ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
4
Drivetrain Assembly
(continued)
3/8"
x1
x1
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
13
®
