Specifications
Product Name
iGUIDE PLANIX
●
Product Model
IMS-6
●
Performance
Measurement Range: Up to 40m
●
Measurement Uncertainty: +/- 1cm up to max range*
●
Laser Scanner Field of View: 360°
●
360° Camera: Ricoh THETA Z1
●
Connectivity and System Control
Wi-Fi: Wi-Fi 802.11 2.4GHz/5GHz Access Point
●
Survey Web App: Planitar web app in a browser over Wi-Fi from any device
●
Electrical
System Battery: 7.2V 6.9Ah/49.7Wh Li-Ion battery, user-replaceable
●
System Power Supply Input: 100-240VAC, 50-60Hz, 1.0A; Output: 12VDC, 3.3A
●
PLANIX Input Power: 12VDC, 3.3A
●
System Battery Performance: 7 hours of typical operation
●
Mechanical
System Unit Weight: 980g (2.16 lbs)
●
System Unit Dimensions: W: 34cm (13.4") x D: 11cm (4.3") x H: 11cm (4.3")
●
Shipping weight (with carrying case, without packaging): 3.6 kg (8 lbs)
●
Carrying Case Dimensions: W: 39cm (15.4") x D: 29cm (11.2") x H: 17cm (6.7")
●
Tripod Mounting Thread: 1/4" - 20
●
Environmental
Operating Temperature Range: 0-40°C (32-104°F)
●
Storage Temperature Range: -20-50°C (-4-122°F)
●
Relative Humidity: 0-90%
●
Maximum Altitude (operating): 4,000 m
●
* Typical, based on at least 60 cm wide wall segment
