the screen brightness, touch the key [+] or [-] or drag the brightness setting bar.
  • Page 223 5.2. Settings Document management Through the file management, the user can view, search, play and delete the files in the media source. System Audiovisual Document settings settings management Local File holder Song 1.mp3 Video.mp4 16G available, 32G total Song 2.mp3 Shortcut menu In the open state of the audio system, above the screen status bar, slide down to pull out the shortcut menu, and check some functions quickly.

  • Page 224: Vehicle Settings

    5.2. Settings Vehicle setting In the main menu interface, touch [my car] to access the vehicle setting main interface. Vehicle setting main interface Calling..Lighting Driver Head up Maintenance, etc. Comfort setting setting assistance display Enter the lighting setting interface (see R223) Go to the Comfort Setting interface (see P.224) Go to the Driver Assistance interface (see P.225) Go to the Head Up Display interface (see P.226)
  • Page 225 5.3. Navigation Lighting setting Driver Head up Maintenance, etc. Lighting Comfort setting assistance display setting Daytime running lamp High beam assist Welcome lamp Boarding lighting Time (s) Air conditioner is Daytime running lamp Set DRL on/off. High beam assist Set the IHC On and Off. Welcome lamp Set LED board on/off.
  • Page 226 5.2. Settings Comfort setting Driver Head up Comfort setting Maintenance, etc. Lighting setting assistance display Safe unlocking Facilitate in and out Automatic folding of rearview mirrors Rear seat belt unfastened indicator lamp Mobile phone left reminding A/C off Safe unlocking Set safe unlocking on/off.
  • Page 227 5.3. Navigation Driver assistance Driver Head up Maintenance, etc. Lighting Comfort setting assistance display setting Smart speed restriction Speed limit reminder (km/h) Cruise mode Adaptive cruise control A/C off Smart speed restriction Set the road traffic mark identification system on/off. The default status is on. Speed restriction reminding Set the speed restriction reminding on/off.

  • Page 228: Navigation

    5.2. Settings Head up display Calling..Driver Head up Lighting setting Comfort setting Maintenance, etc. assistance display HUD brightness Cruise system Smart speed restriction reminding Navigation HUD brightness HUD brightness setting range: -1 (MO, default value is 0. Cruise system Set the cruise system display on / off.
  • Page 229 5.3. Navigation Maintenance, etc. Driver Head up Maintenance, etc. Lighting Comfort setting assistance display setting Remaining range Wiper repair position 5000km Remaining time - day Maintenance notification Mileage interval Time interval setting setting Average fuel consumption billing Unit price of fuel (RMB Yuan/L) A/C off Wiper repair position...

  • Page 230: Navigation

    5.3. Navigation Fundamental function Navigation map interface - Map mode interface  A/C off Main menu Touch to access the main menu interface. Current position Display the current vehicle position Status bar Touch to deploy the status bar information. Return Return audio system main interface.
  • Page 231 5.3. Navigation ■ Navigation mode interface A/C off Distance to next intersection and road name Display the remaining distance to the next intersection and the road name at the next intersection. Lane information Display the information of lane in which the vehicle is. Navigation status bar Touch to deploy the status bar information.

  • Page 232: Using The Navigation

    5.3. Navigation Using the navigation Main Menu Touch the screen key on the navigation interface to access the main menu interface. Favorites Off-line data Click logging in Synchronize search records with the phone and computer My car Enter the plate number and keep clear of limiting zone My messages No new message...
  • Page 233 5.3. Navigation Set destination - Users can set their destinations by searching POI (points of interest), name search, quick navigation, favorite spots, etc. The following is an example of name search. ■ Name searching Step In the map mode interface, touch [destination] to access the search interface. A/C off Step In the search interface, enter the destination and touch [search] to access the search result interface.
  • Page 234 5.3. Navigation Using the navigation Step In the route planning interface, select the appropriate route and touch [start navigation]. Route preference Shortest time 22 minutes, 8.9km 10 traffic lights Highway first 25 minutes, 10.0km Shortest distance 32 minutes, 7.7km Start navigation. A/C off Note: the billing information can be displayed online.
  • Page 235 China FAW. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated. Network connection quality  The quality of network connection will vary due to the continuous change of antenna position, the difference of signal strength and the influence of nearby objects (such as trains and transmitting stations).

  • Page 236: Radio

    5.4 Radio Using the radio Radio has two wave bands: FM and AM. Calling..Radio My music Bluetooth music Manually Save favorite stations modulating AM/FM button Radio preview button Sound field settings Mute/play key Favorite list/radio list button How to enter the radio screen: Method 1: touch [multi-media] on the screen and select [radio] to access My music.
  • Page 237 5.4. Radio Searching for channels Manually modulating  Touch/drag the frequency bar to carry out manual tuning. Manually searching  Manually search for channels by tapping the screen buttons Preview and select stations  Preview the stations through the screen key .
  • Page 238 It is difficult to maintain perfect reception at all times due to the continually changing position of the antenna, differences in signal strength and surrounding objects, such as trains and transmitters. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 239: Music

    5.5. Music My music play The audio play main interface includes the artist name, track name and album cover. Calling..Radio My music Bluetooth music Ode to the Hong Qi ... Shanghai Symphony Orchestra Track list Sound field settings Play mode Media source key Previous track button Next track button...
  • Page 240 5.4. Radio Play control ■ Pause/Play Tap the screen button ■ Play progress control Touch/drag the progress bar to adjust the playing progress (the progress bar cannot be adjusted when the media source is Bluetooth). ■ Switching tracks Swipe left or right to switch the cover of the track to select the previous / next track to play ■...
  • Page 241 5.5. Music Edit favorite list ■ Favorite list Delete a music: In the favorite list interface, click the screen button to enter the edit mode, select the music to be deleted in the list or click [Select All] button on the screen and click the screen button to delete the selected music.
  • Page 242 A poor quality USB device will cause the system to fail to recognize it. It is recommended to use a better quality USB device. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 243: Bluetooth Music Bluetooth Music Play

    5.6. Bluetooth Music Bluetooth music play The system supports Bluetooth music play, and you can go to the Bluetooth music play interface by starting the Bluetooth music. You can control the play via the buttons on the Bluetooth music play interfaces.
  • Page 244 5.6. Bluetooth Music Play control ■ Pause/Play Tap the screen button ■ Switching tracks Touch the on - screen button and both can select up/down tracks to play. CAUTIONS ■ Reduce the possibility of traffic accidents ● While driving, avoid operating this system as far as possible. ●...

  • Page 245: Video

    Previous video key Next video key Pause/play button Method to access video interface: touch the screen key [HONGQI SMART LINK], select [video] to access the video media source list interface and select the video to play to access the video play interface.
  • Page 246 5.7. Video Play control ■ Pause/Play Tap the screen button ■ Fast backward/fast forward By tapping/dragging the progress bar, you can control the play progress. Sliding on the screen side to side will control the play progress. ■ Adjust the volume On the screen right side, sliding up and down can regulate the volume.
  • Page 247 A poor quality USB device will cause the system to fail to recognize it. It is recommended to use a better quality USB device. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 248: Images

    5.8. Images Image viewing When a USB device with image files is connected, you can view images in the multimedia display. Slide key Delete key Knob key How to enter the picture viewing interface: press the screen button "Hong Qi Intelligence Link" and select "Picture"...
  • Page 249 5.8. Images Image viewing ■ Slide play Touch the screen button ► to enter slideshow mode. In slide mode, the image cannot be magnified or reduced. ■ Image zoom in/zoom out The image can be magnified and reduced by the double-finger scaling. ■...
  • Page 250 A poor quality USB device will cause the system to fail to recognize it. It is recommended to use a better quality USB device. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 251: Hands-Free System

    5.9. Hands-free System Using the hands-free system The hands-free system allows you to use the phone call function of a mobile telephone without touching The system supports Bluetooth® mobile phones. Bluetooth® is a wireless data system that enables a mobile phone to wirelessly connect with a hands-free system to make/receive calls.
  • Page 252 5.9. Hands-free System ■ Bluetooth microphone Make the other party hear the sound. ■ When using the hands-free system ● The audio system will be muted when making a call. ● If both parties speak at the same time, it may be difficult to hear. ●...
  • Page 253  Do not leave your mobile telephone behind in the vehicle, which would be damaged because of temperature increase in the vehicle. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 254: Bluetooth Telephone

    The system supports the functions of making and receiving calls, hanging up, checking the contacts, checking the call history, etc. Dial Call history Contacts Teacher Zhang 1332332**** Hongqi service 1332333**** Unknown Dial out button Recent call history Dialpad There are two methods to enter into the Telephone interface: Method 1: Connect Bluetooth and press the button on the steering wheel to enter the phone interface.
  • Page 255 5.10. Bluetooth Telephone Contacts ■ Save contacts After the mobile telephone is bound to the Bluetooth system successfully, the system will automatically download the contact information from the bound telephone. Mobile phones can store up to 4 Bluetooth device contact lists. ■...
  • Page 256 Method 3: search the contact through the contact interface screen key and dial. Answering/ending the incoming call When there is an incoming call, the caller ID will pop up. Hongqi service Incoming call..Answer button Private button End phone call button...
  • Page 257  Do not leave your mobile telephone behind in the vehicle, which would be damaged because of temperature increase in the vehicle. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 258: Using The Voice Recognition Function

    5.11. Voice Recognition Using the voice recognition function Users can achieve voice control to the system via the voice recognition function. Voice control functions include: radio, music, Bluetooth telephone, navigation and A/C control. Voice recognition triggering Methods Press the steering wheel key to trigger the speech recognition system.
  • Page 259 5.11. Voice Recognition Voice recognition exit Method 1: After triggering the voice recognition system, the system will automatically exit the voice recognition if there is no identifiable instruction. Method 2: The voice recognition is exited after the normal execution of voice command is completed. Method 3: After triggering the speech recognition system, if the input command is invalid, the speech system will give a prompt.

  • Page 260: Mobile Phone App

    Open the logged - in mobile phone on - board Internet APP and enter the APP homepage. My vehicle Information viewing: You can view the driving behavior Hongqi HS5 analysis, navigation, health manager and electronic Remaining oil 1L Residual traffic 0MB...
  • Page 261 ■ APP downloading About the downloading and installation of the mobile APP, please ask the FAW authorized Hongqi dealer. ■ Login information Users will provide their personal information to dealers for real name authentication, and the system will give the APP login information and the PIN information on vehicle control to the user after the real name authentication;...
  • Page 262 When using APPs, some functions need to be given corresponding limits, and ensure that third-party tools do not prohibit the network limits of APPs, otherwise the system may not work properly. When Failure Arises  Contact the FAW authorized Hongqi Dealer if the fault still can not be eliminated.

  • Page 263: Hongqi Smart Connect

    5.13. Hongqi Smart Connect Using the Hongqi Smart Connect The system can operate additional extended functions like Baidu CarLife, road rescue, information consultation and Hong qi micro-application, etc. Calling..QQ music Video Image Himalaya Hong qi micro Electronic Baidu CarLife...
  • Page 264 5.13. Hongqi Smart Connect Roadside Assistance When the vehicle is in trouble and needs emergency rescue, the user can contact the rescue service through road rescue (B-Call). Roadside Assistance Calling…… When the background receives the user's rescue request, the rescue service will be properly arranged to solve the troubles for user.
  • Page 265 5.13. Hongqi Smart Connect Hong qi micro application Users can inquire about information, weather, violation, etc. through the Hong Qi applications, and can inquire about traffic and purchase. Traffic query Traffic Violation Message Beijing and purchase Information Northwest wind level 3 Select the content on the screen to enter the corresponding interface, operate and use as per the system prompts.
  • Page 266 5.13. Hongqi Smart Connect QQ music/Himalaya QQ Music/Himalaya can provide users with comfortable and convenient personalized services to improve driving pleasure. ■ QQ music Calling..Recom Ranking list Type mend ■ Himalaya Home Type Broadc Page playing Select the content on the screen to enter the corresponding interface, operate and use as per the system...
  • Page 267 5.13. Hongqi Smart Connect Stop quick payment Users can pay for parking quickly by stopping the quick payment. Please enter your destination Nearest distance Select the content on the screen to enter the corresponding interface, operate and use as per the system prompts.
  • Page 268 5.13. Hongqi Smart Connect Electronic manual Electronic manual Calling..Please enter the keyword you want to search for. Phantom Quick start black Highlight Peacock blue Catalogue Clear gold Emergency Titanium white Profile Select the content on the screen to enter the corresponding interface, operate and use as per the system prompts.
  • Page 269 ● If the foreign matter or water falls into this system and result in abnormal situation, immediately stop using and contact the authorized dealer of FAW HONGQI. If it continues to be used, it may lead to failure. ● Do not use it when the screen is not displayed or no sound is produced.
  • Page 270 5.13. Hongqi Smart Connect Caution The speech recognition results are for reference only.  Please use standard and clear Putonghua and avoid using it in noisy environment to avoid incorrect  results. Try to avoid using voice recognition when driving. If using voice recognition, please try to avoid ...

  • Page 271: Interior Equipment

    Interior Equipment 6-1. Using the A/C System • Cup holder ............287 Fully automatic air conditioning system..270 • Bottle rack and sundry bucket ....... 288 · Using the automatic A/C system ....272 • Document pocket ..........288 • Manual adjustment setting ......273 •...

  • Page 272: Fully Automatic Air Conditioning System

    6.1 Using the A/C System Fully automatic A/C system This vehicle is equipped with the dual-zone A/C system, which can set the interior temperature according to passengers in the vehicle by combining with the current interior temperature, environment temperature, sunlight intensity, vehicle speed, water temperature and other environmental parameters;...
  • Page 273 6.1. Using the A/C System ► Air conditioning operation interface of central control panel Driver side temperature setting button Driver side temperature display AUTO button Front windshield defroster/defogger button Windshield heating button Air volume increase button Front passenger side temperature display Front passenger side temperature setting key Air volume decrease button Internal/external circulation button...

  • Page 274: Using The A/C System

    6.1 Using the A/C System Using the automatic A/C system Method 1: Touch the [AUTO] button on the multimedia display screen, and the indicator turns on to enter the automatic air conditioning mode. Method 1: Touch the [AUTO] button on the multimedia display screen, and the indicator turns on to enter the automatic air conditioning mode.

  • Page 275: Manual Adjustment Setting

    6.1. Using the A/C System Manual regulation ■ Regulation of air volume Method 1-: After touching [AUTO] button on the multimedia display, its operating indicator lights up and the automatic A/C mode is activated. Method 2: Touch the air volume setting button on the central control panel to adjust the air volume among levels 1 - 7.
  • Page 276 6.1 Using the A/C System ■ Switching of single/dual-zone control modes Touch the [SYNC] key, and the indicator light will turn on. Enter the single temperature zone control mode, and the front passenger side will synchronize to the temperature set by the driver side. By tapping the [SYNC] button again, the indicator goes out, it goes to the dual-zone control mode, and you can independently set the temperatures at the driver's side...
  • Page 277 6.1. Using the A/C System The airflow is blowing toward the face and feet. The airflow is blowing toward the feet and the windshield. Air is blown to the front windshield. Automatically start the front windshield defrost/defog mode. ■ A/C switch When the engine is running, by taping [A/C] button, the button is on, and the A/C refrigeration starts.

  • Page 278: Other Functions

    6.1 Using the A/C System CAUTIONS ■ Do not use the internal circulation mode in cold or rainy weather Using the internal circulation mode in cold or rainy weather will lead to fogging of the car windows, thus blocking your sight and possibly causing serious accidents. ■...
  • Page 279 6.1. Using the A/C System ADS anti-fog sensor At the running state of air conditioner, when the windshield has a fogging tendency, A/C system will enter the automatic anti-fogging mode, and the air volume will be appropriately increased and blow towards the windshield;...

  • Page 280: Adjust The Air Outlet Direction And Open And Close The Air Vents

    6.1 Using the A/C System ■ AQS air quality sensor The system automatically detects the air quality outside the car. When the outside air is polluted, the air conditioning system automatically switches to internal circulation, and prevents polluted air from entering the car to ensure the air quality inside the car.
  • Page 281 6.1. Using the A/C System ■ Remote operation of air conditioning system ● A/C system can be operated remotely via the mobile APP. (See P.258) ● When the vehicle is started remotely and the remote air conditioner is turned on at the same time, the air conditioner operation panel cannot be operated because the air conditioner is in the remote mode, but the remote air conditioner can be turned off through the OFF button.

  • Page 282: Windshield Heating

    6.1 Using the A/C System Windshield heating Touch the key. The indicator turns on to start heating the rear windshield and the front windshield. By tapping the button again, the indicator goes out and the system stops to work. Tip: The system will automatically shut down after running for about 15min (minutes), and the system indicator turns off.

  • Page 283: Using The Interior Lamps

    6.2. Using the Interior Lamps List of interior lamps Front interior lights (see P.282) Welcome lamp Front reading lights (see P.282) Vanity mirror lamp (see P.283) Rear reading lights (see P.283) Trunk lamp Ambient lamp (see P.223) Sundries box lamp...

  • Page 284: Front Row Of Interior Lights

    6.2. Using the Interior Lamps Front row of interior lights By pressing the button, turn on the front room lamp; by pressing it again, turn off the front room lamp. By pressing the button, the indicator is on, and the Door Linkage with the room lamp is turned on;...

  • Page 285: Rear Reading Light

    6.2. Using the Interior Lamps Rear reading lamp By pressing the button, turn on the rear map lamp; by pressing it again, turn off the rear map lamp. Vanity mirror lamp By opening the sun visor and sliding open the vanity mirror cover, the vanity mirror lamp is ON.

  • Page 286: Using The Storage Units

    6.3. Using the Storage Units List of storage units Eyeglasses box (see P.289) Bottle rack and sundry bucket (see P.288) Left lower guard plate sundries box (see P.286) Glove box (see P.285) Cup holders (Front/Rear) (see P.295) Front central storage box (see P.286) File pocket (see P.288)

  • Page 287: Glove Box

    6.3. Using the Storage Units Glove box By pulling the handle, open the glove box. When closing the glove box cover, it means securely locked when it “clicks”. CAUTIONS ■ Warning during driving Keep the glove box closed. Otherwise, personnel may be injured in case of accident or emergency braking.

  • Page 288: Front Central Storage Box

    6.3-4. Using the Storage Units Front central storage box Lift the storage box cover to open the storage box. CAUTIONS ■ Warning during driving Keep the storage compartment closed. Otherwise, personnel may be injured in case of accident or emergency braking. Left lower panel glove box By pulling the handle, open the glove box.

  • Page 289: Cup Holder

    6.3. Using the Storage Units Cup Holder  Front Press the cup holder cover downward, and the cup holder cover will open automatically.  Rear Put down the rear center armrest, take down and release the cup holder cover, and the rear cup holder will pop out automatically.

  • Page 290: Bottle Rack And Sundry Bucket

    6.3-4. Using the Storage Units Bottleholder and side pocket Bottleholders and side pockets are located on doors, and used to place bottles, duster cloth or sundries. When placing bottles, tighten their lids. Some bottles might not be held there because of their size or shape.

  • Page 291: Glasses Box

    6.3. Using the Storage Units Eyeglasses box Pull down the lower case lid edge, the eyeglasses box will open downward. It is used to temporarily store small items such as sunglasses. CAUTIONS ■ Items that should not be stored in the glasses box Do not leave the glasses or lamper on it for long.

  • Page 292: Trunk Device

    6.3. Using the Storage Units Trunk appliance Trunk hook Lift the hook for immediate use. The cargo hook is used to secure loose items. CAUTIONS ■ Always return the goods to the stowed position when not in use. Trunk string bag Luggage net pockets are located on both sides of the luggage compartment.

  • Page 293: Other Interior Equipment On-Board Wireless Charging

    6.4. Other interior equipment On-board wireless charging* The front of the central console box is equipped with a wireless charging system. Phones that support Qi standard wireless charging can be placed directly in the wireless charging area for charging. Wireless charging indicator Phones that do not support Qi standard wireless charging need to be charged with a receiver.

  • Page 294: Sun Visor

    6.4. Other Interior Equipment Sun visor Forward position Flip the sun visor down. Side position Flip down the sun visor, unhook, and pull to the side.

  • Page 295: Paper Holder

    6.4. Other interior equipment File holder The file holder is located on the visor at the driver's side. It is used to store receipts, cards and other items. Caution Prevent holder damage  Do not put too many items on the file holder.

  • Page 296: Vanity Mirror

    6.4. Other Interior Equipment Vanity mirror lamp Flip down, and slide the cover to open the vanity mirror. Caution When not in use  Keep the makeup mirror closed. Prevent low battery power  When the vehicle is not started, do not turn on the makeup mirror lamp for a long time.

  • Page 297: Cigarette Lighter

    6.4. Other interior equipment Cigar lighter Press down on the front cup holder cover and open it to connect the cigarette lighter. The cigarette lighter will pop up after it has been properly preheated. ■ The cigarette lighter can be used when The engine switch is placed in "IG-ON"...

  • Page 298: Power Socket

    6.4. Other Interior Equipment Power Socket ■ 12V power The power socket can be used for 12V accessories that run on less than 10A. Located at the lower end of the rear central outlet. Located on the right trim panel of the trunk. ■...
  • Page 299 6.4. Other interior equipment ■ The power sockets can be used when The engine switch is placed in "IG-ON" mode - Caution Prevent the power socket from being damaged.  Close the power socket lid when the power socket is not in use. Foreign objects or liquids that enter the power socket may cause a short circuit.

  • Page 300: Seat Temperature Control

    6.4. Other Interior Equipment Seat temperature control* The temperature of the seats can be adjusted separately. ■ Front seat temperature adjusting Press the seat heating and ventilation button to select the appropriate gear. Level 1-3 adjustment can be realized. ■ Rear seat temperature adjusting By pressing the seat heating button, the indicator is on;...
  • Page 301 6.4. Other interior equipment CAUTIONS ■ When using the seat heater, be sure to observe the following. ● Special attention should be paid to the following persons sitting in a seat with the seat heater operating, to avoid burns:  Babies, children, the elderly, patients and people with disabilities ...

  • Page 302: Rear Center Armrest

    6.4. Other Interior Equipment Rear central armrest Pull down the armrest to use. Caution Prevent handrail damage  Do not place too much strain on the armrest.

  • Page 303: Roof Grab Handle

    6.4. Other interior equipment Roof grab handle The roof handles are located on the front passenger side and both sides of passengers. When sitting on the seat, the body can be supported by the roof handles installed on the roof lining. CAUTIONS ■...

  • Page 304: Coat Hook

    6.4. Other Interior Equipment Coat Hook Hang clothes on coat hooks. CAUTIONS ■ Items not suitable for hanging on coat hooks Do not place hangers or other hard or sharp objects on the coat hook. If curtain airbags are deployed, these objects may be ejected and cause serious injury or death.

  • Page 305: Maintenance

    Maintenance 7-1. Maintenance and Servicing Cleaning and protecting vehicle exterior trim 304 Cleaning and protecting vehicle interior trim . 306 7-2. Maintenance Maintenance instructions ........308 7-3. Do-It-Yourself Maintenance Precautions for do-it-yourself maintenance ..310 Hood ..............312 Engine compartment ......... 313 Tire ..............

  • Page 306: Cleaning And Protecting Vehicle Exterior Trim

    7-1. Service and maintenance Cleaning and protecting vehicle exterior trim Observing the following operations helps to protect the vehicle exterior trim and keep it in the best condition:  Flush the body, wheel cap and bottom of the vehicle with large amount of water from top to bottom to remove dirt and dust.
  • Page 307 7.1. Maintenance and Servicing Caution ■ Prevent aging of body, aging of paint and corrosion of body and components (aluminum wheels, etc.) The vehicle shall be cleaned immediately after the following situations occur:  • After driving along the seaside. •...

  • Page 308: Cleaning And Protecting Vehicle Interior Trim

    7-1. Service and maintenance Cleaning and protecting vehicle interior trim Observing the following operations helps to protect the vehicle interior trim and keep it in the best condition: ■ Protecting vehicle interiors Use a vacuum cleaner to remove dirt and dust. Wet the cloth with warm water and wipe off the dirty. ■...
  • Page 309 7.1. Maintenance and Servicing CAUTIONS ■ Prevent water from entering the car Do not spill liquid into the car, otherwise it may lead to failure of electrical components or fire.  Do not allow air bag components or wires inside the vehicle to get wet. ...

  • Page 310: Maintenance Instructions

    Even if you are an experienced professional technician, we still suggest that you go to an FAW authorized Hongqi Dealer for standard maintenance because they will record the maintenance information of your car and help you apply for warranty service.
  • Page 311 The engine coolant temperature continues to be high.  If you find any of the above signs, please contact an FAW authorized Hongqi Dealer as soon as possible because your vehicle may need to be adjusted or repaired. CAUTIONS ■...

  • Page 312: Precautions For Do-It-Yourself Maintenance

    7-3. Maintenance for user Precautions for do-it-yourself maintenance You can perform maintenance by yourself. Please be sure to follow the correct procedures below. Item Components and tools • Warm water • Baking soda Battery condition (see P.322) • Grease • Conventional wrench (for terminal clamping bolts) •...
  • Page 313 When the brake pads are worn or the fluid level in the brake fluid tank is high, the brake fluid level drops slightly. This is normal. If brake fluid needs to be frequently added to the brake fluid tank, it indicates that there may be a serious problem. Please contact your FAW authorized Hongqi Dealer to have your vehicle checked.

  • Page 314: Hood

    7-3. Maintenance for user Engine compartment cover Unlock inside to open the engine compartment cover. Pull opening handle of the engine compartment Step cover. The engine compartment cover will bounce slightly upwards. Dial up the opening handle of the safety hook of the Step hood and then lift up the hood.

  • Page 315: Engine Compartment

    7-3. Do-It-Yourself Maintenance Engine compartment Washer fluid tank (see P.325) Coolant reservoir (see P.318 ) The dipstick (see P.315) Machine oil filler cap (see P.316) Brake fluid tank (see P.320) Battery (see P.322) Condenser (see P.319) Fuse box (see P.336) Radiator (see P.319) Cooling fan Intercooler (see P.319)
  • Page 316 7-3. Maintenance for user Engine compartment trim cover Remove the engine compartment trim cover ■ ■ Install the clips...
  • Page 317 7-3. Do-It-Yourself Maintenance Engine oil Check the oil level when the engine reaches operating temperature and the engine switch is turned off. ■ Check the oil Step Place the vehicle on the level ground. After shutting down the engine, wait 5 minutes or more for the oil to return to the bottom of the engine.
  • Page 318 7-3. Maintenance for user ■ Fill the oil Add oil of the same rating as the existing oil in the engine if the level is at or below the lower mark. Be sure to determine the oil grade and prepare the required items before adding oil. Step Unscrew the oil filler cap counterclockwise and remove it.
  • Page 319 For information about oil recovery and disposal, please consult the China FAW authorized Hongqi distributor. Please do not place the used oil in places where children can reach.
  • Page 320 If the coolant level drops soon after refilling ■ Visual inspection of radiators, liquid storage tank lids, water pipes and etc. is required. If no leakage is detected, please contact your FAW authorized Hongqi dealer to check the cooling system for leaks. ■...
  • Page 321 7-3. Do-It-Yourself Maintenance CAUTIONS ■When the engine is in hot condition When the engine is hot, do not add to it with coolant. The hot engine can be very dangerous. If the engine  has ever run, the engine compartment can become extremely hot and seriously scald you. Do not remove the coolant reservoir cap and radiator cap.
  • Page 322 7-3. Maintenance for user Turbocharged engine When the inspecting, removing, and replacing of the turbocharger is required, it must be performed after the  engine is stopped and the turbocharger has cooled down. Do not drop any oil on the hot surface of the turbocharger, as this may cause a fire. ...
  • Page 323 7-3. Do-It-Yourself Maintenance CAUTIONS ■ Recautions about brake fluid adding It is very dangerous when the brake fluid is spilled. If brake fluid gets into your eyes, rinse immediately  with plenty of water and seek medical attention as soon as possible. Be careful not to spill brake fluid on your body or electrical components in the engine compartment.
  • Page 324 7-3. Maintenance for user Battery ■ Power Management System When the battery runs down, some comfort functions may be limited and disabled to ensure vehicle startability. When the battery power is restored to the safe range, the above comfort type functions will be automatically restored to the user's set operating state to function.
  • Page 325 7-3. Do-It-Yourself Maintenance ■ Before charging Pay attention to the following matters before charging: If the in-vehicle battery is to be charged, be sure to turn off the engine switch and disconnect the grounding  wire. Make sure the power switch on the charger is turned off when connecting/ disconnecting the charger cable ...
  • Page 326 7-3. Maintenance for user CAUTIONS ■ Chemicals in the battery The battery has toxic corrosive sulphuric acid and may lead to combustible and explosive hydrogen. To reduce the chance of serious personal injury, observe the following requirements when handling the battery or working near it: Do not touch the battery terminals with tools to avoid sparks.
  • Page 327 7-3. Do-It-Yourself Maintenance Washer fluid If any cleaner does not work or a message appears on the multi-function display of the instrument cluster, the cleaning fluid reservoir may be empty. Please add the cleaning solution in time. CAUTIONS When adding cleaning solution ■...

  • Page 328: Tire

    1. The spare tire is a non-full-sized spare tire, which cannot be used for tire rotation but temporary use. 2. No spare tires have tire pressure monitoring sensors. 3. If tire rotation finishes, configure the tire pressure monitoring system. Contact your FAW authorized Hongqi Dealer if necessary.
  • Page 329 7-3. Do-It-Yourself Maintenance Protective measures for wheel malfunction ■ When encountering curbs or similar obstacles, the vehicle should drive as slowly as possible parallel to the  obstacles. Be careful not to let the tires come into contact with grease, oil and fuel. ...
  • Page 330 7-3. Maintenance for user CAUTIONS ■ Precautions for inspecting or replacing tires To avoid damage to the components of the drive train and affecting the handling performance of the vehicle, which may cause accidents and serious personal injuries, follow the following precautions: Do not mix tires with different manufacturers, models, tread patterns or tread wear degrees.

  • Page 331: Tire Pressure

    7-3. Do-It-Yourself Maintenance Tire pressure Be sure to maintain proper pressure in the tires. Check the tire pressure once per month at least. A tire pressure label is attached under the B-pillar lock of driver side. Consequences of incorrect tire pressure ■...
  • Page 332 7-3. Maintenance for user CAUTIONS ■ Proper inflation is the key to protecting the tires Be sure to maintain proper tire pressure. Failure to do so may cause one of the following conditions: Excessive wear * Uneven wear * Poor handling ...

  • Page 333: Wheel

    When replacing a wheel, take care to ensure that the replacement wheel has the same load carrying capacity, diameter, rim width and offset distance as the original wheel. Contact FAW authorized Hongqi dealer for alternative wheels. The following wheels are not recommended by China FAW: ...

  • Page 334: Air Conditioning Filter

    7-3. Maintenance for user Air-conditioning filter Air conditioning filters must be replaced regularly to maintain air conditioning performance. ■ Replace the air conditioner filter Step Turn the IGNITION switch OFF. Open the glove box. Step Remove the plastic fixing bolts on the left and right sides of the sundries box, disengage the limiter and flip the sundries box downward to the location where filter can be taken out.
  • Page 335 If the airflow in the vent is significantly reduced The filter may be clogged. Check the filter, and replace it if necessary. ■ A/C filter If the filter needs to be cleaned or replaced, please contact FAW authorized Hongqi dealer. Caution When using the A/C system ■...

  • Page 336: Replace Key Battery

    7-3. Maintenance for user Replace the key battery If the smart key or card key battery is low, replace it with a new battery. ■ The following items are required:  Lithium cell ■ Replace the smart key battery Disengage the key shell. Step Remove the used battery from key panel.
  • Page 337 Passive start function fails.  ■ Use lithium battery It is suggested that same or equivalent products recommended by the China FAW authorized Hongqi  distributor can be used for replacement. Battery model for the smart key: CR2032 Battery model for the card key: CR2016 Old batteries must be disposed of according to local regulations.

  • Page 338: Check And Replace Fuse

    Engine compartment (type B) Press the tabs and open the fuse box lid. Right front threshold decorative panel ■ Remove the front right door sill trim board. When replacing the fuse here, contact the FAW authorized Hongqi dealer for replacement.
  • Page 339 7-3. Do-It-Yourself Maintenance Step If there is a trouble in the system, contact FAW authorized Hongqi dealer for specific instructions on which fuses to check. Remove the fuse with the fuse puller. Step Step Check whether the fuse is blown or not.
  • Page 340 Failure to follow the precautions below may result in serious damage / fire to the vehicle or personal injury. Never use fuses higher or lower than the rated amperage.  Make sure to use the same or equivalent products recommended by the China FAW authorized Hongqi  distributor.

  • Page 341: When Failure Arises

    When Failure Arises 8-1. Important information Hazard warning lamps ........340 SOS warning ............341 8-2. Measures to Be Taken in Emergencies If the vehicle needs to be towed ......342 If any abnormality is found on the vehicle ..347 If a warning lamp turns on or a warning buzzer sounds ..............

  • Page 342: Hazard Warning Lamps

    8-1. Essential Information Hazard warning flashers When the vehicle fails, stop by the roadside while using the hazard warning lights; when the vehicle cannot move due to a fault, place a triangle warning sign at the rear of the vehicle while turning on the hazard warning lights.

  • Page 343: Sos Warning

    8-1. Essential Information SOS warning If you need help in emergency, press and hold SOS alarm switch for 3 seconds to call for emergency rescue, SOS indicator will change from steady light to flashing, and the background service will arrange a proper rescue service after receiving your call for help. SOS alarm switch is located at the rear of the front indoor light.

  • Page 344: Measures To Be Taken In Emergencies

    All traction must use safety chain devices and comply with local laws and regulations Before towing The following may indicate a problem with your transmission. Contact the FAW Authorized Hongqi dealer before towing. ●The engine is operating but the vehicle will not move.
  • Page 345 8-2. Measures to Be Taken in Emergencies ■ Two-wheel drive Deactivate the parking brake. Towing with a wheel-lifting truck from the front Place the towing table under the front wheel. Using a flat bed truck Apply the electronic parking brake, and turn off the engine switch.
  • Page 346 8-2. Measures to Be Taken in Emergencies Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed by fastening a cable or chain to the emergency towing eyelets and shifting the gearbox to N. This should only be attempted on hard surfaced roads for short distances at low speeds.
  • Page 347 8-2. Measures to Be Taken in Emergencies Step Firmly secure the towing cable or chain onto the towing eyelet. Don’t damage the body. Step Enter the towed vehicle and start the engine. If the engine can not be started, turn the engine switch to “IG- ON” mode. Step Release the electronic parking brake and shift the gear into N gear.
  • Page 348 8-2. Measures to Be Taken in Emergencies While towing ■ If the engine does not run, it means the brake and the steering wheel’s power assistant system are not working, which makes steering and braking even more difficult. ■ Towing eyelet Towing eyelets are stored in the vehicle tool box.

  • Page 349: If Any Abnormality Is Found On The Vehicle

    8-2. Measures to Be Taken in Emergencies If any abnormality is found on the vehicle If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Please contact with China FAW authorized Hongqi distributor. ■ Visible symptoms ●...

  • Page 350: If A Warning Lamp Turns On Or A Warning Buzzer Sounds

    Calmly perform the following actions if any warning lamp lamps up or flashes. If the warning lamp lamps up or flashes and goes out subsequently, it does not necessarily mean a system fault. However, if this continues to occur, please contact China FAW authorized Hongqi dealer to inspect the vehicle. List of warning lamps...
  • Page 351 → Check the bulbs and wiring harness connectors of external lamps for faults, or contact China FAW authorized Hongqi dealer immediately. Cleaning fluid level low warning lamp ● Indicate that the cleaning fluid level is too low. → Add the washer fluid or contact the FAW authorized Hongqi Dealer immediately.
  • Page 352 EPS system fault warning lamp ● EPS system fault warning lamp → Please drive the vehicle with caution and contact the FAW authorized Hongqi Dealer. EPS system serious fault warning lamp ● EPS system fault warning lamp →...
  • Page 353 Hongqi Dealer. Electronic steering column system fault warning lamp ● Indicates that the electronic steering column adjustment system is faulty. → Immediately contact the FAW authorized Hongqi Dealer. EPB system fault warning lamp ● Indicates a failure in EPB system.
  • Page 354 Warning lamp/details/actions Passive start system fault warning lamp ●Indicates that there is a malfunction in the smart start system. → Immediately contact the FAW authorized Hongqi Dealer. IFC system camera fault warning light ● Indicates a failure in IHC system.
  • Page 355 Headlight height automatic adjustment system fault warning indicator ● Indicates that the headlamp beam height automatic adjustment system is faulty. → Immediately contact the FAW authorized Hongqi Dealer. Note: when the oil pressure warning lamp and coolant temperature warning lamp lamps up, the warning...

  • Page 356: In The Case Of A Flat Tire

    8-2. Measures to Be Taken in Emergencies In the case of a flat tire Remove the flat tire and replace it with the spare. CAUTIONS Do not drive a vehicle with a flat tire ■ ● Do not continue driving with a flat tire. ●...
  • Page 357 8-2. Measures to Be Taken in Emergencies Jack Warning triangle Tire wrench Towing eyelet Vehicle tool box Spare tire fasteners Spare tire Trunk carpet Jack handle Reflective vest assembly Dismantling tool for wheel decoration cover...
  • Page 358 8-2. Measures to Be Taken in Emergencies Take out the spare tire Take out the carpet floor. Step Take out the vehicle tool box. Step Disconnect the speaker connector. Step Use a tire wrench to loosen and remove the fixture, and take out the speaker.
  • Page 359 8-2. Measures to Be Taken in Emergencies CAUTIONS ■ When accessing the spare tire Be careful, and do not let your finger or other body part between the spare tire of the vehicle body. Flat tire replacement Use holding blocks to wedge the tire. Step Tire Block Position Wheel with air leakage...
  • Page 360 8-2. Measures to Be Taken in Emergencies Calibrate the jack positions to make its notch “1” cover Step the jack point and the base plate “2” flatly attached to ground. At this moment, the base plate “2” must be vertically under the jack point. Insert the jack handle into the hole of the jack.
  • Page 361 •Do not install severely damaged wheel trim cover as they may come off the wheels while the vehicle is running •When installing wheels, use only wheel nuts designed for this wheel. • If bolts or nuts on the wheels have any crack or deformation, have the FAW authorized Hongqi dealer to inspect the vehicle. ●...
  • Page 362 8-2. Measures to Be Taken in Emergencies Installing the spare tire Remove any dirt or foreign matter from the wheel Step contact surface. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
  • Page 363 Have the wheel nuts tightened with a torque wrench to standard value in the FAW authorized Hongqi dealer as soon as possible after changing wheels. ● Have FAW authorized Hongqi dealer inspect and replace the wheel if the wheel bolt hole is damaged or cracked. Caution ■...

  • Page 364: If The Engine Cannot Be Started

    ■The starter does not run. The interior lights and headlights are off or the horns are not sounding. The cause of the failure may be one of the following. ● The battery terminals may be disconnected. ● The battery may be discharged. If the fault cannot be rectified or repaired, please contact China FAW authorized Hongqi dealer.

  • Page 365: If The Key Is Lost

    8-2. Measures to Be Taken in Emergencies If the key is lost If key is lost or stolen, please provide China FAW authorized Hongqi distributor with the remaining keys. After rematching the keys, the lost or stolen keys will be invalid. Improper modification or use of...

  • Page 366: If The Key Does Not Work Properly

    8-2. Measures to Be Taken in Emergencies If the key does not work properly If the communication between the smart key and the vehicle is interrupted (see P.85) or the smart key cannot be used due to insufficient battery power, the smart entry and wireless remote control functions will not be available.
  • Page 367 Step Hold the brake pedal down and press the engine switch to start the engine. If it sill fails to start the engine, please contact with China FAW authorized Hongqi distributor. Replacing the key battery ■...

  • Page 368: If The Battery Is Low

    "IG-ON" mode to start the engine. Step Once the vehicle engine is successfully started, remove the spanning cable in exactly the opposite order as it was connected. Once the vehicle is started, contact the FAW authorized Hongqi dealer as soon as possible.
  • Page 369 8-2. Measures to Be Taken in Emergencies ■ To prevent battery depletion ● Turn off the headlamps and the audio system while the engine is off. ● Turn off all unnecessary electronics when the vehicle travels at low speeds for a prolonged period of time (such as in traffic jams).
  • Page 370 If the battery gets aged, its continued use may cause the foul gas emission of battery, which may harm the occupants' health. Please contact the FAW authorized Hongqi dealer as soon as possible by then. Caution When Jumper Cable is Operated ■...

  • Page 371: If The Vehicle Is Overheating

    Step After the engine has cooled sufficiently, check the engine coolant level, and then check for radiator leaks. Step Add engine coolant if necessary. (See P.318) Contact the FAW authorized Hongqi dealer if engine coolant is unavailable in an emergency.
  • Page 372 8-2. Measures to Be Taken in Emergencies CAUTIONS ■ Precautions during inspection To prevent an accident or injury when inspecting under the engine compartment cover of your vehicle, observe the following precautions. ● If steam is seen coming from under the engine compartment cover, do not open the engine compartment cover until the steam has subsided.

  • Page 373: In Case Of The Vehicle Stuck

    8-2. Measures to Be Taken in Emergencies In case of the vehicle stuck If the wheels spin or the vehicle is stuck in mud or snow, please perform the following procedures. Step Shut down the engine. Apply the electronic parking brake and shift the shift lever to P. Step Remove the mud, snow or sandy soil around the trapped tire.

  • Page 374: If You Drive On Water-Covered Roads

    If you drive on water-covered roads The vehicle accidentally enters the water when driving on the stagnant road. Please contact China FAW authorized Hongqi dealer to check the following items: ● Inspect the braking efficiency of the brake. ● Check the oil quantity and oil quality of the engine and transmission (when the lubricating oil is cloudy, it means that water is mixed and should be replaced)..

  • Page 375: In Case Of A Punctured Tire

    Do not continue driving with a punctured tire, otherwise, it might easily cause accidents. In addition, it will cause damage to the tire, rim, suspension and body. At this Bang time, please replace the tire immediately or contact China FAW authorized Hongqi dealer.

  • Page 376: If An Accident Occurs

    Call the police. Accident site Accident condition Injured people Communicate with the responsible party and request his/her information (ID, insurance card, phone number). Contact the FAW authorized Hongqi dealer and your insurance company.

  • Page 377: Trunk Lid Emergency Open

    8-2. Measures to Be Taken in Emergencies Emergency opening of trunk The following steps may be used as an emergency measure to ensure that the trunk lid can be opened: Step You can access the trunk through the folded rear right backrest. Open the emergency release cover on the trunk lid.
  • Page 378 8-2. Measures to Be Taken in Emergencies...

  • Page 379: Vehicle Specification

    Vehicle specification: 9. Specifications Maintenance data ..........378 Fuel information ..........390...

  • Page 380: Maintenance Data

    9.Specifications Maintenance data Dimensions ■ Model No.: CA6471T, CA6471, CA6472HA6, CA6472HA6T Overall length 4,760 mm Overall width 1,907 mm Overall height 1,700 mm Front Overhang 967 mm Rear Overhang 923 mm Wheel Base 2,870 mm Front 1,630 mm Wheel Track Rear 1,630 mm Approach angle (no load)
  • Page 381 9.Specifications Curb weight ■ Model No.: CA6471T, CA6472HA6T Curb weight 1,805kg Maximum permissible total mass 2,255kg Front 1,148kg Full- load axle load Rear 1,107kg ■ Model No.: CA6471, CA6472HA6 Curb weight 1,755kg Maximum permissible total mass 2,205kg Front 1,136g Full- load axle load Rear 1,069kg...
  • Page 382 9.Specifications Vehicle Performance ■ Model No.: CA6471T, CA6472HA6T Maximum net power/speed 160 kW ( kilowatt )/ (4500-5500) r/min Rated power/engine speed 165kW ( kilowatt )/ (4500-5500) r/min Maximum output torque/engine speed 340 N·m / (1650-4500) r/min Maximum grade ability ≥40% Maxmimum speed 204 km/h ■...
  • Page 383 9.Specifications Rear wheel alignment (no load) Rear-wheel camber angle -49'±45' Rear wheel ß =16':±5' 2ß=32':±10' Vehicle height (from the wheel center to the fender edge) 468mm Suspension ■ Model No.: CA6471T, CA6472HA6T Type McPherson independent suspension Spring type Helical spring Double cylinder hydraulic inflatable damper / continuous Shock absorber type Front suspension...
  • Page 384 9.Specifications ■ Model No.: CA6471, CA6472HA6 Type McPherson independent suspension Spring type Helical spring Binocular hydraulic gas filled shock absorber Front suspension Shock absorber type Type Hollow stabilizer bar Stabilizer bar Diameter Φ29.2mm Multi-link independent suspension with a transverse Type stabilizer bar Spring type Helical spring...
  • Page 385 9.Specifications ■ Vehicle identification number The vehicle identification number (VIN) is a unique code to identify a motor vehicle. This is the main identification code of a vehicle, which is used for vehicle registration. ► Dashboard upper left The sticker is affixed under the front window glass on the upper left of the dashboard.
  • Page 386 9.Specifications ► Type 2 As shown in the figure, the engine number is embossed on the engine cylinder block. Engine Model CA4GC20TD-32 Inline four-cylinder, four-stroke, water-cooled, double overhead camshaft, 16 valve, intake Type and exhaust WT, Gasoline Direct Injection, supercharged gasoline engine Bore and stroke 82.5x93 mm Displacement...
  • Page 387 9.Specifications Oil quality grade Oil viscosity grade FAW turbocharged engine oil 5W-30 Select viscosity grade Turbocharged gasoline engine lubrication oil 5W-30 according to the use environment humidity Temperature range anticipated before the next oil change Cooling system ■ Model No.: CA6471T, CA6471, CA6472HA6, CA6472HA6T Capacity 7±0.1L Coolant type...
  • Page 388 9.Specifications Four-wheel drive power take-off Capacity 310±30mL Specification 80W-90 Rear main retarder Main retarder oil capacity 480±30mL Main retarder oil specification 80W-90 A/C refrigerant A/C refrigerant capacity 550±25 9 g A/C refrigerant specification R134a Transmissions ■ Model No.: CA6471T, CA6471, CA6472HA6, CA6472HA6T Transmission fluid type 6-Gear automated manual transmission Transmission fluid capacity...
  • Page 389 9.Specifications Brake system Free stroke of brake pedal ≤8mm Travel of brake pedal 120mm Brake fluid capacity 0.85±0.05L Brake fluid type (in accordance DOT4 with GB12981-2012) Reasonable use range of the brake friction pair ►Front Overall thickness Thickness of friction material Standard thickness 18.8mm 11.5mm...
  • Page 390 9.Specifications Microwave window Vehicle without multifunctional camera Vehicle equipped with multifunctional camera Suggested position of microwave window (shown in cab view) Tires and wheels Tire specifications 255/45 R20 101 W 235160 R18 103W Wheel size 20*8.5J 18*7 J 3 persons Full Load Tire pressure kPa (bar) Front...
  • Page 391 9.Specifications Bulb Bulb Lamp source type Lamp color Front position lamp 13.5 White Low beam White High beam White Front turn signal lamp Amber Front fog lamp White Side turn signal lamp White Exterior lamping Rear position lamp and signal devices Brake lamp Rear fog lamp Reversing lamp...

  • Page 392: Fuel Information

    ■ If the engine knocks Please contact with China FAW authorized Hongqi distributors.  Occasionally, a brief and slight knocking sound is heard during acceleration or climbing. This is normal and ...
  • Page 393 Additional information Additional information on sales to other countries and regions except for the mainland of China......394...

  • Page 394: Additional Information

    2. 5-11 Voice recognition* and related functions: temporarily only available in the mainland of China 3. 5-12 Mobile phone APP* and related functions: temporarily only available in the mainland of China 4. 5-13 HONGQI Smart Connect* and related functions: temporarily only available in the mainland of China...

  • Page 395: Other Information

    Other information List of Abbreviations ......... 394...

  • Page 396: List Of Abbreviations

    Thumbnail list Thumbnail list Abbreviations Meaning Automatic Brake Prefill Antilock Brake System Adaptive Cruise Control Auto Defrost system Autonomous Emergency Braking Auto Parking Assist Air Quality System Blind Spot Detection CDD-S Controlled Deceleration for ACC-Stop & Go (autonomous cruise control deceleration control (ACC stop-and-go type)) Controlled Deceleration for Parking Brake (Parking brake deceleration) Carbon Monoxide...
  • Page 397 Thumbnail list Abbreviations Meaning Emergency Stop Signal Forward Collision Warning Hydraulic Brake Assistant Hydraulic Brake Boost Hill Descent Control Hill Hold Control Intelligent Front Camera Intelligent High Beam Control Lane Departure Warning Light Emitting Diode Lane Keeping Assist Minimize Maximum Moving Object Detection Media Transfer Protocol On-Board Diagnostic...
  • Page 398 Thumbnail list Abbreviations Meaning Traffic Sign Recognition Universal 8eMal Bus Vehicle Identification Number WLAN Wireless Local Area Networks...
  • Page 399 Opening button inside the trunk lid Release handle of the hood Fuel fiiller cap Tire pressure Fuel tank capacity (for reference) Fuel type Unleaded gasoline (see P.384) Tire pressure See P.388 Oil capacity See P.384 Oil grade See P.385...
  • Page 400 On-board tools list Illustration Name Qty. Warning triangle Towing ring Reflection vest assembly tire wrench; Jack crank Jack Dismantling tool for wheel decoration cover*...

Table of Contents

Save PDF
