STEP 1 | WEIGHT STACK INSTRUCTIONS & NOTES
ID DESCRIPTION
1
2
3 Left Front Shroud
4 Right Front Shroud
5
Machine must be assembled on a flat and level floor.
• Disconnect rep counter wires during top cap removal (View A)
• Remove top cap and shrouds as shown
• Ensure that cable routing is as shown in View B
M8 X 50L SHC
Top Cap
Rear Shroud
QUANITY
4
1
1
1
1
ASSEMBLY
PART 1: WEIGHT STACK DISASSEMBLY
View A
View B
