Remote Configuration of a Siretta Router
The document is designed for any customer interested in accessing a Siretta Router web page
(GUI) remotely for configuration purposes, such as adding a Router to the management
platform, connecting to a VPN, advanced network settings and other Router setup functions.
NOTE: To setup the Router it must be connected locally to your PC initially using an ethernet
cable (See Router Quick Start Guide). This will allow you to configure and setup remote access
to the Router which will enable you to access and configure the Router remotely.
The following resources were used to create this document:
QUARTZ-W22-UMTS (EU) + ACCECSSORIES
PC for Router configuration
Fixed IP SIM card
Router Quick Start Guide
Steps to configure the Router for remote access.
1. Insert fixed IP SIM card into the Siretta Router (For this example a QUARTZ-W22-UMTS
(EU) was used)
2. Enter the APN details as provided by the SIM card provider (see Quick Start Guide).
3. Once the Router is connected to a mobile network you will see the connected status on the
Router's web interface (GUI) as shown below.
Siretta Limited - Enabling Industrial IoT
https://www.siretta.com | +44 1189 769000 | sales@siretta.com
Advertisement
Table of Contents
Related Manuals for SIRETTA QUARTZ-W22-UMTS(EU)
Summary of Contents for SIRETTA QUARTZ-W22-UMTS(EU)
- Page 1 Remote Configuration of a Siretta Router The document is designed for any customer interested in accessing a Siretta Router web page (GUI) remotely for configuration purposes, such as adding a Router to the management platform, connecting to a VPN, advanced network settings and other Router setup functions.
- Page 2 NOTE: This password field will be visible on the public internet and will be subject to hacking attempts and should therefore be a very secure password which is not easy to guess through dictionary or brute force attempts. Siretta Limited - Enabling Industrial IoT https://www.siretta.com | +44 1189 769000 | sales@siretta.com...
- Page 3 9. Click save and wait for Router to reboot. 10. Make sure that you see the settings you have defined in the page below after you have saved and rebooted the Router. Siretta Limited - Enabling Industrial IoT https://www.siretta.com | +44 1189 769000 | sales@siretta.com...
- Page 4 12. To access the Router remotely you will need to know the fixed IP address of the SIM card inside the Router to remotely access it over the internet. Siretta Limited - Enabling Industrial IoT https://www.siretta.com | +44 1189 769000 | sales@siretta.com...
- Page 5 15. You will see the login window below where you will need to enter your username and password that you configured in the remote access settings page. Siretta Limited - Enabling Industrial IoT https://www.siretta.com | +44 1189 769000 | sales@siretta.com...
- Page 6 With the VPN options you will need to source your own VPN server which has access to the same subnet as the PC's attempting to remotely connect to the Siretta Router. Once the VPN is configured and established with the Router the PC connected on the same subnet as the VPN server will be able to connect directly to the Router using the Routers own IP address.
- Page 7 DDNS is an alternative method of accessing the Router remotely without a fixed IP address which is explained in the link below: https://www.siretta.com/2019/04/setting-dynamic-dns-ddns-on-a-siretta-Router/ Any queries please contact support@siretta.com Siretta’s range of Router products can be found at the following: https://www.siretta.com/industrial-Routers/ Siretta Limited - Enabling Industrial IoT https://www.siretta.com | +44 1189 769000 | sales@siretta.com...
