ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
3
Base Frame Construction
1/4"
1/2"
x1
x1
x2
x2
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
7
®
