All information in these instructions is based upon the latest product information available at the time of publication. Kohler China reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
Bushing Percussion Drill Pen Knife Wrench ROUGHING-IN Unit: mm Reference Value Ventilation Outlet Junction Box Cover 295 268 Inlet(where filter mat is installed) Kohler Logo Hot Air Outlet Kohler reserves the right to change marked dimensions without prior notice. 1374352-T01-D...
0 Pa The exhaust air volume, air change noise and other data are the test results of Kohler company, which are all central values, which are measured under the static pressure of 0 Pa. The error of exhaust air volume shall not be less than 90% of the express value.
WIRING DIAGRAM K-24619T-G-0 HOT MOTOR BLUE YELLOW/GREEN OVER CURRENT FUSE CAPACITOR 220V 50Hz BLUE THERMOSTAT THERMAL FUSE VENT MOTOR BLUE CAPACITOR ALL-POLE SWITCH (OPTIONAL) HEATER 1 BLUE HEATER 2 BROWN WHITE STEPPER MOTOR THE RATE OF THE POWER SWITCH GRAY BLUE MUST NOT BE LOWER THAN 250V 20A PINK...
PREPARATIONS BEFORE INSTALLATION A. Preparation before the installation 1. Open the hole of outlet window Make sure that the outlet window's position (it should be lower than the outlet of the bathroom heater to prevent the water come back to the bathroom heater from the outlet window), and open a round hole on the wall.
Page 7
C. Packing List 1367446 1367441 100 Air Outlet Window Fixed Column Assy. M6 Expansion Head 10 Expansion Pipe 1374343 100 Air Exhasut Pipe M6 Screw Rod Note: Initial Length: 150mm Stretch Length: 2200mm 150mm 2200mm 1285549 Clamp 1285553 Lock Assy. / M6 Butterfly Nut 6 Washer 1373399...
INSTALLATION Caution before installation: 200mm The installed product must be 200mm or above away from curtains or other combustible materials. The distance between the ceiling where the product is 200mm mounted and the roof shall be 200mm or above. Ensure that the gap between the product edge and the 300mm wall is 300mm or above.
Page 9
(2) Plug the M6 screw rod on the cerement board and attach the hanger to the rod as the diagram shows. Fix two wooden bars to the hanger with 8 ST 4.2*10 ST4.2*10 triangular screws. (8pcs) M6 Butterfly Nut 6 Washer 6 Spring Washer M6 Nut Hanger Clinging to Plasterboard...
Page 10
(4) Fix the power cord to the bathroom heater Remove the screw on the wiring cover plate. (II) Open the wiring cover plate. (II) (III) Lift the terminal protection cover. (III) (IV) Loosen the screw fixing the power cord clip. (IV) (V) Loosen the screw on the wiring terminal, insert the power cord (not supplied) connected to the indoor...
Page 11
(6) After the bathroom heater is fully inserted into the hole. Fix the hanger with the heater by using 8 BTP 4*8 BTP4*8 triangular self-tapping screws. Finally, put back the (8pcs) decorative screw covers. (5pcs) Plasterboard Panel Base Clinging to Plasterboard Panel Base Decorative Screw Cover...
Page 12
2) Make the holes at the marked position. Cement Board Suspender (2) Demount five decorative screw covers. and install the (5pcs) ventilation outlet assembly first with 1 ST 4.2*8 self- ST4.2*8 (1pc) tapping screw. Decorative Screw Cover ST4.2*8 Self-tapping Screws ST4.2*8 (1 ) (3) Fix the hangers to the heater with 8 BTP 4*8 self-...
Page 13
INSTALLATION OF REMOTE CONTROLLER HOLDER INSTALLATION OF REMOTE CONTROLLER HOLDER NOTE: If the wall for installation is made of special material (such as wood board, density board and etc.), suitable fixing methods shall be adopted. NOTE: The place to install the remote controller shall not be easily splashed by water.
TROUBLESHOOTING Problem Diagnosis Solution Bathroom Heater does not A. A power failure occurred. A. Wait until the power is restored. work. B. The power cord is disconnected. B. Connect the power cord into the junction box of bathroom heater. C. Circuit breaker is in the "Off" position. C.
Page 17
2. Hold the two ends of the filter, and take it off by pulling the assembly. Holding Here Filter Filter 3. After the filter is cleaned, put it back to the wind swing assembly, on which there is an arrow symbol. Please make sure that the printed point is well matched with the mark to install the filter correctly.
