ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
15
Wiring the Line Tracking Sensors
ANALOG PORT 3
ANALOG PORT 2
ANALOG PORT 1
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
