Rightline Gear Trunk Storage Bag Setup Manual

Trunk Storage Bag Set Up Guide
The correct attachment of this product is critical and
beyond the control of Rightline Gear. The safe use
and long life of this product depends entirely on
your good judgment and following these directions.
Pack The Trunk Storage Bag
1-Slide the hard plastic sheet into the top sleeve (Fig 1).
2-Velcro the (2) hard plastic shelves onto the horizontal
dividers (Fig 2).
Fig 1
3-Place items like gloves, tree trunk protectors, recovery
straps, snatch blocks, jumper cables, tool kits, air compres-
sors, bikini tops, jackets, clothing, and blankets in the (4)
storage compartments.
4-Place smaller items in the inner mesh pouch (Fig 3).
5-Close the zippers and secure the Velcro closures at the
bottom of each compartment (Fig 4).
Fig 3
Attach The Trunk Storage Bag
2-door Jeep Wranglers
The Trunk Storage Bag straps to the rear vertical roll
bars, the rear seat headrests, and the attachment rings
on the bottom of the rear seat. Your Wrangler's top can
be up or down. This product fits the Jeep Wrangler JK.
1-Position the bag behind the rear seat (Fig 5).
Fig 2
Fig 4
A
Fig 5
2-Buckle (2) of the rear side straps through their matching
attachment rings on the bottom of the rear seat (Fig 6).
Rear Side
Of Bag
Fig 6
3-Buckle the A strap around the left rear vertical roll bar,
above the seat belt holder, without twisting the strap (Fig
5 and Fig 7).
4-Buckle the D strap around the right rear vertical roll bar,
above the seat belt holder, without twisting the strap (Fig
5 and Fig 8).
5-Buckle the B strap around the left headrest, without
twisting the strap (Fig 5 and Fig 9).
6-Buckle the C strap around the right headrest, without
twisting the strap (Fig 5 and Fig 10).
Fig 7
Fig 9
7-Tighten all (4) straps. The top of the bag should follow
a straight line, parallel to the top of the rear seat (Fig
11).
B C
D
Attachment
Rear Side
Strap
Fig 8
Fig 10
Ring
