Unique UGP-30G Owner's Manual

Off-grid by unique 30” propane gas range
Hide thumbs
Table of Contents

Advertisement

Quick Links

OFF-GRID BY UNIQUE
30" PROPANE GAS RANGE
(LPG & NG CONVERTIBLE)
Conforms to CSA/
ANSI STD Z21.1
2018 Certified to
CSA STD 1.1 2018
Household Cooking
Appliances.
MODEL NUMBER: UGP-30G OF2 S/S,
OWNER'S GUIDE
serial number:
DEC21V1
WARNING:
Never Operate the Top Surface Cooking Section of
this Appliance Unattended
•
Failure to follow this warning statement could
result in fire, explosion, or burn hazard that could
cause property damage, personal injury, or death.
•
If a fire should occur, keep away from the appliance
and immediately call your fire department.
DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE
FIRE WITH WATER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UGP-30G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unique UGP-30G

Summary of Contents for Unique UGP-30G

  • Page 1 OFF-GRID BY UNIQUE 30” PROPANE GAS RANGE (LPG & NG CONVERTIBLE) MODEL NUMBER: UGP-30G OF2 S/S, OWNER’S GUIDE WARNING: serial number: Never Operate the Top Surface Cooking Section of Conforms to CSA/ this Appliance Unattended ANSI STD Z21.1 • Failure to follow this warning statement could...
  • Page 2 OFF-GRID BY UNIQUE 30” PROPANE GAS RANGE LPG & NG CONVERTIBLE Installation & Owner’s Manual This manual contains information for: • Important Safeguards • Installation • Use and Care Certain ranges come equipped with special features. Determine from a study of your range which of the instructions given in this booklet pertain to your range.
  • Page 3 MANUFACTURED & CERTIFIED BY UNIQUE APPLIANCES WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFEGUARDS ......6 CARBON MONOXIDE WARNING ..... 12 ENERGY SAVING IDEAS .
  • Page 5 WELCOME & CONGRATULATIONS Congratulations on your purchase of a UNIQUE range! We are very proud of our product – and are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual very carefully. It contains valuable information on how to properly maintain your new Unique propane range.

  • Page 6: Important Safeguards

    READ ALL IMPORTANT SAFEGUARDS AND ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. IF YOU SMELL GAS • Open windows • Don’t touch electrical switches • Extinguish any open flame • Immediately call your gas supplier FOR YOUR SAFETY • Keep appliance area clear and free from combustible materials gasoline and other flammable vapors and liquids.
  • Page 7 PROPER INSTALLATION: Be sure a qualified technician in accordance with the National Fuel Gas Code ANSI Z223.1/NFPA54 properly installs your appliance. Install only per installation instructions provided in the literature package for this range. Be sure leveling legs are in place at the bottom corners of the range. If necessary, raise or lower the leveling legs at the base of the range by turning clockwise or counter clockwise to insure a level range.
  • Page 8 USER SERVICING: Do not repair or replace any part of the appliance unless specifically recommended in this owner’s guide. Only a qualified technician should do all other servicing. This will reduce the risk of personal injury and damage to the range. Storage in or on appliance: Flammable materials should not be stored in an oven, near surface burners or in the broiler section.
  • Page 9 Do not use water or flour on grease fires. Smother the fire with a pan lid, baking soda or use a dry chemical or foam-type extinguisher. Operation of the Surface Burners. When the burners are operated for the first time, a small amount of smoke may be generated due to tape residue or manufacturing lubrication, this is not dangerous.
  • Page 10 Cookware handles should be turned inward and not extend over adjacent surface burners. To reduce the risk of burns, ignition of flammable materials, and spillage due to unintentional contact with the cookware, the handle of a cookware should be positioned so that it is turned inward, and does not extend over adjacent surface burners.
  • Page 11 Flexible Connectors: If the gas range/oven is connected to a gas supply with a metal flexible connector, move the range/oven with CAUTION for service or cleaning. Flexible connectors are not intended for repeated bending. Do not allow cleaners to make contact with flexible connectors. The connector and its fittings are designed for use only on the original installation and are not to be reused for another appliance or at another location.

  • Page 12: Carbon Monoxide Warning

    CARBON MONOXIDE WARNING Carbon Monoxide is a possible danger when using any gas powered appliance. All gas appliances MUST be installed by a licensed professional who is familiar with the Carbon Monoxide levels appropriate for each appliance. The American Gas Association publishes CO emissions for appliances and heating equipment through the ANSI Std.

  • Page 13: Energy Saving Ideas

    ENERGY-SAVING IDEAS Surface Cooking Use lids when surface cooking. A lid traps steam and uses it to speed up the cooking process. If you have a pressure cooker or vegetable steamer, use it. You’ll waste fewer vitamins, save time and cut energy costs. Use medium-weight, flat bottomed pans that match the flame size.

  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS Be sure appliance is properly installed and grounded by a qualified technician. It is the responsibility of the technician to make certain that your range is properly installed. Situations caused by improper installation are not covered under the warranty.

  • Page 15: How To Install The Backsplash

    HOW TO INSTALL THE BACKSPLASH 15 页 1. Align the backsplash to the rear part of the cooktop as shown in the diagram. 23 页 15 页 2. Secure the backsplash to the cooktop from the back using the 2 Phillips head screws provided as shown in the diagram.
  • Page 16 GAS CONNECTIONS NOTICE TO MASSACHUSETTS APPLIANCE DEALERS: Be sure this document is included in all gas range appliances sold to consumers in the State of Massachusetts. NOTICE: Massachusetts law requires the following: • Appliances must be installed by a licensed plumber or gas fitter. •...
  • Page 17 GAS CONNECTIONS (continued) The appliance and its individual shut-off valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of psig. The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than psig.
  • Page 18 GAS CONNECTIONS (continued) For correct operation, the pressure of natural gas supplied to the regulator should be between 4” and 5” of water column. For LP gas, the pressure supplied must be between 10” and 12” of water column. When checking for correct operation of the regulator, the inlet pressure must be at least 1”...

  • Page 19: Wall Clearances & Anti-Tip Location

    WALL CLEARANCES All units must be installed in accordance to minimum rear and side wall clearance and clearances extended vertically above cooking top which are stated on the serial plate located at the back of the range. ANY OPENINGS IN THE WALL BEHIND THE UNIT AND IN THE FLOOR UNDER THE UNIT MUST BE SEALED.
  • Page 20 WALL CLEARANCES (continued) Anti-Tip Bracket Location...

  • Page 21: Ng Conversion Instructions

    The installation is not proper and complete until the operation of the converted appliances is checked as specified in the manufacturer’s instructions supplied with the kit.” UGP-30G OF1 Parts List: NOZZLE (NG) 1.
  • Page 22 GAS RANGE CONVERSION (continued) Convertible Pressure Regulator The range is shipped to operate on LPG. NG orifices and a special screwdriver for adjusting the minimum flame are shipped with the unit in a separate envelope with the manual. The inlet pressure of the gas supply shall be in accordance with the nominal inlet pressure of the regulator used on the range or 1/2 psig maximum.
  • Page 23 GAS RANGE CONVERSION (continued) 10. Take the NG orifices provided and install them as shown below See below for rating of orifice for each model Natural Gas Orifices 13,000 10,000 3,200 10,000 13,000 BURNER Triple Burner Semi-Rapid Simmer Rapid Burner Oven Burner Burner Burner POSITION...
  • Page 24 GAS RANGE CONVERSION (continued) 18. With a 7 mm wrench or pliers remove the orifice and replace with NG orifice. ORIFICE OVEN ORIFICE WRENCH 19. Replace the burner tube, then start up the oven to check oven flame, making sure the back of the burner tube to achieve this.

  • Page 25: Checking For Manifold Gas Pressure

    CHECKING FOR MANIFOLD GAS PRESSURE To check the manifold gas pressure, remove the burner cap and connect a manometer (water gauge) or other pressure test device to the burner orifice. Use a rubber hose with inside diameter of approximately ¼” hold the end of the tube tight over the orifice.

  • Page 26: Adjusting The Top Burner And Oven Flame

    ADJUSTING THE TOP BURNER AND OVEN FLAME Keep appliance area clear and free from combustible materials, WARNING gasoline, and other flammable vapors and liquids. Do not obstruct the flow of air that is necessary for combustion and ventilation. Top Burner Valves The top burners have orifices that are dedicated to the type of fuel to be used.
  • Page 27 ADJUSTING THE TOP BURNER AND OVEN FLAME Top Burner Height INCORRECT AND GOOD FLAME PATTERNS QUALITY OF FLAMES The combustion quality of burner flames needs to be confirmed visually. A. Yellow flames — Call for service B. Yellow tips on outer cones — It is normal for LP gas Incorrect: flame Good flame: Well-defined blue...

  • Page 28: Operation Of Range

    OPERATION OF RANGE HIGH FLAME / IGNITION BURNER POSITION OVEN PUSH PUSH TO IGNITE OVEN Lighting the Top Burners 1. To obtain a flame more easily, light the burner before placing a cooking utensil on the burner grate. 2. Decide which burner you’re igniting first using the screened diagram below the burner knob.
  • Page 29 OPERATION OF RANGE (continued) Lighting the Oven 1. Depending on how long the gas line run is, it may take a while to light the oven pilot. It is suggested that you light a top burner first to ensure the gas is at the valve. 2.
  • Page 30 OPERATION OF RANGE (continued) Hot Oven Restart If you turn off the oven but then decide to turn it back on before it has cooled to room temperature, the burner may not light properly. This is due to the thermostat still sensing “heated oven”...

  • Page 31: Alignments And Adjustments

    ALIGNMENTS AND ADJUSTMENTS Oven Burner Air Shutter Adjustment The oven burner flame should be a clean, blue flame with distinct inner cones. A soft, lazy flame with indistinct cones means too much gas or not enough air. A noisy lifting flame indicates too much air.
  • Page 32 ALIGNMENTS AND ADJUSTMENTS (continued) Baking Follow the recipe instructions when baking. Use correct ingredients, measure them carefully, and use the correct type and size of cookware suggested in the recipe. Remember to preheat properly. Avoid opening of the oven door as much as possible when baking.
  • Page 33 ALIGNMENTS AND ADJUSTMENTS (continued) Removable Oven Bottom First remove the racks from the oven. The oven bottom lifts from the rear. Grasp each side of the oven bottom and lift upward from the rear until the bottom is clear, lift it to remove from the front.

  • Page 34: Broiling

    BROILING Preheat the broiler area and broil pan for a few minutes. No definite time can be given for broiling meats because of varying thickness, amounts of fat, and personal taste. Be careful when handling hot broiler pans; be careful of the hot grease. Serious injury can result due to spillage of hot grease.

  • Page 35: Cleaning The Range

    CLEANING THE RANGE Always keep cleaning materials and chemicals in a safe place and away from children. Know what you are using. Make sure all parts of the range are COOL before cleaning. Be sure to replace the parts correctly. Knobs Pull forward on the knobs to remove them (or use light string to place behind the knob and pull away from the unit).
  • Page 36 CLEANING THE RANGE (continued) Products of combustion from the top pilots as well as certain atmospheric conditions can create an oxidation reaction on the underside of the top. This will appear as rust or in the form of a reddish brown deposit. This will NOT AFFECT THE LIFE OF THE TOP in comparison to the general life expectancy of the range itself.
  • Page 37 CLEANING THE RANGE (continued) Moisture During the initial heat-up of your range, the heat mixing with the cooler air in the oven cavity may produce fogging of the door glass or a collection of water on the door. To prevent this, open the oven door for the first few seconds of initial oven heat-up. This will allow the moist air within the oven to escape, without the forming of visible moisture on the range.

  • Page 38: Removing The Oven Door For Cleaning

    CARE AND MAINTENANCE (continued) REMOVING THE OVEN DOOR FOR CLEANING To facilitate oven cleaning, it is possible to remove the door. Please follow the instructions carefully. The oven door is heavy - you may need help removing and replacing the door. To remove the door: •...

  • Page 39: Removing The Kickplate For Cleaning

    CARE AND MAINTENANCE (continued) REMOVING THE KICKPLATE FOR CLEANING It is possible to remove the magnetic kickplate at the bottom of the range to aid in cleaning underneath the range. HOW TO GAIN ACCESS TO THE BATTERY COMPARTMENT Gaining access to the battery compartment: 1.

  • Page 40: Troubleshooting Guide

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTION Surface burner fails to a. Clogged burner ports a. Remove burners and clean out light dirt and spider webs b. Battery dead b. Replace with new D size battery c. Ignition relay defective c. Replace relay Uneven flame a.

  • Page 41: Wiring Diagram

    WIRING DIAGRAM IGNITION MODULE MODULE D’ALLUMAGE TSTAT...

  • Page 42: Parts Diagram And List

    PARTS DIAGRAM AND LIST Please visit our website www.UniqueAppliances.com to view a PDF version of the schematics which will allow you to zoom in and out.
  • Page 43 Medium Burner ASSY for UGP-30G S/S OF2 UGP-CY14515 Backsplash Mount Plate UGP-30G S/S OF2 UGP-DWSJ13248-3 Cooking Panel Black for UGP-30G S/S OF1; 30CR Range UGP-DWWJ01003 Al. Gas Pipe (back right) for UGP-30G Ranges UGP-DWWJ01004 Al. Gas Pipe (front right) for UGP-30G Ranges UGP-DWWJ01006 Al.
  • Page 44 Oven Door Inner Panel for UGP-30G S/S OF1 25 UGP-WSJ13267 Oven Floor for UGP-30G/30CR Range 68 UGP-CYJ00799 Oven Door Upper Decorative Strip (S/S) for UGP-30G S/S OF2 26 N/A 69 UGP-XGL00009 Oven Seal (Gasket) for UGP-30G S/S OF2 27 UGP-DPJ24070 Nozzle Seat for UGP-30G/20 &...
  • Page 45 Medium Burner ASSY for UGP-30G S/S OF2 UGP-CY14515 Backsplash Mount Plate UGP-30G S/S OF2 UGP-DWSJ13248-3 Cooking Panel Black for UGP-30G S/S OF1; 30CR Range UGP-DWWJ01003 Al. Gas Pipe (back right) for UGP-30G Ranges UGP-DWWJ01004 Al. Gas Pipe (front right) for UGP-30G Ranges UGP-DWWJ01006 Al.
  • Page 46 APPLIANCE INFORMATION (manual copy - keep with your records) To make care and servicing of your range easy and efficient, please record the following information for future reference: Model: Serial Number: Purchased From: Date Purchased: Installed By: detatch along dotted line detatch along dotted line APPLIANCE INFORMATION (remote copy - keep with your appliance)

  • Page 47: Warranty

    If the appliance fails to do so because of a defect in material or workmanship within one year from the original date of purchase: Unique will at our option, repair, exchange, or correct by other means Unique consider appropriate, any part(s) Unique finds to be defective except for the surface finish.

  • Page 48: Rating Label

    Toll-free Website info@UniqueAppliances.com 1-877-427-2266 or 1-905-827-6154 www.UniqueAppliances.com available during regular business hours, 8:30 am to 4:30 pm, EST Please visit our website for more quality Unique products: www.UniqueAppliances.com Unique Appliances Ltd., 2245 Wyecroft Road #5, Oakville, Ontario, Canada, L6L 5L7...
  • Page 49 ©2021 Unique Appliances Ltd., 2245 Wyecroft Road #5, Oakville, Ontario, Canada, L6L 5L7 www.UniqueAppliances.com...
