All information in these instructions is based upon the latest product information available at the time of publication. Kohler China reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
Level Screw driver Connection wire Wire cutter Insulation tape Bushing Percussion Drill Pen Knife Wrench ROUGHING-IN Reference Value Unit: mm Junction Box Cover Ventilation Outlet Hot Air Outlet Kohler reserves the right to change marked dimensions without prior notice. 1369766-T01-E...
0 Pa The exhaust air volume, air change noise and other data are the test results of Kohler company, which are all central values, which are measured under the static pressure of 0 Pa. The error of exhaust air volume shall not be less than 90% of the express value.
WIRING DIAGRAM ALL-POLE SWITCH (OPTIONAL) OVER CURRENT FUSE THE RATE OF THE POWER SWITCH MUST NOT BE LOWER THAN 250V 16A 250V YELLOW CAPACITOR BLUE YELLOW/GREEN MOTOR 220V 50Hz BLUE THERMOSTAT THERMAL FUSE BROWN PRODUCT STEPPER MOTOR SWITCH HEATER BLUE BLUE PINK YELLOW...
PREPARATIONS BEFORE INSTALLATION A. Preparation before the installation 1. Open the hole of outlet window Make sure that the outlet window s position (it should be lower than the outlet of the bathroom heater to prevent the water come back to the bathroom heater from the outlet window), and open a round hole on the wall.
Page 8
Installing the Main Body 300*300 300*450 300*600 Integrated ceiling should be 300*300, 300*450, 300*600: 1. Connecting the power cord Pass the power cord through the ceiling. Power cord Decorated Plate 2. Take down the decorated plates around the installation position to ensure that there is sufficient operation space for installation (see the figures below).
Page 9
5. Push the bathroom heater into the integrated ceiling. Use BTP4*8 BTP4*8 triangular self-tapping screws to connect the body and L-mounting brackets. The installation height shall be adjusted before the screws are tightened. Decorated Plate Body BTP4*8 Triangular Self Tapping Screw BTP4*8 (8 ) 6.
8. Take down the wiring cover plate. Insert the power cord and 2 power lines of wall controller into the wire terminals. Tighten the terminal screws and fix the lines. Finally, mount the wiring cover plate. In line layout B, power line of wall controller needn't be connected to wire box.
B. Time Setting Under the heater mode, there is a delay of 30 secs after " " " " the heater mode is stopped or switched ventilation mode. Fan light flashes while air flow light is on within the 30 secs of delay.
Page 12
CARE & CLEAN (PROFESSIONAL ONLY) 1. Turn off power supply before maintenance or cleaning. If Casing or Air Louver are covered with dust, do not splash water onto it. Use only damp sponge or cloth to wipe dirt off. 2. Do not use eradicator, abrasive powder or oil, acid or alkali liquid detergent to clean casing or air louver.
Note: Troubleshooting needs to be done by professional of KOHLER CHINA. Users are not suggested to do this without help. Please remember that the checking and repairs done by users themselves could easily cause damage to the machine or cause physical harm to the person.
