A P P E N D I X

System Specifications

This appendix contains system specifications.
General
This section provides general system information on the IGX 8.
System Capacity:
Enclosure Size:
Shipping Weight:
Clearance Requirement:
Power Input Voltage:
Current Requirements:
• AC System
• DC System
A
1 shelf with 8 card slots.
Requires 2 dedicated front slot(s) for NPMs.
Requires 2 dedicated back slots for SCMs (1 slot with blank plate).
Up to 6 T1/E1 circuit ports.
Up to 6 T1/E1 packet trunks.
Up to 48 synchronous data ports.
Up to 25 Voice, Data, and/or Frame Relay Module groups.
IGX 8 Standalone/Rackmount:
Height: 25 ins. (63.5 cm) standalone; 24.5 ins. (62.3 cm), rack
Width: 19.9 ins. (50.5 cm), standalone; 19 ins. (48.3 cm.), rack
Depth: 26.5 ins. (67.3 cm), standalone and rack-mount
270 pounds (122.7 kilograms)
Min. clearance: 30 inches front; nominal 30 ins. rear; 12 ins. side.
AC system: 100 to 240 VAC (90–264 under-voltage and
over-voltage tolerance), 47 to 63 Hz.
DC system: –42 to –56 VDC.
Each AC supply can provide up to 400 watts to the card shelves.
Space for 4 power supplies.
Configuration dependent - use Network Design Tool for exact
requirements. For planning purposes, use the following:
10 Amps Max. for 110 VAC, 5 A for 220 VAC.
20 Amps max. at –48 VDC; 25 Amps at –42 VDC (worst case)
-1
