Eclipse Security ECL-IP2D50 User Manual page 11

Table of Contents

Advertisement

Installation
Model
Parameter
Main Processor
OS
System
Resources
User Interface
System Status
Image Sensor
Pixel
Day/night
Gain Control
White Balance
BLC
Exposure Mode
Video
Compression
Standard
Video Frame
Rate
Video Bit Rate
Video Flip
Snapshot
Privacy Mask
Video Setup
Video
Information
Lens
Lens Interface
Ceiling and wall mount
High performance DSP
Embedded LINUX
Support real-time network, local record, and remote operation at the
same time.
Remote operation interface such as WEB, DSS, PSS
Bit stream statistics, log, and software version.
1/3-inch CMOS
1280(H)*960(V)
Support day/night mode switch
Fixed/Auto
Manual/Auto
On/Off
Manual/Auto/Low noise/Low motion blur
It ranges from 1/3 to 1/100000.
H.264/H.264H/MJPEG
PAL:
Main stream (1280*960@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2 ( 1280*720@8fps)
NTSC:
Main stream (1280*960@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
Note:
Extra stream 2's actual frame depends on device max capacity set
which can be adjusted within its range.
H.264H: 40Kbps-8192Kbps
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Support mirror.
Support flip function.
Max 1f/s snapshot. File extension name is JPEG.
Supports max 4 privacy mask zones
Support parameter setup such as bright, contrast.
Channel title, time title, motion detect, tampering, overlay.
2.8mm, 3.6mm, 6mm. Fixed focus.
M12. Lens is the default accessories
2048(H)*1536(V)
PAL:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*576@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@25fps)
extra stream 1 ( 704*576@25fps)
extra stream 2
( 1280*720@11fps)
NTSC:
Main stream (2048*1536@20fps)
extra stream 1 ( 704*480@20fps)
extra stream 2 ( 1280*720@1fps)
Main stream (1920*1080@30fps)
extra stream 1 ( 704*480@30fps)
extra stream 2 ( 1280*720@1fps)
6
