ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
RTS735T-CS01-3
2
RTS735T-CS01-2
3
RTS735T-CS08-2
4
62RTS735TQ101
5
RTS735T-CS11-1
6
RTS735T-CS14-1
7
17C03A0814041Y2
8
17C02A0709003Y4
9
17C01A0706002Y4
10
17C03A0816041Y2
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.
Step 1:
Fasten the seat post (#3) to the right leg (#1) and left leg (#2)
by using bolts (#7) and washers (#11). Keep the bolts loose.
See Figure 1.
Note:
1. The arrow marks attached on the seat post (#3) and legs
(#1 and #2) should coincide with Figure 1 to ensure proper
assembly.
2. The labels marked "L" and "R" on the legs (#1 and #2)
should coincide with Figure 1 to ensure proper assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
RTS735T
PART
Q'TY
RIGHT LEG
LEFT LEG
SEAT POST
SUPPORT
SEAT ASSEMBLY
SUPPORT FRAME
BOLT M8*40
BOLT M6*30
BOLT M6*16
BOLT M8*45
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP
DON'T RETURN TO STORE!
PAGE 1 OF 3
11
17FA08060601-Y4
1
12
17FA05040301-Y4
1
13
17EA1203-----23
1
14
17D03A040401-Y4
1
15
18000319004
1
16
18000337006
1
17
18000337002
4
18
17KAA0201----Y4
4
19
17KAB1101----Y4
4
20
61R735TX00001BA
4
21
61R735TY00001BA
FIGURE 1
11
11
WASHER d8.5*D17*1.6
WASHER d6.5*D13*1.0
WASHER
JAM NUT M8*1.25
BOLT CAP M8
BOLT CAP M6
BOLT CAP M6
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
BACK CUSHION
SEAT CUSHION
1
R
3
7
7
15
15
#7 BOLT M8*40
COURTYARD CREATIONS INC.
12
4
2
4
8
4
4
1
1
1
1
2
L
40
