ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
4
Drivetrain Assembly
1/4" 6-32
x2
x4
x4
x2
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
9
®
