Summary of Contents for Hettich CADRO

  • Page 1 | Rahmensystem | Technical Information and Assembly...
  • Page 2 | CADRO Technical Information and Assembly | Frame system...

  • Page 3: Table Of Contents

    2 | 3 Contents | CADRO Base 6– Basic assembly of each CADRO piece of furniture The basic principle The safe connection Planning The sketch The CADRO frame Processing 8–9 Definition of the profile lengths Cutting of the profiles Cleaning...
  • Page 4 Basic lighting profile with diffusing profile for shelf panels Assembly Attachment of the LED lighting strips Laying of the cables Power supply Cable outlet | CADRO Glass display case 30–37 Frames for glass panels 30–31 The principle Drilling Glass elements...
  • Page 5 Lighting profiles 43 - 44 Assembly Attachment of the LED strips Laying of the cables | CADRO Room concept 45 - 46 Fixing elements Wall / floor attachment I Wall / floor attachment II Wall / floor / ceiling attachment...

  • Page 6: Cadro Base

    CADRO Base. Basic assembly of each CADRO piece of furniture. The basic principle. The principle is very simple and always remains the same: The connectors are inserted into the ends of the profiles and screwed with threaded pins to achieve a firm connection.

  • Page 7: Planning

    Door inside the frame The CADRO frame. The next step is to choose the CADRO components that are required for the CADRO frame construction. Definition and quantity of the required connectors. This determines the quantity of the required grub screws: 3-way connector = 3 screws, 4-way connector = 4 screws, etc.

  • Page 8: Processing

    CADRO Base. Processing. Definition of the profile lengths. All connectors within the assembled frame have a thickness of 18,5 mm. This dimension must be deducted from the outer dimensions of the furniture for each connector to obtain the exact profile dimensions. E.g. for 2 connectors and an outer...

  • Page 9: Drilling/Milling

    9 mm, up to the middle. Another option is using the Hettich Cadro jig Mini, order no. 9 316 176. Alternatively, the holes can also be drilled by using a CNC milling machine.

  • Page 10: The Drilling And Tapping Jig

    9 298 865 The drilling and tapping jig is specially designed for the profiles of the CADRO system. It is fixed only once on a pillar drilling machine and Center hole for the then offers the possibility to drill precise and uniform holes by simply...

  • Page 11: Structure And Function

    10 | 11 Structure and function. Optional sets (e.g. for sliding door profiles) Fixing points for optional sets (e.g. sliding door profiles) 4 different positions for the stop plate Stop plate Center hole for the positioning on the pillar drilling machine (position of the drill) Optional sets.

  • Page 12: Assembly

    CADRO Base. Assembly. Tools. All you need to assemble the basic frame is a 2,5 mm Allen key or, better still, a cordless screwdriver with the appropriate bit. When using a cordless screwdriver, the torque lock should be set to 0,8-1 Nm (e.g.
  • Page 13 12 | 13...

  • Page 14: Attachment

    | CADRO Technical Information and Assembly CADRO Base. Attachment. Profil The invisible wall mounting system. The profile has to be centrally milled out at the furniture elements‘s back with a width of 12 mm and a minimum height of 67 mm. Please...

  • Page 15: Load Capacity Of Wall-Mounted Standard Shelves

    At the same distance as used for the fastening sleeves, a 10,5 mm centre drill hole for each fastening sleeve is to be drilled into the CADRO frame with a depth of 15 mm. On the right or left side of the profile next to the drill hole a second hole with thread has to be drilled.

  • Page 16: Side And Shelf Panels

    CADRO Base. Side and shelf panels. Peripheral groove. In order to create closed furniture elements with side and rear walls, the 2 mm. Thus they can neatly and securely be assembled into the frame without any visible fixation. wall elements are provided with a peripheral groove having a width of...

  • Page 17: Eccentric System

    The edges of the required side panels have to be predrilled with an 8 mm drill. Afterwards the ball spring plungers are inserted. The drilling depth has to be 18 mm. As for the CADRO profile, the drillings have to be made at the same positions. ADVICE: You can use the already existing holes for the threaded pins in the profiles to avoid additional drillings for the ball spring plungers.

  • Page 18: Hinged Doors

    With commercially available pot hinges, doors can be mounted inside and outside the frame system. In this case, we recommend: Hettich Sensys hinges for inset doors (base B-4) in combination with Sensys cross mounting plates. The choice of the mounting plate depends on the individual application, e.g.

  • Page 19: Sliding Doors

    . The profiles also offer the possibility to insert shelves at tem. All components perfectly fit into the guiding grooves of the CADRO the top and bottom or to screw them tight from the inside.

  • Page 20: Drilling Dimensions

    | CADRO Technical Information and Assembly CADRO Base. Profiles for sliding doors. overlay Profile on top 12,5 Top profile 9 298 798 / 9 298 799 Profile at the bottom 12,5 Bottom profile 9 298 800 / 9 298 801 Drilling dimensions.

  • Page 21: Drilling Dimensions

    9 298 804 / 9 298 805 Drilling dimensions. The external dimensions of the inset door are all-around 1 mm smaller than the external dimensions of the CADRO frame. The right and the left side mir- rors the same drilling distances. SlideLine M...

  • Page 22: Actro You / Actro 5D

    Assembly of the basic profile. In order to integrate the basic profile for drawer guidings rails into the CADRO frame system, it is advisable to place a connector at the lower profile connection position . Thus, a stabilizing cross profile can also be integrated at this position.

  • Page 23: Attaching The Guiding Rail

    9 298 808 / 9 298 809 is used. Two-sided covering ist provided by the profile order no. 9 298 810 / 9 298 811. CADRO drawer profile, we recommend the use of a M5 x 11 mm countersunk head screw Ø 3,6 x 8 mm, order no. 9 217 435. Predrilling of the profile with Ø...

  • Page 24: Alternative Profile Attachment

    CADRO Base. Alternative profile attachment. Universal connector. Universal connector incl. cylinder head screw 9 298 862 M 5 x 35 mm Drill a 4 mm diametre core bore in the centre of the profile‘s width (18 mm). Drilling depth approx. 10 mm.

  • Page 25: Accessories

    24 | 25 Accessories. Connecting thread and adjustable stand. Cut the profile to the required length. The connecting thread is inserted into the profile‘s end up to the 9 mm flush end. 8 mm Thanks to the integrated M8 nut in the connecting thread, it is possible to insert the adjustable stand or to fix commercially available castors with M8 screws.

  • Page 26: Cadro Lighting

    For the lighting and guidance of the cables the connectors and profiles from the CADRO lighting range are to be used. They are specially designed to hold and guide the cables and LEDs.

  • Page 27: Lighting Profiles

    26 | 27 Lighting profiles. Basic lighting LED lighting strip profile Basic lighting profile with diffusing profile. 9 298 812 / 9 298 813 A LED lighting strip (max. width 6 mm) is simply glued into the basic lighting profile, order no. 9 298 812 / 9 298 813, and afterwards neatly covered by the diffusing profile, order no.

  • Page 28: Assembly

    CADRO Lighting. Assembly. The assembly of the frame is done in the same way as described on page 12 | 13. As for the lighting profiles and connectors for lighting and cable guidance, their use results from the previous planning (Example described on page 26).

  • Page 29: Power Supply

    28 | 29 Power supply. Cable exit. For the connection to an LV-transformer all cables are guided through the connector for power supply towards the outside, that is usually towards the wall - in case of hanging furniture mostly upwards, as for standing furniture also downwards.

  • Page 30: Cadro Glass Display Case

    3 mm) to the inner dimension of the frame (= profile dimension). (See also figure on the right.) For doors being mounted with the CADRO glass door hinge, 4 mm (all- 2,5 mm around) have to be deducted from the inner dimension of the frame.
  • Page 31 30 | 31 4 0 0 Dimensions of the components using the follwing example: Inner dimension of the frame (profile length) = Outer dimension of the frame - 2 x connector = 400 mm - 37 mm x 400 mm - 37 mm = 363 x 363 mm Size of the glass panel to be fixed in the frame = I nner dimension of the frame + 6 mm (3 mm all-around)

  • Page 32: Preparation Of The Profiles

    CADRO Glass display case. Preparation of the profiles. Grub screw 9 303 930 Inserting of the screws. The screws are inserted the same way as done for the base frame (see page 9). However, M5 x 4 mm DIN 913 grub screws are used for the glass profiles.

  • Page 33: Assembly

    32 | 33 Assembly. The frame is assembled according to the order as described on page 12 | 13. Afterwards, all protective films must be removed from the sealing strip. Finally, the glass panels are inserted one after the other and securely fixed using the clip-on profiles.
  • Page 34 CADRO Glass display case. Assembly. RECOMMENDATION: In case of inaccurate drilling for the connectors, the screw can hinder the clip-on profiles to be clicked in. In this case it is pos- sible to remove a little bit of the Clip-on profile...
  • Page 35 34 | 35 In the open area intended for the glass door, the clip-on profile, order no. 9 303 916 / 9 303 917, is to be used. Because of its larger width, it neatly covers the frame profile in the area where no glass panel is firmly installed.

  • Page 36: Glass Door Hinge

    Glass door The glass door hinges from our CADRO Glass display case range of products have been designed to support 4 mm thick glass doors for display cases. The glass door is simply slided into the hinges at the top and the bottom and then fixed by screwing (see below).
  • Page 37 36 | 37 Drilling and hole positions 4 mm in the profile. The drilling positions for the top and bottom hinge and the ball spring plungers are arranged oppositely at the same positions depending on the size of the glass door. Glass door As a rule, the door is all-around 4 mm smaller than the inner dimension of the frame (see also page 31).

  • Page 38: Drilling And Hole Dimensions

    10 mm 24 mm 24 mm 4 mm 4 mm CADRO Frame of glass display case CADRO Frame of glass display case = 50 mm = 50 mm Drilling for lock = x - 6 mm Drilling for lock = x + 14 mm...
  • Page 39 38 | 39 Lock assembly. At first, the lock must be opened on the back. Then, the two screws Afterwards, the cover including the latch is reattached. of the cover must be removed to take off the cover. The protective film of Please make sure that the locking cylinder and the latch is correctly the adhesive surface also has to be removed so that the lock can be stuck positioned!

  • Page 40: Glass Door Handle Attachment

    CADRO Glass display case. Glass door handle attachment. Glass door handle e.g. knob attachment Cadria 9 303 936 / 9 303 937 Choose a suitable knob as a handle for your display case door and fasten 40 mm it by screwing to the handle attachment before mounting the glass panel.

  • Page 41: Clip-On Glass Shelf Support

    40 | 41 Clip-on glass shelf support. Glass shelf support 9 317 667 Glass shelf support 9 317 669 Depending on the position, the glass shelf supports were designed to be used for the 2-sided and 1-sided clip-on profiles: Clip-on profile Clip-on profile Clip-on profile...

  • Page 42: Glass Shelf Dimensions

    Glass shelf 18,5 mm Inner dimension of the frame width 18,5 mm dimensions. Generally, glass shelves are mounted in a way that they are inserted in the frame profiles at the front and the back. Their sides reach until the side glass panels of the glass display case. In Glass shelf Glass shelf the area of the front edge, the glass door hinge...

  • Page 43: Lighting Profiles

    The 1-sided clip-on profile, order no. 9 303 924, is used to create a closed profile side, e.g. for door surfaces. PLEASE NOTE: We recommend a detailed lighting planning in advance for your display case. For this purpose, see also chapter CADRO Lighting | planning on page 26. 13,5 Lighting...

  • Page 44: Laying Of The Cables

    Now, the LEDs are being covered by clipping on the lighting clip-on profiles. At the same time, they help to fix the glass panes securely within the frame. Lighting clip-on profile 9 303 925 Laying of the cables. The cables are now guided towards the connector with cable exit (see Clip-on profile also page 29).

  • Page 45: Cadro Room Concept

    44 | 45 CADRO Room concept. Fixing elements. Wall / floor attachment 18 x 18 mm. The wall / floor attachment is simply screwed onto the fixing surface with a suitable countersunk screw (min. length 60 mm), if necessary with a dowel.

  • Page 46: Wall / Floor / Ceiling Attachment

    Wall / floor / ceiling attachment with clamp SAFETY NOTE: The wall / floor / ceiling attachment is integrated into the profile frame, Provided that the attachments have correctly been fixed to the wall, so that the frame can be placed parallel to a wall, ceiling or floor. The floor or ceiling, we recommend a maximum tensile load of 30 kg set including the clamp offers the possibility to mount the frame at two per attachment.
