Courtyard Creations RTS099W-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
DESCRIPTION
NO.
1
RTS099W-CS01
2
RTS590E-CS02
3
RFS8821-CS04
4
17C03A0814041Y2
5
17C01A0712002Y4
6
17FA08060601-Y4
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the seat assembly (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the seat post (#3) to the brace on the seat
assembly (#1) by using bolts (#4), washers (#6 and #7),
and jam nuts (#9). See Figure 1.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely
!
assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts
!
and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed
!
by children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
RTS099W-
PART Q'TY
SEAT ASSEMBLY
BASE ASSEMBLY
SEAT POST
BOLT M8*40
BOLT M6*35
WASHER d8.5*D17*1.6
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
7
17FC08030801-Y2
1 8
17FA05100701-Y4
1 9
17D03A040401-Y4
1 10
18000319004
4 11
18000337002
1 12
17KAA0201----Y4
4 13
17KAB1101----Y4
FIGURE 1
7
9
7
9
WASHER d8.5*D12*2.1
WASHER d6.5*D30*2.0
JAM NUT M8*1.25
BOLT CAP M8
BOLT CAP M6
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
10
4
6
10
4
1
6
3
40
#4 BOLT M8*40
COURTYARD CREATIONS INC.
4
1
4
4
1
1
1
