2 Structure

2.1 Components

You can refer to the following figure for
Please refer to the following sheets for detailed information.
Component
Component 1
Component 2
No. Port
4 LAN
5 DC12V

2.2 Framework and Dimension

structure components
Figure 2-1
Component Name
Device lens
Dome enclosure
Sheet 2-1
Name Connector Note
Network
Ethernet
port
DC 12V
power
Sheet 2-2
information. See Figure 2-1
To connect to
Ethernet.
To connect to DC12V power
supply.
.
standard
