MODEL SPECIFICATIONS:

Product Specification (Raw 1.7)
Type of laser:
Guaranteed optical output:
Suitable for:
Control signal:
Scanning system:
Scan angle:
Safety:
Weight:
Package Includes:
R | G | B [mw]:
Beam size [mm]:
Beam divergence:
Modulation:
Power requirements:
Consumption:
Operation temperature:
Ingress rating:
System features:
Laser safety features:
Notice:
Dimensions [cm]:
full-colour, semiconductor diode laser system
>1,700mW
small to medium indoor / outdoor laser shows and laser graphic displays
ILDA - We recommend Pangolin FB3QS and QuickShow
25,000 points per second @ 8°
50°
fully complies with the latest EN 60825-1, and FDA regulations
5,3 kg
Carton box,
power cord, 10m ILDA signal cable, E-STOP box with 10m
cable, set of 4 safety keys, remote interlock bypass, user guide.
350 | 500 | 1000
5 x 3
<1mrad [full angle]
analog, 50kHz
100-230V/50Hz
max. 100W
10-40 °C
IP 20
All the adjustments such as power output of each colour, X & Y axes invert,
X & Y size and position, etc.Scanning system protection, daisy chain of
emergency STOP signal for multiple system "one-hit" operation.
Keyed interlock, emission delay, magnetic interlock, scan-fail safety,
mechanical shutter, adjustable aperture masking plate.
*Due to Advanced Optical Correction technology used in our laser systems
the optical power output of each laser colour within the system may slightly
differ from the specification of respective laser module(s) installed. This
does not affect the total guaranteed power output.
Length: 238
Width: 126
Height: 197
