Framework And Dimension - Eclipse Security ECL-IP2D50 User Manual

Please refer to the following sheet for detailed information.
Component
Component 1
Component 2
Component 3
No. Port
4 LAN
5 DC12V

2.2 Framework and Dimension

Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-3 to
Figure 2-6.
Component Name
Device lens
Dome body
Dome enclosure
Name Connector Note
Network
Ethernet
port
DC 12V
power
Figure 2-3 Dimension of Metal Dome 1
To connect to
Ethernet.
Note:

Some devices
support PoE.
To connect to DC12V power
supply.
standard
do not
11
