ROBOTC
SWERVEBOT BUILDING INSTRUCTIONS
7
Attaching Omni-Wheel & Rear Bumper
1/4"
1/2"
x2
x2
© 2011 Carnegie Mellon Robotics Academy / For use with VEX
Robotics Systems
Swervebot 1.1
•
20
®
