ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
9
Attaching the Line Tracking Kit and Front Bumper
2"
1/4 "
x2
x2
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
23
®
