System Settings

Auto Align - Laser measurement data will be automatically arranged following each scan. Toggle on or off.
HDR (High Dynamic Range) - Retains more details in bright and dark areas of the 360° images by merging
Coverage Opacity - Change the opacity of measured areas when looking at the laser measurement data.
Always Show Lidar Scan - Toggle the active lidar scan (shown in green color) on or off.
Quiet Mode - Mute all sounds produced by the 360° camera and the smart device. Suitable for
environments where sounds may be undesirable. Toggle on or off.
360° Camera Volume - Adjust the volume for the 360° camera's beeps.
Units - Input units for exterior wall thickness measurements. Toggle between centimetres or inches.
WiFi Band - Toggle between 2.4GHz or 5GHz bands. The 5GHz band will usually provide better WiFi
connectivity, however, in many countries the 5GHz band is to be used indoors only.
Region (selector) - Select your region to allow PLANIX to automatically choose an optimal WiFi channel
which will be compliant with your local wireless regulations. Ensure you follow your
local regulations regarding indoor use restrictions for the 5GHz band and do not use
PLANIX outdoors where not permitted.
Access Point Name - Specify the WiFi access point name.
WiFi password - Customize the WiFi password. The default password is the serial number of the system
found on the product label located on the base of the system..
Power Off Timeout - The camera will automatically power off after the specified minutes of inactivity.
Enter 0 to disable timeout.
Save Settings - Save changes to system settings. All unsaved changes will be lost.
Eject USB Drive - Halt all reading and writing from the USB drive for safe removal.
Power Off - Remotely power off the system.
Calibrate Compass - Calibrate the compass responsible for rotating laser measurement data and for
measuring overall property orientation. On-screen instructions will guide you through
a simple calibration procedure.
Align 360° Camera - Align the camera with the laser measurement data. On-screen instructions will guide
you through a simple alignment procedure. This alignment must be done each time
you remove and then re-attach the 360° camera and will help ensure proper alignment
of visuals with floor plans in the iGUIDE 3D tour.
Format USB Drive - Erase all data stored on the USB drive and reformat the drive.
Update System File - Update camera system parameters when instructed by technical support
Setup ➤ Connect ➤ Survey
images with different exposure settings. Toggle on or off.
